- Page 1 Manual Information, updates and the latest manual for download under www.Hi-Skyper.com Content Model is made of a multipart EPP- Parts to add: Accessoires Body Rear wing LiPo charger with balancer Brushless motor with holder left and right truss 10V /220V adaptor...
-
Page 2: Security Advices
SECURITY ADVICES • The Hi-Skyper is not suitable for children under the age of 14 years. Adolescents just can run the model under attention of a parent. • The operation with this Hi-Skyper model requieres a high level of technical knowledge, carefulness and an special safety-conscious acting. -
Page 3: The Remote Control
The remote control The model will be controlled by the left and right throttle (1 & 2) – Factory Settings: left sided elevator and ruder/ right sided acceleration and Querruder. The trimmer (3-6), each close to the throttle will be used to adjust ruder an elevator. Under the cover (7) the crystal is located which firms the channel oft he controller –... -
Page 4: Assembling Of The Model
Assembling of the model Step 1 Assembling of the rear wing Add the parts as shown in Figure 1. Assure that the outer carriers are not mixed up (Stickers at the outer side) Fix the carriers and ruder to the wing using the smaller screws Step 2 Installation of the receiver Below the cockpit you will find the plugs for the servos and the motor controller marked as follows:... - Page 5 Test drive, not test flight Weather conditions: less / no wind For testing the Hi-Skyper , a free and flat surface is required – a sheet of ice, a snow-capped or asphalted area with the dimensions of 100 x 100 m would be ideal.
- Page 6 Frozen water If you test your Hi-Skyper on an iced areal, just enter it if everything safety. Don´t get in Danger. On an iced area the Hi-Skyper can achieve the top speed – optimal to fight races.
- Page 7 Stick new plastic sliders on the model. Trimming is not alright. Trim rudders The surface falls off to one side. Choose another surface for starting Sidewind affects the sliding. Always start against the wind. Schematic Further hints are available on the Hi-Skyper homepage: www.Hi-Skyper.com...
-
Page 8: Beschreibung Description
HS1132 LiPo Ladegerät LiPo charger AA1130 FlyCamOne USB 8Mb 24g 320x240px Li-Ion SD CardSlot ACME the game company – Industriestr. 10A – 33397 Rietberg – Germany Hotline: 0700 70 77 77 00 - Fax 05244 97 40 48 info@ACME-Online.de www.ACME-Online.de... -
Page 9: Important Battery Information
Lorsque la pile ne fonctionne plus, enlevez-la et emmenez-la dans un centre de recyclage. T: +49 700 70 77 77 00 F: +49 5244 97 40 48 E:info@acme-online.de www.ACME-Online.de © copyright 2006 ACME the game company...
