Hardware Installation Guide

DGS-1210/ME Series
Product Model :
Metro Ethernet Switches
Release 1.10
©Copyright 2014. All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for D-Link DGS-1210/ME Series

Summary of Contents for D-Link DGS-1210/ME Series

  • Page 1: Hardware Installation Guide

    Hardware Installation Guide DGS-1210/ME Series Product Model : Metro Ethernet Switches Release 1.10 ©Copyright 2014. All rights reserved.
  • Page 2 Reproduction in any manner whatsoever without the written permission of D-Link Computer Corporation is strictly forbidden. Trademarks used in this text: D-Link and the D-Link logo are trademarks of D-Link Computer Corporation; Microsoft and Windows are registered trademarks of Microsoft Corporation.

  • Page 3: Table Of Contents

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Table of Contents Table of Contents ............................. i Intended Readers ............................. 1 Typographical Conventions ........................... 1 Notes and Cautions ............................1 Safety Instructions ............................1 Safety Cautions ............................1 General Precautions for Rack-Mountable ....................2 Protecting Against Electrostatic Discharge ....................

  • Page 5: Intended Readers

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Intended Readers The DGS-1210/ME Series Hardware Installation Guide contains information for set up and management of the Switch. This manual is intended for network managers familiar with network management concepts and terminology. For all practical reasons all the switches in this series will be simply referred to as the Switch throughout this manual.

  • Page 6: General Precautions For Rack-Mountable

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide the part or contact your trained service provider: Damage to the power cable, extension cable, or plug. An object has fallen into the product. The product has been exposed to water. The product has been dropped or damaged.

  • Page 7: Protecting Against Electrostatic Discharge

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide CAUTION: Installing systems in a rack without the front and side stabilizers installed could cause the rack to tip over, potentially resulting in bodily injury under certain circumstances. Therefore, always install the stabilizers before installing components in the rack.

  • Page 8: Product Introduction

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Product Introduction  Switch Description  Front Panel Description  LED Indicators  Rear Panel Description  Side Panel Description  Gigabit Fiber Port  Connecting the DPS-200 to the RPS Port (for DGS-1210-10/ME only) ...
  • Page 9 DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide  LEDs for Power, Console, Link/Act for port 1 ~ 20. Figure 1.2 – DGS-1210-20/ME Front Panel CAUTION: The MiniGBIC ports should use UL listed Optical Transceiver product, Rated Laser Class I. 3.3Vdc.

  • Page 10: Led Indicators

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Figure 1.5 – DGS-1210-28P/ME Front Panel CAUTION: The MiniGBIC ports should use UL listed Optical Transceiver product, Rated Laser Class I. 3.3Vdc. LED Indicators The Switch supports LED indicators for Power, Console, Fan, and Link/Act for each port. The following shows the LED indicators for the DGS-1210/ME Metro Ethernet Switch along with an explanation of each indicator.

  • Page 11: Rear Panel Description

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Amber Solid Light Error Condition Solid Off No Power feeding When there is a secure 1000Mbps Solid Green Ethernet connection (or link) at any of the ports. LED Per When there is reception or...

  • Page 12: Side Panel Description

    Figure 1.12 - Side panels of the DGS-1210/ME SERIES Gigabit Fiber Ports The DGS-1210/ME Series features support four Small Form Factor Portable (SFP) ports (optional). See the diagram below to view the four SFP port modules being plugged into the Switch.

  • Page 13: Conncting The Dps-200 To The Rps Port (For Dgs-1210-10/Me Only)

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide The Switch is equipped with SFP ports, which are to be used with fiber-optical transceiver cabling in order to uplink various other networking devices for a gigabit link that may span great distances.
  • Page 14 DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Figure 1.16 –Installing the DPS-200 in the DPS-800 The DPS-800 rack-mount chassis can be mounted into a standard 19" rack. Use the following diagram to guide you.

  • Page 15: Installation

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Installation This chapter provides unpacking and installation information for the D-Link Metro Ethernet Switch. Step 1: Package Contents Open the shipping carton and carefully unpack its contents. Please consult the packing list located in the User Manual to make sure all items are present and undamaged.

  • Page 16: Step 3 - Plugging In The Ac Power Cord

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Then, use the screws provided with the equipment rack to mount the switch in the rack. Figure 2.3 – Mount the Switch in the rack or chassis Please be aware of following safety Instructions when installing: A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.

  • Page 17: Power Failure

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Figure 2.4 – Plugging the switch into an outlet Power Failure As a precaution, the switch should be unplugged in case of power failure. When power is resumed, plug the switch back in.

  • Page 18: Switch Management

    Connecting to the Console Port Management Options The D-Link Metro Ethernet Switch can be managed through any port on the device by using the Web-based Management or command line interface. Each switch must be assigned its own IP Address, which is used for communication with the Web-Based Management or a SNMP network manager.

  • Page 19: Login Web-Based Management

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Login Web-based Management In order to login and configure the switch via an Ethernet connection, the PC must have an IP address in the same subnet as the switch. For example, if the switch has an IP address of 10.90.90.90, the PC should have an IP address of 10.x.y.z (where x/y is a number between 0 ~ 254 and z is a number between 1 ~ 254), and...

  • Page 20: Password Protection

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Figure 3.4 Initial Console Screen after Logging In NOTE: The baud rate for firmware version 6.10 is 115200bps and for firmware version 6.11 is 9600bps. Password Protection The DGS-1210 Series Switches do not have a password. One of the first tasks when settings up the Switch is to create user accounts.

  • Page 21: Assigning Ip Addresses

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide save all your configuration changes in nonvolatile storage, you must use the save command to copy the running configuration file to the startup configuration. Assigning IP Addresses Each Switch must be assigned its own IP Address, which is used for communication with an SNMP network manager or other TCP/IP application (for example BOOTP, TFTP).

  • Page 22: Snmp Settings

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Switch IP address can be automatically set using BOOTP or DHCP protocols, in which case the actual address assigned to the Switch must be known. The IP address may be set using the Command Line Interface (CLI) over the console serial port as follows: Starting at the command line prompt, enter the commands config ipif System ipaddress xxx.xxx.xxx.xxx/yyy.yyy.yyy.yyy...

  • Page 23: Traps

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide SNMP v3 uses a more sophisticated authentication process that is separated into two parts. The first part is to maintain a list of users and their attributes that are allowed to act as SNMP managers. The second part describes what each user on that list can do as an SNMP manager.

  • Page 24: Web-Based Switch Configuration

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Web-based Switch Configuration  Logging onto the Web Manager  Web-based User Interface  Areas of the User Interface  Web Pages Logging onto the Web Manager In order to login and configure the switch via an Ethernet connection, the PC must have an IP address in the same subnet as the switch.

  • Page 25: Web Pages

    This area displays the Switch's ports and expansion modules and shows port Tool Bar activity, depending on the specified mode. Some management functions, including port monitoring are accessible here. Click the D-Link logo to go to the D-Link Website. Main...

  • Page 26: Appendix A - Ethernet Technology

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Appendix A - Ethernet Technology The appendix contains the device specifications, and contains the topics: • Technical Specifications • Supported Transceivers Technical Specifications Performance Transmission Method Store-and-forward Packet Buffer memory DGS-1210-10/ME: 1.5Byutes DGS-1210-20/ME: 1.5Byutes...
  • Page 27 DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Physical and Environmental DGS-1210-52/ME: Smart Fan Operating Temperature -5 to 50 degrees Celsius Storage Temperature -40 to 70 degrees Celsius Humidity Storage: 5% to 90% non-condensing Dimensions 11-inch, 1U Rack-mount size: - DGS-1210-10/ME: 280 mm x 126 mm x 44 mm...
  • Page 28 DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide General 8 x 10/100/1000 Mbps ports 2 x 1000Mbps SFP ports DGS-1210-20/ME: 16 x 10/100/1000 Mbps ports 4 x 1000Mbps SFP ports DGS-1210-28/ME: 24 x 10/100 /1000Mbps ports 4 x 1000Mbps SFP ports...

  • Page 29: Appendix B -Cables And Connectors

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Appendix B –Cables and Connectors Ethernet Cable: When connecting the Switch to another switch, a bridge or hub, a normal cable is necessary. Please review these products for matching cable pin assignment.
  • Page 30 DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Console Cable: When connecting the Switch a PC, a Console cable is necessary. The following diagrams and tables show the standard Console-to-DJ-45 receptacle/connector and their pin assignments. Figure B- 2. Console-to-RJ-45 Cable...

  • Page 31: Appendix C - Module Specs And Cable Lengths

    DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide Appendix C – Module Specs and Cable Lengths Use the following table to as a guide for the module specs and maximum cable lengths. Standard Media Type Maximum Distance 1000BASE-LX, Single-mode fiber module...
  • Page 32 The customer must submit with the product as part of the claim a written description of the Hardware defect or Software nonconformance in sufficient detail to allow D-Link to confirm the same, along with proof of purchase of the product (such as a copy of the dated purchase invoice for the product) if the product is not registered.
  • Page 33 D-Link Corporation/D-Link Systems, Inc., as stipulated by the United States Copyright Act of 1976 and any amendments thereto. Contents are subject to change without prior notice. Copyright 2004 by D-Link Corporation/D-Link Systems, Inc.

  • Page 34: Product Registration

    Product Registration Register your D-Link product online at http://support.dlink.com/register/ Product registration is entirely voluntary and failure to complete or return this form will not diminish your warranty rights.

  • Page 35: Tech Support

    You can find software updates and user documentation on the D- Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the service period, and warranty confirmation service, during the warranty period on this product.
  • Page 36 Technical Support United Kingdom (Mon-Fri) Home Wireless/Broadband 0871 873 3000 (9.00am–06.00pm, Sat 10.00am-02.00pm) Managed, Smart, & Wireless Switches, or Firewalls 0871 873 0909 (09.00am – 05.30pm) (BT 10ppm, other carriers may vary.) Ireland (Mon-Fri) All Products 1890 886 899 (09.00am-06.00pm, Sat 10.00am-02.00pm) €0.05ppm peak, €0.045ppm off peak Times Internet http://www.dlink.com...

  • Page 37: Assistance Technique

    Assistance technique Assistance technique D-Link sur internet : http://www.dlink.com Assistance technique D-Link par téléphone : 01 76 54 84 17 Du lundi au vendredi de 9h à 19h (hors jours fériés) Asistencia Técnica Asistencia Técnica Telefónica de D-Link: +34 902 30 45 45 0,067 €/min...

  • Page 38: Pomoc Techniczna

    Pomoc techniczna Telefoniczna pomoc techniczna firmy D-Link: 0 801 022 021 Pomoc techniczna firmy D-Link świadczona przez Internet: http://www.dlink.com Technická podpora Web: http://www.dlink.com E-mail: support@dlink.cz Telefon ČR: +420 211 151 640 nebo SK: +421 (0)692 147 110 Telefonická podpora je v provozu: PO - PÁ od 09:00 do 17:00 Volání...
  • Page 39 Internetin kautta : http://www.dlink.com Arkisin klo. 09:00 - 18: 00 Numerosta : 0200-555 57 Teknisk Support D-Link Teknisk Support via Internet: http://www.dlink.com D-Link Teknisk Support via telefon: 0770-33 00 35 Vardagar 08:00 - 17:00 Assistência Técnica Assistência Técnica da D-Link na Internet: http://www.dlink.com e-mail: soporte@dlink.es...
  • Page 40 D-Link - ovo spletno stran www.dlink.eu http://www.dlink.com Suport tehnic Vă mulţumim pentru alegerea produselor D-Link. Pentru mai multe informaţii, suport şi manuale ale produselor vă rugăm să vizitaţi site-ul D-Link www.dlink.eu http://www.dlink.com...
  • Page 41 Technical Support You can find software updates and user documentation on the D-Link website. Tech Support for customers in Australia: D-Link Middle East - Dubai, U.A.E. Tel: 1300-766-868 Plot No. S31102, 24/7 Technical Support Jebel Ali Free Zone South, Web: http://www.dlink.com.au P.O.Box 18224, Dubai, U.A.E.
  • Page 42 Technical Support You can find software updates and user documentation on the D-Link website. Tech Support for customers in ‫שראל‬ Iran Unit 5, 5th Floor, No. 20, 17th Alley , Bokharest ‫מטלון סנטר‬ St. , Argentine Sq. , ‫רח' המגשימים‬...
  • Page 43 Обновления программного обеспечения и документация доступны на Интернет-сайте D-Link. D-Link предоставляет бесплатную поддержку для клиентов в течение гарантийного срока. Клиенты могут обратиться в группу технической поддержки D-Link по телефону или через Интернет. Техническая поддержка компании D-Link работает в круглосуточном режиме ежедневно, кроме...
  • Page 44 SOPORTE TÉCNICO Usted puede encontrar actualizaciones de softwares o firmwares y documentación para usuarios a través de nuestro sitio www.dlinkla.com SOPORTE TÉCNICO PARA USUARIOS EN LATINO AMERICA Soporte técnico a través de los siguientes teléfonos de D-Link PAIS NUMERO Argentina...
  • Page 45 Suporte Técnico Caso tenha dúvidas na instalação do produto, entre em contato com o Suporte Técnico D-Link. Acesse o site: www.dlink.com.br/suporte...
  • Page 46 D-Link 友訊科技 台灣分公司 技術支援資訊 如果您還有任何本使用手冊無法協助您解決的產品相關問題，台灣 地區用戶可以透過我們的網站、電子郵件或電話等方式與D-Link台灣 地區技術支援工程師聯絡。 D-Link 免付費技術諮詢專線 0800-002-615 手機付費電話 (02)6600-0123#8715 服務時間：週一至週五，早上9:00到晚上9:00 (不含周六、日及國定假日) 網 站：http://www.dlink.com.tw 電子郵件：dssqa_service@dlink.com.tw 如果您是台灣地區以外的用戶，請參考D-Link網站全球各地 分公司的聯絡資訊以取得相關支援服務。 產品保固期限、台灣區維修據點查詢，請參考以下網頁說明： http://www.dlink.com.tw 產品維修： 使用者可直接送至全省聯強直營維修站或請洽您的原購買經銷商。...
  • Page 47 Dukungan Teknis Update perangkat lunak dan dokumentasi pengguna dapat diperoleh pada situs web D-Link. Dukungan Teknis untuk pelanggan: Dukungan Teknis D-Link melalui telepon: Tel: +62-21-5731610 Dukungan Teknis D-Link melalui Internet: Email : support@dlink.co.id Website : http://support.dlink.co.id...
  • Page 48 Technical Support この度は弊社製品をお買い上げいただき、誠にあり がとうございます。 製品に同梱されている保証書の購入元にお問い合 わせください。...
  • Page 49 技术支持 辦公地址：北京市朝陽區將台路５號院５號樓 郵編：100016 技術支持中心電話：400-629-6688 技術支持中心傳真：(028)-61317620 各地維修中心地址請登陸官方網站查詢 網址：http://www.dlink.com.cn 400電話工作時間：工作日9:00-19:00；節假日9:00-18:00.

  • Page 50: Registration Card

    8. What category best describes your company? Aerospace Engineering Education Finance Hospital Legal Insurance/Real Estate Manufacturing Retail/Chain store/Wholesale Government Transportation/Utilities/Communication System house/company Other________________________________ 9. Would you recommend your D-Link product to a friend? Don't know yet 10.Your comments on this product? __________________________________________________________________________________________ __________________________________________________________________________________________...
  • Page 52 DGS-1210/ME series Metro Ethernet Switch Hardware Installation Guide...
