Refrigerator - Freezer
Thank you for your trust and for buying this appliance. We hope it will
Refrigerator with freezer is for domestic use
only.
The upper part of the appliance is
refrigerator and is used for storing fresh foods
at the temperature of 0°C and higher.
Before Putting Into Use .........................2
Important ...............................................3
Placing and Installation ........................4
Operation Control .................................7

Before Putting Into Use

 Before connecting the appliance to the
mains supply, leave it stand for about 2
hours, which will reduce a possibility of
malfunctions in the cooling system due to
transport handling.
 Clean the appliance, and be thorough,
especially in the interior (See Cleaning and
Maintenance).
 In case the interior accessories are not
correctly placed, rearrange them as
described in chapter Description of the
Appliance.
Instructions for Use
These instructions for use are intended for the
user. They describe the appliance and its
correct and safe use. They were prepared for
Downloaded from Fridge-Manual.com Manuals
2
successfully serve the purpose for many years.
7
Instructions for Use
The lower part is freezer and is used for
freezing fresh foods and storing frozen foods
for longer periods of time (up to one year,
depending on the kind of foods you store). The
compartment is marked with four stars.
Use...........................................................7
Door ......................................................10
Maintenance and Cleaning .................11
Trouble-Shooting Guide......................12
various types/models of appliances therefore
you may find in it description of some functions
and accesories that your appliance does not
have.
We Care for the Environment
 Our products use environmentally friendly
packaging, which can be either recycled or
disposed of in an environmentally friendly
manner. To this end, individual packaging
materials are clearly marked.
 These instructions are printed either on
recycled paper or chlorine free bleached
paper.
 When your appliance finally wears out,
please try not to burden the environment
with it; call your nearest authorised service
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RK 4200 W and is the answer not in the manual?

Questions and answers

Related Manuals for Gorenje RK 4200 W

Summary of Contents for Gorenje RK 4200 W

  • Page 1: Table Of Contents

    Refrigerator - Freezer Thank you for your trust and for buying this appliance. We hope it will successfully serve the purpose for many years. Refrigerator with freezer is for domestic use The lower part is freezer and is used for only.

  • Page 2: Instructions For Use

    agent. (See Disposing of the Worn Out mode selection switch to the setting for Appliance) automatic operation as soon as possible.  Before loading the appliance with packages of fresh foods, make sure they are cooled to Tips for Energy Savings ambient temperature.

  • Page 3: Time During Power Supply Interruption

    Time During Power Supply Disposing of the Worn Out Appliance Interruption  When your appliance finally wears out, dispose it of. If the appliance has a lock, Do not open the freezer in case of failure or break it, in order to prevent eventual power supply interruption! In case the accidents (danger of children get locked interruption is extended over longer period of...

  • Page 4: Connection To Power Supply

    Connection to Power Supply Connect the appliance with the cable and plug to the power supply socket outlet with a ground terminal (safety socket). Required nominal voltage and frequency are indicated on the rating plate. The connection to the mains supply and earthing have to be made according to current standards and regulations.

  • Page 5: Freezer (B)

     when the ambient temperature in the room is lifted in the front) thus enabling the positioning of bottles on the stopper as well. increased (above 30°C), It is protected against pulling out. If you want to  in case of increased humidity (during pull it out, simply lift its rear part and pull it summer season).

  • Page 6: Operation Control

    Operation Control  Changes of the ambient temprature affect The appliance is controlled with thermostat knob, situated in the right upper part inside the temperature in the interior of the appliance refrigerator.Turn the knob clockwise from (choose correct setting of the thermostat STOP (0) position towards 7 and backwards.

  • Page 7: Freezing Fresh Foods

    Fresh Food Storage Time in the Refrigerator Fresh Food Storage Storage time (days) Butter Eggs Meat: fresh uncut chopped smoked Fish Marinade Root Cheese Sweets Fruit Prepared dishes Legend: + recommended storage time = possible storage time  If you have a model with integrated Freezing Fresh Foods switch for intensive cooling, switch it on ...

  • Page 8: Storing Frozen Foods

     For freezing smaller amount of foods (up to Commercially Frozen Foods 1 kg) there is no need to change the The storage time and the recommended thermostat setting (see Temperature temperature for storing commercially frozen foods Selection). are indicated on the packaging. For storing and using consider the manufacturer's instruction.

  • Page 9: Changing The Direction Of Opening The Door

    Changing the Direction of Opening the Door of hair drier, for example) and lightly Appliances without cover stretched to the required height. In certain If you find the direction of opening the door on models it is not possible to replace the door your appliance inconvenient, you can change gasket.

  • Page 10: Maintenance And Cleaning

     Turn the middle hinge by 180° and attach it on the opposite side of the appliance.  Slip the lower door onto the middle hinge.  Screw in the lower footed hinge to the opposite side.  Unscrew the handles and replace them to the opposite side (not for handles mouinted horizontally).

  • Page 11: Cleaning The Appliance

     Avoid using defrosting sprays, as they may cause damage to the plastic parts and may be hazardous to health. Cleaning the Appliance Disconnect the power supply before cleaning the appliance. Do not use coarse or aggressive cleaning  Do not forget to clean also the defrost water agents as you can damage the surface.
  • Page 12 The cause of increased ice formation may be it has no influence whatsoever on the one of the following: lifetime of the appliance.  the door does not seal well (clean the  After starting the appliance, the operation gasket if it is contaminated, or replace it of the compressor and the refrigerant flow if it is damaged);...
