The SimpliPhi Power PHI2.6™ Technical Overview:
PHI2.6™ Smart-Tech Battery Safety Protocol and
Protective Features
Safety Protocol:

IMPORTANT NOTE:

several points of a power storage and generation installation to effectively isolate and protect all
components of the system to safeguard against faults, short circuits, polarity reversals or a failure of
any component in the overall system. Fuses, breakers, wiring ratings and values should be determined
by established standards and evaluated by certified electricians, licensed installers, and regional code
authorities. Although each PHI2.6™ Smart-Tech Battery contains both an 80 Amp circuit breaker and
an internal BMS with circuitry that protects the Lithium Ferrous Phosphate cells from overcharge, over-
discharge and excessive load amperage, the PHI2.6™ Smart-Tech Batteries must always be installed with a
charge controller and the appropriate settings to protect the PHI2.6™ from open PV voltage and other high
voltage charging sources. The PHI2.6™ Smart-Tech Battery Management System (BMS) and internal circuit
breaker alone will not protect the PHI batteries from these extreme electrical phenomena. Failure
to adhere to installation protocol will void the Warranty.
CAUTION: Verify polarity at all connections with a standard volt meter before 1) energizing the
system and 2) turning the
at the battery terminals will void the Warranty and destroy the batteries.
PHI2.6™ Smart-Tech Batteries pose some risk of shock or sparking during the installation and initial wiring
and connection process. This is consistent with all other battery based storage formats. Be sure to turn
the built-in 80 Amp breaker to the "OFF" position to minimalize the risk of shock or sparks during the
installation and commissioning of the system. Use of insulated gloves, clothing and footwear is always
recommended when working in close proximity to electrical devices. Cover, restrain or remove jewelry
or conductive objects (metal bracelets, rings, belt buckles, metal snaps, zippers, etc.) when working with
any electrical or mechanical device. Cover or restrain long hair and loose clothing when working with any
electrical or mechanical device.
PHI2.6™ Smart-Tech Batteries do not vent any harmful gasses, and do not require special ventilation
or cooling.
PHI2.6™ Smart-Tech Batteries are not capable of thermal runaway. If the cells are severely damaged due to
physical abuse incurred outside of warranted specifications, which can cause electrolyte leakage and other
failures, as with any battery, the electrolyte can be ignited by an open flame. However, unlike other lithium
ion batteries (LCO) there are no hazardous or toxic materials in the electrolyte or the material components
of PHI2.6™ Smart-Tech Batteries. See MSDS for chemical analyses (Page 23).
SimpliPhi Power, Inc. | 420 Bryant Circle | Ojai, CA 93023, USA | +1 (805) 640-6700 | info@simpliphipower.com |
Circuit Breakers, Disconnects and Fuses should be employed throughout
80 Amp breaker "ON/OFF" switch to the "ON" position. Reverse polarity
