PMA-50
INTEGRATED AMPLIFIER
Quick Start Guide
Guide de démarrage rapide / Guía de inicio rápido
Read Me First....
Lisez-moi en premier.... / Lea esto primero....
Please do not return this unit to the store – call for assistance.
If you need help... :
If you need additional help in solving problems, contact Denon customer service in your area.
1-855-MY.Denon
1-855-693-3666
Call for Assistance: Monday – Friday 10:00AM to 10:00PM E.S.T, Saturday 12:00PM to 8:00PM E.S.T
For frequently asked questions please visit www.usa.denon.com/FAQ
For US and Canada only
ENGLISH
FRANÇAIS
ESPAÑOL
Advertisement
Table of Contents
Related Manuals for Denon PMA-50
Summary of Contents for Denon PMA-50
-
Page 1: Quick Start Guide
Lisez-moi en premier../ Lea esto primero..Please do not return this unit to the store – call for assistance. If you need help… : If you need additional help in solving problems, contact Denon customer service in your area. 1-855-MY.Denon 1-855-693-3666 Call for Assistance: Monday –... -
Page 2: Before You Begin
Welcome Before You Begin Thank you for choosing a Denon amplifier. This guide provides What’s In the Box step-by-step instructions for setting up your amplifier. Quick Start Guide Integrated Amplifier Owner’s Manual Power cord Safety Instructions Remote control unit Notes on radio... -
Page 3: Required For Basic Connections
Required for Basic connections Speaker systems Speaker cables Optional Computer Bluetooth device These drawings are for illustrative purposes only and may not represent the actual product(s). - Page 4 Setup There are seven steps to the setup process. Before using the remote control unit Placing this unit Installing the driver software onto your PC (Windows OS only) Connecting the speakers to the amplifier Plug the power cord into a power outlet Enjoying music using PC or Mac Enjoying music using Bluetooth...
-
Page 5: Before Using The Remote Control Unit
Before using the remote Placing this unit control unit n Horizontal placement The feet are initially attached to the unit for horizontal installation. -
Page 6: Vertical Placement
n Vertical placement Remove the cap (black). NOTE Be careful not to damage your nails when removing the caps. If necessary, use a thin-tipped tool to remove the caps. However, be careful not to damage the unit when using tools. Rotate the removed feet clockwise to attach them. - Page 7 Installing the driver software onto your PC (Windows OS only) Download the dedicated driver from the Install the driver. “Download” section of the PMA-50 page of q Select the language to use for the installation. the Denon website w Click “OK”.
- Page 8 r Read the Software Licensing Agreement, y Click “Install” on the installation start dialog. and click “I accept the terms in the license • The installation starts. Do not perform any agreement”. operation on the PC until the installation is t Click “Next”.
- Page 9 u In the Windows security dialog, select “Always trust software from DandM Holdings Inc.”. i Click “Install”. o When the installation is completed, click “Finish”.
-
Page 10: Connecting The Speakers To The Amplifier
Connecting the speakers to the amplifier Connecting the speaker cables q Peel off about 3/8 inch (10 mm) of sheathing from the tip of the speaker cable, then either twist the core wire tightly or apply solder to it. USB-DAC OPTICAL OPTICAL COAXIAL... -
Page 11: Plug The Power Cord Into A Power Outlet
Plug the power cord into a power outlet USB-DAC OPTICAL OPTICAL COAXIAL DIGITAL AUDIO SUBWOOFER SPEAKERS PRE OUT AUDIO IMPEDANCE : 4～16Ω Power cord (supplied) Connect to household power outlet (AC 120 V, 60 Hz) -
Page 12: Enjoying Music Using Pc Or Mac
Enjoying music using PC or Mac n Connect to PC or Mac n Listen to PC or Mac Audio Connect to PC or Mac. Press to change the input source to “USB- Computer on which Type A DAC”. the driver software and USB 2.0 cable audio player software are (supplied) - Page 13 D/A converter. • When there is a checkmark for a different device, • It is recommended that “2 channel, 24 bit, click “Denon USB Audio” and “Set Default”. 192000 Hz (Studio Quality)” is selected. r Select “Digital Audio Interface” and click u Click “Apply”.
- Page 14 Check that “Use this device for sound output” is checked in “PMA-50”. • If a different device is checked, select and “Secondary click” on “PMA-50”, and then select “Use this device for sound output”. t Quit Audio MIDI Setup.
- Page 15 NOTE Play back a music file with music playback • Adjust the volume to an appropriate level on the computer. software such as Windows Media Player, • Further settings might be required in your dedicated media iTunes, foobar2000, Audirvana Plus and player software such as JRiver to enable high resolution JRiver Media Center.
-
Page 16: Enjoying Music Using Bluetooth
Enjoying music using Bluetooth Select “Denon PMA- Press for 3 seconds or 50” from the Bluetooth longer. device list on your • “Pairing“ appears on the Denon PMA-50 display of the unit. device. • “At the end of the pairing,... -
Page 17: Online Version
Insert the disc into your Online Manual Contents English WEB Manual Follow the screen or double click on the PDF Overview INTEGRATED AMPLIFIER file. Connections PMA-50 Playback Settings Tips Appendix PDF Download INTEGRATED AMPLIFIER Copyright 2014 D&M Holdings Inc. All Rights Reserved. - Page 18 D&M Holdings Inc. Printed in China 5411 11248 00AD...
