VORTEX Beat 2.0
ANDROID SMARTPHONE
QUICK-START USER GUIDE ANDROID 5.1

Advertisement

Table of Contents
loading

Related Manuals for Vortex Beat 2.0

Summary of Contents for Vortex Beat 2.0

  • Page 1 VORTEX Beat 2.0 ANDROID SMARTPHONE QUICK-START USER GUIDE ANDROID 5.1...
  • Page 2 PRECAUTIONS On the Road Using a device while driving is illegal in many countries. Please refrain from using your mobile while driving. Near Sensitive Electronics or Medical Equipment Don’t use your device near sensitive electronic equipment – particularly medical devices such as pacemakers –...

  • Page 3: Parts And Buttons Of The Device

    1. PARTS AND BUTTONS OF THE DEVICE 1 .Front camera 2. Speaker 3. Touchscreen 4. Volume button 5. Power button 6. Menu button 7. Home button 8. Back button 9. Micro USB and charging port 10. Earphone jack 11. Rear camera 12.

  • Page 4: Touch Buttons

    2. TOUCH BUTTONS button moves back one step to the previous menu/page. button returns immediately to the main screen. button displays a menu of recently opened applications. button will launch the applications and settings menu. 3. GETTING STARTED Installing the micro-SIM Card and Battery Switch off your phone before installing or replacing the battery or the micro-SIM card.

  • Page 5: Home Screen

    WARNING! To avoid damage to the phone, do not use any other kind of SIM card, or any non-standard micro-SIM card cut from a SIM card. You can get a standard micro-SIM card from your service provider. Insert the battery by aligning the metal contacts on the battery with the metal contacts in the battery compartment.
  • Page 6 5.QUICK NOTIFICATION PANEL When you receive a notification you can quickly view it by following the below instructions. Slide your finger from the top of the screen down to the center to access Notification Panel to see your notifications. Drag the notification menu down to display the second fast access menu, the menu will look similar to the below image.

  • Page 7: Settings Menu

    Through this menu, it is possible to modify the functions such as brightness, auto rotation, Wi-Fi, Bluetooth and more. 6. SETTINGS MENU cellphone The settings menu allows you to adjust Tablet System Confguration. To Change Settings: 1. Touch the “Settings” menu icon on the Application menu.

  • Page 8: Making And Receiving Calls

    • About Phone – Displays information about your phone 7. INSERTING/REMOVING SIM CAEDS 1. When phone is powered off insert a SIM card by removing the SIM cover as illustrated above, insert your finger in the indent located near the charging port and unclip the SIM cover, then insert the SIM card.

  • Page 9: Software Keyboard

    9. ANSWERING AND REJECTING CALLS To answer a call – Slide your finger to the blue Call Answer key. To reject a Call – Slide your finger to the Red Call End key. To message – touch the message icon. 10.
  • Page 10 Touchscreen The touchscreen responds to finger touch. Note: • Don’t place any object on the touchscreen for it may damage or crush the screen. Single Click: Single click one icon to choose the icon or option you want. Long Press: Press and hold an icon to delete or move an icon or app. Drag: Press the icon and drag it to a different screen.

  • Page 11: Connection To Internet

    2. A notification will pop up on the screen displaying USB connected, select the desired USB operation. 3. The USB connection has been successful. 12. CONNECTION TO INTERNET Wireless: 1. Select “Settings”. 2. Select “Wi-Fi” and slide OFF to ON status. 3.
  • Page 12 Web Browsing Connect to the Internet and launch the browser. Type in the desired browsing URL. 14.BLUETOOTH Select “Settings”, select Bluetooth from “OFF” to “ON”. Search for the device you would like to pair with and select “PAIR”. You will see a message “Connected Successfully”. 15.

  • Page 13: Troubleshooting

    1. Touch the icon to take a photo. 2. Touch the icon to start camera recording. 3. Touch the icon on the top right to see the previous picture and to delete, share or set it as a wallpaper. Click the return button to exit camera interface.
  • Page 14 normal. To close the application, click the icon on the shortcut bar to enter the system configuration interface. Select the Application Running and the interface is Tap the application you want to close. A pop-up window will be displayed. Tap “Stop”...
  • Page 15 SPECIFICATIONS CPU/PCB SOLUTION: Quad-core MTK 6580 DISPLAY: 4''WVGA(480*800)TN Capacitive SIM CARD SUPPORT: SINGLE SIM RAM: 512M ROM: 2G/GPRS/WAP/EDGE: 850/900/1800/2100MHz 1900/850 WI-FI: YES/802.11b/g/n FRONT CAMERA: 0.3MP REAR CAMERA: FM RADIO: BLUETOOTH: Version 4.0 GPS: TF CARD SUPPORT: Up to 32GB - Not Included CHARGER: DC 5V-700mA USB:...
  • Page 16 FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: Beat 2.0 (FCC ID: 2ADLJBEAT20) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at the ear is 0.503W/kg and when properly worn on the...
