Contents Contents
Safety informations
Related equipment safety
Transport
Preparation
Checklist
Prepare to install the oven
Location requirements
Product dimensions - single ovens
Cabinet dimensions - single ovens
Product dimensions - double ovens
Cabinet dimensions - double ovens
Installation instructions
Prepare built-in oven
Remove and replace oven door(s)
Electrical connection
Install oven
Self-diagnosis
Temp sensor & Heater check
2 English
Install_NW9000K-DG68-00862A-03_EN+MES+CFR.indb 2

Safety informations

2

Related equipment safety

2
Remove all tape and packaging before using the appliance. Dispose of the
2
packaging after unpacking the appliance. Never allow children to play with
packaging material.
4
Never modify or alter the construction of the appliance. For example, do not
4
remove panels, wire covers or screws.
4

Transport

5
5
To avoid damage to the oven vent, use the transport method shown in the picture
6
below.
7
7
9
A
9
B
10
12
14
15
15
A. Front
B. Pallet
DANGER
ELECTRICAL SHOCK HAZARD
To avoid risk of electrical shock, personal injury or death; verify your appliance
has been properly grounded in accordance with local codes or in absence of codes,
with the National Electrical Code (NEC). ANSI/NFPA 70-latest edition.
WARNING
MOVING HAZARD
To avoid risk of severe personal injury; this appliance requires two or more people
while handling and moving. Use of appliance moving devices is recommended.
Support the bottom of the oven from either
side when moving it into the installation
location. Leave the unit attached to the
shipping pallet until it is in front of the
cabinet opening and is ready to be lifted
into place.
