Summary of Contents for BenQ DC E53 Plus
- Page 1 DC E53+ Digital Camera User’s Manual Welcome Downloaded From camera-usermanual.com BenQ Manuals...
-
Page 2: Taking Care Of Your Camera
Copyright Copyright 2005 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chem- ical, manual or otherwise, without the prior written permission of this company. -
Page 3: Table Of Contents
BenQ DC 5530 User’s Manual 1. Touring your DC E53+ ............1 ........1 1.1 Checking the Package Contents ............ 1 1.2 DC E53+ Components ............1 1.2.1 Front View ............2 1.2.2 Rear View ..........2 1.2.3 Status LED Indicator 2. - Page 4 BenQ DC 5530 User’s Manual ........15 3.3.2.2 Magnifying Images ....16 3.3.2.3 Thumbnail Display (Index Playback) ....... 16 3.3.3 Playback Mode Menu Settings .. 17 3.3.4 Playback Mode LCD Monitor Information (Video) ........17 3.3.5 Playing Back Video Clips ..............
-
Page 5: Touring Your Dc E53
BenQ DC 5530 User’s Manual DC E53+ OURING YOUR 1.1 Checking the Package Contents Carefully unpack your kit box and ensure that you have the following items. In the event that any item is missing or if you find any mismatch or damage, promptly contact your dealer. -
Page 6: Rear View
BenQ DC 5530 User’s Manual 1.2.2 Rear View LCD monitor Display / Audio mode button Status LED T Zoom in button W Zoom out button Menu button Delete button Strap eyelet Control and Set buttons Battery / SD memory card cover 10. -
Page 7: Preparing Your Dc E53+ For Use
BenQ DC 5530 User’s Manual DC E53+ REPARING 2.1 Installing the Battery We highly recommend you to use the specified rechargeable lithium-ion battery to realize the full capability of your digital still camera. Make sure that the power of the digital still camera is off before inserting or removing the battery. -
Page 8: Using An Ac Power Adapter
BenQ DC 5530 User’s Manual 2.3 Using an AC power adapter Using an AC power adapter prevents the digital still camera from automatically powering off while transferring files to your computer. Perform the steps in the preceding section "Charging the Battery". -
Page 9: Using The Dc E53
BenQ DC 5530 User’s Manual DC E53+ SING THE 3.1 Capture Mode 1. Press the POWER button to turn on the camera. 2. Slide the mode switch to [ Press down halfway 3. Compose your image in the LCD monitor. -
Page 10: Capture Mode Lcd Monitor Information
BenQ DC 5530 User’s Manual 3.1.1 Capture Mode LCD Monitor Information Camera mode Image quality ] SUPER FINE FINE ] NORMAL Image size (resolution) 2560 x 1920 2048 x 1536 1280 x 960 640 x 480 TIFF IMAGE Available number of shots... -
Page 11: Changing Camera Settings
BenQ DC 5530 User’s Manual 3.1.2 Changing Camera Settings Camera settings can be changed with the five-way button. 1. Up/Flash: Scrolls upwards in menus and enables you to choose the appropriate flash setting. 2. Left/Quick View: Scrolls left in menus and enables you to view the last picture that was captured. -
Page 12: Using The Flash
BenQ DC 5530 User’s Manual 3.1.2.2 Using the Flash The flash is designed to function automatically when lighting conditions warrant the use of flash. You can capture an image using a flash mode suitable to your circumstances. 1. Press the POWER button to turn on the camera. -
Page 13: Using The Self-Timer
BenQ DC 5530 User’s Manual 3.1.2.3 Using the Self-Timer The self-timer can be set in [ ] mode. This feature is useful for situations where you may wish to join into the scene when taking group shots. 1. Secure the camera to a tripod or place it on a stable surface. -
Page 14: Deleting Images
BenQ DC 5530 User’s Manual 3.1.2.5 Deleting Images Use this function to delete one or all images/video clips stored in the internal memory or memory card. Please note that the deleted images or video clips cannot be recovered. Immediate Erasure (Quick Delete Function) The quick delete function enables you to delete the last image during capture. -
Page 15: Capture Mode Function Menu
BenQ DC 5530 User’s Manual Icon Item Functional Description COLOR Sets the color of the image that will be captured. NORMAL B&W SEPIA WHITE Sets the white balance when capturing images under specific lighting con- BALANCE ditions. AUTO AUTO DAYLIGHT... - Page 16 BenQ DC 5530 User’s Manual Icon Item Functional Description Selects a brightness level for the LCD monitor. BRIGHTNESS The adjustment range is from –5 to +5. DIGITAL Enables or disables digital zoom. ZOOM – ON/OFF QUICK VIEW Sets to display a captured image on LCD monitor immediately after you...
-
Page 17: Video Mode
BenQ DC 5530 User’s Manual 3.1.3.2.3 Using the Digital Zoom Using a combination of 3 times optical zoom and 4 times digital zoom permits zoom photography up to 12 times to suit the subject and the distance. Digital zoom is a compelling feature, however, the more an image is enlarged (zoomed), the more pixilated (grainer) the image will appear. -
Page 18: Movie Mode Menu Settings
BenQ DC 5530 User’s Manual 3.2.2 Movie Mode Menu Settings 1. Slide the mode switch to [ MOVIE SETUP 2. Press the button to access in Camera menu, then use the buttons to select [FUNCTION] menu. 3. Use the / / / buttons to select the desired item in [FUNCTION] menu, then press the OK button. -
Page 19: Playback Mode Lcd Monitor Information (Image)
BenQ DC 5530 User’s Manual 3.3.1 Playback Mode LCD Monitor Information (Image) 1. Playback mode 2. Frame number 3. SD memory card indicator (if present) 4. Battery power indicator 5. Image size (resolution) 6. Camera mode 3.3.2 Viewing Images 3.3.2.1... -
Page 20: Thumbnail Display (Index Playback)
BenQ DC 5530 User’s Manual Note The range of magnification factor is: 1.5x, 2.0x, 2.5x, 3.0x, 3.5x, 4.0x, 4.5x, 5.0x, 5.5x, 6.0x, 6.5x, 7.0x, 7.5x and 8.0x. 3.3.2.3 Thumbnail Display (Index Playback) This function allows you to view four or nine thumbnail images on the LCD monitor simultaneously so you may search for a particular image. -
Page 21: Playback Mode Lcd Monitor Information (Video)
BenQ DC 5530 User’s Manual Icon Item Functional Description COPY TO Allows you to copy your files from the digital still camera’s internal memory COPY CARD to a memory card. Of course, you can only do this if you have a memory card installed and some files in internal memory. -
Page 22: Audio Mode
BenQ DC 5530 User’s Manual Notes • The zoom function cannot be activated while playing back video clips. • To play back video clips on the computer, we recommend you to use Windows Media Player 9.0 (WMP 9.0). You can download WMP ver- sion from the website at www.microsoft.com. -
Page 23: Deleting Voice Files
BenQ DC 5530 User’s Manual 1. Perform the above steps 1~3. Voice playlist appears on the screen. 2. Use the buttons to select the voice file you want to AUD_0011 play. 3. Press the OK button to start playback of the voice file PLAY! through the camera’s speaker. -
Page 24: Setup Menus In Playback Mode
BenQ DC 5530 User’s Manual Icon Item Functional Description FORMAT Erases all data and reformats the internal memory or the SD card loaded in your camera. Protected images are also erased. SD card cannot be format- ted if it is write-protected. -
Page 25: Pc Dependent Features
BenQ DC 5530 User’s Manual PC DEPENDENT FEATURES 4.1 Bundled Software The DC E53+ is supplied bundled with the following software: Ulead Photo Ulead® Photo Express™ 5.0 SE is a complete photo project software for Express digital images. Acquire photos effortlessly from digital cameras or scanners. -
Page 26: Printer Mode
BenQ DC 5530 User’s Manual 4.3 Printer Mode If a printer that supports PictBridge is available, images can be printed by connecting the digital still camera directly to the PictBridge-compatible printer without using a computer. Connecting the Camera to the Printer 1. - Page 27 BenQ DC 5530 User’s Manual 4. Use the buttons to select the desired item, then PRINT INFO press the OK button. Use the buttons to change the setting, then press the OK button to confirm. DATE ]: Specifies the number of prints. You can select the FILE NAME number up to 10.
- Page 28 BenQ DC 5530 User’s Manual 1. Use the buttons to select the [PRINT ORDER] PRINT MODE SELECT mode, then press the OK button. PRINT PRINT ORDER SELECT ITEM : ENTRY: 2. Use the button to access in the selection of paper PRINT PAPER setting, then press the OK button to print.
-
Page 29: Troubleshooting
BenQ DC 5530 User’s Manual ROUBLESHOOTING Refer to the symptoms and measures listed below before sending the camera for repairs. If the problem persists, contact your local reseller or service center. Symptom Cause Measure The power does not The battery is not loaded. - Page 30 BenQ DC 5530 User’s Manual Symptom Cause Measure Even if I press the The battery is running low. Recharge or use the AC power shutter button, the adapter. camera does not The camera is not in shooting Slide the mode switch to shooting shoot.
-
Page 31: Specifications
BenQ DC 5530 User’s Manual PECIFICATIONS Image Sensor 1/2.5-inch CCD Effective Pixels: 4.92 megapixels Total Pixels: 5.04 megapixels LCD Display 2.5-inch color LTPS LCD Lens Focal Length: f=5.4-16.2 mm (32mm-96mm; 35mm Equivalent) F No.: F2.8 / F4.8 Focusing TTL Auto Focus... -
Page 32: Service Information
BenQ DC 5530 User’s Manual ERVICE INFORMATION Technical Support If you encountered problems using DC E53+ and the camera driver program, please visit the following web address: http://support.BenQ.com For free driver program updates, product information and news release, please visit the following web address: http://www.BenQ.com...
