Summary of Contents for Pride MILLE
- Page 3 Each master amplifier must be paired up with a exact same model slave amp. Fuses are equipped with for MILLE ( 30Ax3 ATC ). MEZZO is not equipped with the fuse. Fuse ratings are 90A for MILLE and 120A for MEZZO single unit.
- Page 4 This turns on the amplifier whenever MILLE has built-in Fuses ( 30A x 3 ) the source unit is turned on. MEZZO : 120A ( 240A for Link )
- Page 5 RCA INPUTS - REMOTE CONTROL - The RCA inputs ensure the highest quality contacts Use this to control level of the amplifier from and the lowest noise in your audio system. your driver’s seat. RCA OUTPUTS - LOW PASS CROSSOVER FREQUENCY CONTROL - The RCA outputs connect another amplifier for multi This allows you to tune the response of the amplifier car amplifiers system.
- Page 6 Ground Fuses 4 - 1 OHMS...
- Page 7 INPUT CONNECTION STEPS ; Step 1. Set output master / input slave swtich to OUTPUT MASTER on master amplifier. Step 2. Set output master / input slave swtich to INPUT SLAVE on slave amplifier. Step 3. Connect RCA JACK on master amp to RCA JACK on slave amp. Set Master amp switch to Output Master MASTER AMPLIFIER...
- Page 8 SPEAKER OUTPUT CONNECTION STEPS ; Step 1. Connect speaker cable ( ) on master amplifier to subwoofer ( ) Step 2. Connect speaker cable ( ) on slave amplifier to subwoofer ( ) Step 3. Connect speaker cable ( ) on master amplifier to speaker cable ( ) on slave amplifier MASTER AMPLIFIER Fuses Ground...
-
Page 9: Trouble Shooting
... In any case, consult authorized dealer AMPLIFIER GOES IN PROTECTION MODE AT HIGHER GAIN Check speaker impedance ( MILLE & MEZZO ) is 1ohm for single unit and 2ohm for link connection. Check working voltages ( 8.5V - 16Volts for MILLE & MEZZO ) - Page 10 FEATURES MILLE MEZZO 4ohm Power 400W 500W 2ohm Power 650W 900W 1ohm Power 1000W 1500W Frequency Response 15Hz - 270Hz 15Hz - 270Hz Signal to Noise 85dB 85dB Efficiency @ 4ohm O ver 90% O ver 90% Damping Factor 200 <...
