Assembly Instructions:

Bass Drum Assembly and Positioning

Tom Mounting
Bracket
Bass Drum
Spur
Figure A
Figure C
Tom Mounting
Bracket
Figure D
D r u m S e t O w n e r ' s M a n u a l
D4522
Hoop
1. Place the Bass Drum on a flat surface with the Bass Drum
Front Head
with Logo
2. Assemble the 4" Tension Rod/Nylon Washer/Metal Washer and
Tension Rod
Claw
Drum Lug
Figure B.
Hoop
3. Turn the bass drum over and place the Batter Side Clear Drum
Batterside
Head
4. Place the Bass Drum upright and bring the left and right Bass
Bass Drum
Spur
Rubber to
Spike Tip
Spurs facing as pictured. Place the Resonant Side Ebony Drum
Head with the SPL Logo onto the shell centering the logo
along and in line with the Tom Mounting Bracket. Then place
one of the Hoops bevel side down onto the Drum Head.
Figure A.
insert through a Bass Drum Claw. Then hook over the hoop
and finger tighten into the Drum Lug. Attach the rest of the 4"
Tension Rods/Nylon Washers/Metal Washers/ Bass Drum Claws
to this side of the bass drum. Figure B.
Head onto the shell. Then place the other hoop bevel side
down onto the drum head. Repeat step 2. Figure C.
Drum Spurs forward as shown in Figure D and tighten. Using
the supplied Drum Key adjust the length of each spur to raise
the front of the bass drum slightly up off the floor. Note that
the Rubber Tip Feet screw back to revel a Spike Tip. This allows
you to use on any type of flooring. Use the spike tip only on
carpeted surfaces.
Drum Key
