egulating the Flow temperature in accordance with the outdoor temperature
R
The outdoor sensor has to be connected directly to circuit board SM20021. The sensor can thus be managed in one of
two ways:
• In case of remote controller + outdoor temperature sensor installation, the climatic compensation curve is set by
the remote itself (see remote control installation and operating manual).
• In case of outdoor temperature sensor only installation, the climatic compensation curve is set using the central
heating control button. As the arrow up
shown in figure 1 are displayed
The factors governing the correction are reported in figure 1.
The selection of the compensation curve is determined by the maximum delivery temperature Tm and the minimum
outdoor temperature Te.
N.B. The y-axis values of the delivery temperature Tm refer to standard 167-86 °F appliances or 104-77 °F floor-
mounted appliances. The type of appliance can be programmed using parameter 3 (see 5.1 "Parameter
programming").
