INSTEON
Access Point
INSTEON RF Receiver/ RF-PLC Bridge
For models:
#2443
Access Point
#2443P
Access Point
™
two-pack

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2443 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for INSTEON 2443

Summary of Contents for INSTEON 2443

  • Page 1 ™ INSTEON Access Point INSTEON RF Receiver/ RF-PLC Bridge For models: #2443 Access Point #2443P Access Point two-pack...

  • Page 2: Table Of Contents

    Installing Additional Access Point Modules ....................6 ABOUT INSTEON ............................7 Understanding Why an INSTEON Network Is Reliable................7 Further Enhancing Reliability ........................7 Using SmartLabs’ Access Point to Upgrade Your INSTEON Network ............. 7 About INSTEON and X10.......................... 8 TROUBLESHOOTING..........................9 SPECIFICATIONS ............................10 Access Point Specifications ........................

  • Page 3: About Insteon Access Point

    INSTEON is a simple, reliable, and affordable breakthrough in home control. Simple, because Plug-n- Tap™ setup is a breeze, and there are no wires to add – INSTEON uses existing powerline wiring as well as radio-frequency for communication. Reliable, because every INSTEON device is a two-way repeater.

  • Page 4: How To Set Up Access Point

    Prior to setting up and using other INSTEON devices, you should properly install at least two Access Point Modules, so that INSTEON messages can travel everywhere in your home. Access Point Modules (when at least two are properly installed) couple together the two separate powerline circuits, known as powerline phases, which most homes are wired with.

  • Page 5: Install The Access Point

    INSTEON-compatible Access Point User’s Guide Install the Access Point 1. Plug the First Access Point into a convenient wall outlet. Don’t use an outlet controlled by a switch, because if the switch is inadvertently turned off, Access Point won’t have power. The white Status LED on the side will illuminate steadily, indicating that Access Point is working.

  • Page 6: Installing Additional Access Point Modules

    Installing Additional Access Point Modules You can add additional Access Point Modules to your INSTEON network to extend its coverage and maximize performance. Simply choose the Access Point that you previously installed as the First Access Point and follow the steps above to confirm that new Access Point Modules are communicating with your existing Access Point Modules.

  • Page 7: About Insteon

    INSTEON device helps to support the overall network. To further ensure reliability, every INSTEON device confirms that it has received a command. If an INSTEON Controller does not receive this confirmation, it will automatically retransmit the command up to five times.

  • Page 8: About Insteon And X10

    If you have any of these products and the BoosterLinc feature is turned on, please consult your User’s Guide or call 866-243-8018 for help with turning it off. You may then wish to install newer INSTEON BoosterLinc X10 Signal Boosters, which SmartLabs can help you with.

  • Page 9: Troubleshooting

    INSTEON-compatible Access Point User’s Guide TROUBLESHOOTING Problem Possible Cause Solution The Status LED on my Access Point is not getting Make sure Access Point is not plugged into a switched Access Point is not power. outlet that is turned off.

  • Page 10: Specifications

    INSTEON-compatible Access Point User’s Guide SPECIFICATIONS Access Point Specifications General SmartLabs Product Number 2443- INSTEON Access Point or 2443P- INSTEON Access Point (twin pack) Warranty 2 years Operation Status LED White INSTEON RF Features RF Frequency 900 MHz ISM band...

  • Page 11: Fcc Compliance Statement

    INSTEON-compatible Access Point User’s Guide FCC Compliance Statement This device complies with FCC Rules Part 15. Operation is subject to two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference that may be received or that may cause undesired operation.

  • Page 12: Certification

    You may also have other legal rights that may vary from state to state. INSTEON, Plug-n-Tap, ControLinc, TesterLinc, SignaLinc, LampLinc, ToggleLinc, BoosterLinc, ApplianceLinc, KeypadLinc, FilterLinc, ProbeLinc, SwitchLinc, TempLinc, IR Linc and SmarthomeLive are trademarks of Smarthome, Inc.

This manual is also suitable for:

2443p
