THORLABS DET10A Operating Manual page 5

COPYRIGHT 2006 by THORLABS INC.
DETAIL A
SCALE 2 : 1
Battery Cap
OUTPUT BNC WITH
0 TO 10V RANGE
5
BATTERY DIRECTION INDICATOR
2.8
0.11
19.1
0.75
DETECTOR SURFACE
21.1
0.83
A
1.035-40 EXTERNAL THREAD
MATES WITH SM1 LINE
12.7
0.50
TOLERANCES
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES
LINEAR TOLERANCES:
TWO PLACE DECIMAL:
THREE PLACE DECIMAL:
ANGULAR: 30'
SURFACE FINISH: 32 MICROINCHES
PARALLELISM: 0.002
FLATNESS: 0.002
STRAIGHTNESS: 0.002
CONCENTRICITY: 0.002
PERPENDICULARITY: 0.002
THREAD: CLASS 2 FIT
4
13052-S01 Rev C 11/8/2011
Page 5 of 5
70.1
2.76
53.3
2.10
15.2
0.60
NAME
DATE
DRAWN EC 1/11/06
EC
ENG APPR. 1/11/06
MFG APPR. EC 1/11/06
0.010
0.005
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
THORLABS, INC. ANY REPRODUCTION
IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
THORLABS, INC. IS PROHIBITED.
3 2
POWER SWITCH
26.2
1.03
0.535-40 INTERNAL THREAD
MATES WITH SM05 LINE
43.2
48
1.70
1.89
#8-32 x .25" THREAD
(M4 x 6.35MM for -EC VERSION)
PO BOX 366
THORLABS INC.
NEWTON NJ
TITLE:
1mm Si BIASED DETECTOR
MATERIAL:
SIZE
DET10A
A
SCALE: 1:1
SHEET 1 OF 1
DWG. NO. PART NO.
13052-E01 DET10A
1
REV.
A
