TABLE OF CONTENTS
1.
SPECIFICATIONS .................................................................................................................................................................................................................
2.
EXPLODED VIEW ................................................................................................................................................................................................................
3.
ACCESSORIES .....................................................................................................................................................................................................................
4.
I/O PORTS .............................................................................................................................................................................................................................
5.
CONNECTIONS ...................................................................................................................................................................................................................
6.
PANEL REMOVAL .................................................................................................................................................................................................................
7.
MOTHERBOARD INSTALLATION ...................................................................................................................................................................................
8.
POWER SUPPLY INSTALLATION .....................................................................................................................................................................................
9.
FILTERS REMOVAL ..............................................................................................................................................................................................................
10. FANS COMPATIBILITY .......................................................................................................................................................................................................
11. HARD DRIVE INSTALLATION ..........................................................................................................................................................................................
12. HARD DRIVE CAGE ............................................................................................................................................................................................................
13. DROP-N-LOCK SSD BRACKET .........................................................................................................................................................................................
14. WATERCOOLING INSTALLATION ...................................................................................................................................................................................
15. OPTIONAL UPGRADES ......................................................................................................................................................................................................
16. SUPPORT AND SERVICES .................................................................................................................................................................................................
1. SPECIFICATIONS
5
Dimension
210 mm x 465 mm x 470 mm (W x H x D)
6
8.3 in x 18.3 in x 18.5 in
8
Form Factor
Mid Tower
Material(s)
Steel chassis, steel exterior, ABS,
9
Tempered Glass
Motherboard support
ATX, Micro ATX, Mini ITX
10
E-ATX *(up to 272mm wide, unable to use
11
rubber grommets)
Front I/O
2x USB 3.0, Mic, Headphone, Reset,
13
LED Color Control, *3-Speed Fan
14
controller (*Eclipse P400S models only)
Side window
Tempered Glass Window panel
15
16
EXPANSION & DRIVE BAYS
17
Expansion slots
7
18
Internal 3.5"
6 (2x included)
Internal 2.5" (dedicated)
2 (2x included)
19
COOLING (FANS)
20
120 mm
22
Front
3x
(1x included)
23
Top
2x
Rear
1x
(1x included)
4
LIQUID COOLING
120 mm (Radiator)
Front
Up to 360*
Top
-
Rear
120
* 360 radiator requires the removal of the midplate cover
CLEARANCE
Graphic card
395 mm (15.2 in)
280 mm (11.0 in) Optional HDD brackets installed
CPU cooler
170 mm (6.7 in)
Cable Management
25 mm (1.0 in)
PSU (including cable)
270 mm (10.6 in)
Warranty
5 Years*
140 mm
2x
2x
-
140 mm (Radiator)
Up to 280
-
-
5
