Chapter 2. LED Operation and Connector Details

Normal Operation of Individual LEDs

2.1

OK LED

2.1.1
LED
Green On
Off

LAN LED

2.1.2
The LAN LED indicates access to and activity on the Ethernet network. The LAN LED indicates network
packets are being processed by the network interface (not just passing through the embedded switch).
LED
Green Blinking The corresponding network interface is active.
Off

Status LED

2.1.3
The STATUS LED stays green during normal operation.
LED
Green On
Red Blinking

CONN LED

2.1.4
The CONN LED indicates the status of PROFINET connections.
LED
Green On
Amber Blinking No Device Name configured.
Off
20
LED Status
PNS OK
PNS Not OK
LED Status
The corresponding network interface is not active.
LED Status
Normal operation
A MAC address read from non-volatile memory is invalid. Ports with invalid MAC
addresses remain disconnected from the Ethernet network
LED Status
At least one PROFINET connection (AR) exists with an I/O Controller
No PROFINET connection (AR) exists.
PACSystems* RX3i PROFINET IO-Scanner User Manual GFK-2737F
