Page 3: Before Use
Check the contents: Check that the carton contains the following items: Operating instructions LED Diamond II light effect SAFETY INSTRUCTIONS: CAUTION: To reduce the risk of electric shock, do not remove the top cover. No user-serviceable parts inside. Refer servicing to qualified service personnel only. - Page 4 See chapter “how to use the unit” for more information. 6. DOWN button: Used to select a lower speed or DMX address. See chapter “how to use the unit” for more information. 7. ENTER button: used to confirm your selection. JB SYSTEMS LED DIAMOND II ®...
-
Page 5: Overhead Rigging
Pin layout XLR-3pin: Pin1 = GND ~ Pin2 = Negative signal (-) ~ Pin3 = Positive signal (+) Pin layout XLR-5pin: Pin1 = GND ~ Pin2 = Negative signal (-) ~ Pin3 = Positive signal (+) ~ Pins4+5 not used. JB SYSTEMS LED DIAMOND II ®... -
Page 6: How To Operate The Unit
Connect nothing to the DMX input of the first LED DIAMOND, because this will be the Master Unit. Select in this Master unit one of the automatic or sound controlled modes like mentioned in the previous chapter ‘STANDALONE MODE” JB SYSTEMS LED DIAMOND II ®... - Page 7 Mode A7 9: Strobe effect at speed 9 210 - 239 Mode SO1: sound controlled color mode 240 - 249 Mode SO2: sound controlled strobe mode 250 - 255 Random Changing Sound Controlled Show (A1 to A7) JB SYSTEMS LED DIAMOND II ®...
-
Page 8: Maintenance
(1 red + 1 green + 1 blue + 1 white + 1 orange + 1 purple) Weight: 0,42 kg Dimensions: 190 x190 x 175mm The information might be modified without prior notice You can download the latest version of this user manual on our website: www.jb-systems.eu JB SYSTEMS LED DIAMOND II ®...
