  • Page 1 USER’S MANUAL FU LL VE RS IO N TEMPERED GLASS EDI TI ON...
  • Page 2 Thank you. Phanteks continues its user friendly design chassis with the new Eclipse Series P400. Without much effort, the P400 allows users to create a clean and beautiful system. Ambient RGB illumination adds character while the solid metal exterior gives the case a simple elegant design.

  • Page 3: Table Of Contents

    2x USB 3.0, Mic, Headphone, Reset, MOTHERBOARD INSTALLATION ....................................LED Color Control, *3-Speed Fan CPU cooler 170 mm (6.7 in) POWER SUPPLY INSTALLATION ..................................... controller (*Eclipse P400S models only) Cable Management 25 mm (1.0 in) Side window Tempered Glass Window panel PSU (including cable) 270 mm (10.6 in)

  • Page 4: Exploded View

    2. EXPLODED VIEW 1. Chassis 1. Châssis 1. Telaio 1. Chassi 2. Top Panel 2. Filtres de poussière inférieurs 2. Filtri antipolvere inferiori 2. Painel Superior 3. SSD Brackets 3. Support SSD 3. Staffa SSD 3. Suporte do SSD 4. Fans 4.

  • Page 5: Accessories

    responsibility for any damages incurred due to incorrect installation and usage of this product. 3. ACCESSORIES 4. I/O PORTS I / O P A N E L Top Dust Filters (P400S only) 1. USB 3.0 1. USB 3.0 1. USB 3.0 1.

  • Page 6: Panel Removal

    5. CONNECTIONS 6. PANEL REMOVAL CAPTIVE THUMBSCREWS AUDIO PANEL USB 3.0 Power SW MIC2 L Reset SW AGND IntA P2_D+ MIC2 R AVCC IntA P2_D- IntA P1_D+ H.D.D LED FRO-R MIC2_JD IntA P1_D- F_IO_SEN IntA P2_SSTX+ LINE2_JD FRO-L IntA P2_SSTX- IntA P1_SSTX+ IntA P1_SSTX- IntA P2_SSRX+...

  • Page 7: Motherboard Installation

    6. PANEL REMOVAL 7. MOTHERBOARD INSTALLATION For the front panel, place your hands on the area shown and pull outward. Pour le panneau avant, placez vos mains sur la zone affichée, et tirez vers l’ e xtérieur. Positionieren Sie auch bei der Frontblende Ihre Hände an der angezeigten Stelle und ziehen Sie sie dann nach außen.

  • Page 8: Power Supply Installation

    8. POWER SUPPLY INSTALLATION 9. FILTERS REMOVAL To remove the bottom and front filter pull out. Mesh cover on top panel can also be REAR VIEW cleaned. Pour retirer les filtres en bas et à l'avant, tirez dessus. La grille du panneau avant peut aussi être nettoyée.

  • Page 9: Fans Compatibility

    10. FAN COMPATIBILITY 11. HARD DRIVE INSTALLATION 3.5” INSTALLATION 2.5” INSTALLATION FAN COMPATIBILITY TABLE 140mm 120mm Front Rear Align the SSD onto the mounting holes and screw in. Place hard drive into tray and push in the arms to lock. Aligner le SSD avec les trous de montage et vissez.

  • Page 10: Hard Drive Cage

    12. HARD DRIVE CAGE 13. DROP-N-LOCK SSD BRACKET HDD BRACKET REMOVAL SSD INSTALLATION Slide in the SSD and screw in from the side to lock in place. To remove, unscrew the 4x screws on the midplate and the 4x screws on the bottom of the case. Para remover, solte os 4x parafusos na placa do meio e os 4x parafusos na parte inferior do gabinete.

  • Page 11: Watercooling Installation

    14. WATERCOOLING INSTALLATION 14. WATERCOOLING INSTALLATION 120 MM FORM FACTOR RADIATORS WATERCOOLING RADIATOR COMPATIBILITY *Caution: Supported Radiator size and thickness varies depending on your setup. Radiator Size Front Rear *Avertissement : Les tailles de radiateur et les épaisseurs supportées varient en fonction de votre Taille de radiateur Avant Arrière...

  • Page 12: Optional Upgrades

    15. OPTIONAL UPGRADES 3.5” HDD MODULAR BRACKET INSTALLATION (UP TO 4X EXTRA HDD’S) PWM FAN HUB INSTALLATION Step 1. Remove the HDD cover by removing the m3 Screw Step 2: Align the HDD bracket to the slot and drop in. REQUIREMENTS: Step 3: Screw in from the back with thumb screws to lock the bracket in place.
  • Page 13 16. SERVICES AND SUPPORT If you have any questions or concerns, please visit Phanteks’ website for technical support. We consider customer support, satisfaction and feedback an essential element of our overall marketing effort. Please feel free to contact our support team. Thank you! Contact Us at: www.phanteks.com www.phanteksusa.com...

This manual is also suitable for:

P400s
