- Page 1 Crepe Griddle Model CE-CN-0397 Item 23571 Instruction Manual Revised - 5/21/2015 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: sales@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model CE-CN-0397 Section Page General Information ------------------------------------------------------------------------------------- 3 - 4 Safety and Warranty ----------------------------------------------------------------------------------------- 4 Technical Specifications ------------------------------------------------------------------------------------ 5 Installation ------------------------------------------------------------------------------------------------------ 5 Operation ------------------------------------------------------------------------------------------------------- 5 Maintenance --------------------------------------------------------------------------------------------------- 5 Troubleshooting ----------------------------------------------------------------------------------------------- 6 Instructions Français ------------------------------------------------------------------------------------ 6 - 7... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. -
Page 5: Technical Specifications
Technical Specifications Electrical 120V / 60Hz Temperature Range 60°C - 300°C / 140°F - 570°F Plate Diameter 15.62” / 396.8mm Weight 48.5 lbs. / 22 kg. Dimensions 17.5” x 20” x 9” / 444.5 x 508 x 228.6mm Installation Take out the Crepe Griddle from the packaging and place the unit on a stable surface. When this appliance is close to a wall, partitions, kitchen furniture, decorative finished, other objects, etc., it is recommended that they be made of non-combustible material, if not, it is recommended to put a barrier with a non-combustible heat-insulating material. -
Page 6: Troubleshooting
1 AN GARANTIE PIÈCES ET MAIN-D’ŒUVRE BANC Dans la période de garantie, contacter Omcan Inc. au 1-800-465-0234 pour planifier une chute hors soit un dépôt Omcan de service autorisé dans la zone ou à un entrepôt Omcan service pour réparer l’équipement. - Page 7 Instructions Français SERVICE TECHNIQUE Electric 120V / 60Hz Plage de température 60°C - 300°C / 140°F - 570°F Diamètre de la plaque 15.62” / 396.8mm Poids 48.5 lbs. / 22 kg. Dimensions 17.5” x 20” x 9” / 444.5 x 508 x 228.6mm INSTALLATION Retirez la plaque crêpe de l’emballage et placer l’appareil sur une surface stable.
-
Page 8: Parts Breakdowns
Parts Breakdown Model CE-CN-0397 23571... -
Page 9: Parts Breakdowns
Parts Breakdown Model CE-CN-0397 23571 Item Item Item OMC ID Description Position OMC ID Description Position OMC ID Description Position 31071 PA10315A01 Grilling Plate 31075 PA10315A05 Plug and Lead 31079 PA10315A09 Dial 31080 31072 PA10315A02 Element 31076 PA10315A06 Foot PA10315A10... -
Page 10: Electrical Schematics
Electrical Schematics Model CE-CN-0397 23571... -
Page 11: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 12 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
