Turns the DVR+, TV,
or an audio device off
Selects the TV input
(see Programming the
Remote Control on
Reformats screen ratio
Navigation
Choose options in
menus, DVR recordings,
guide, settings and
Return to previous guide
page, menu, or channel
Access Apps
Exit from viewing a
recorded program or
delayed DVR mode;
Pause, Skip back, etc.
Increase/decrease
TV volume (see
Programming the Remote
Control on page 3)
Displays recorded and
scheduled events
Numeric Keypad
Choose channel directly
by number
Displays sub-channels
1
Using the Remote Control
Off
Input
page 3)
Zoom
info bar
Back
Apps
Live
Volume
DVR
Period
On
Turns the DVR+, TV, or
an audio device on
Setup
Programs a TV or audio
device
Colored Buttons
Use varies depending
on feature
TV / AUDIO
Use during set-up mode
to program TV and
audio devices
Menu
View main menu for
advanced options and
settings
Exit
Close menu/guide
and return to viewing
Info
Displays channel and
program information
Guide
Displays channel and
program information
Channel/Page
View previous/next
channel or navigate
guide or text pages
Mute
Silence audio output from
the TV (see Programming
the Remote Control on
page 3)
Playback Control
Skip Forward/Skip Back/
Rewind/Play/Fast Forward/
Stop/Pause
Record
Record current program
or guide selection
Audio CC
Displays audio options,
including closed
captioning
Remote | Quick Start Guide
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Channel Master 7500XRC2
Summary of Contents for Channel Master 7500XRC2
- Page 1 Using the Remote Control Turns the DVR+, TV, Turns the DVR+, TV, or or an audio device off an audio device on Setup Input Programs a TV or audio Selects the TV input device (see Programming the Colored Buttons Remote Control on Use varies depending page 3) on feature...
-
Page 2: Using The Program Guide
Watching TV View program/ channel GUIDE information Increase/decrease Change channel sound volume (see Programming the Remote Control on page 3) Skip forward Mute/unmute Fast forward (see Programming the Remote Control on page 3) Play a program Skip backward Record current Rewind program or selected program... -
Page 3: Programming The Remote Control
Programming the Remote Control The remote is capable of controlling the basic functions of most TV’s and Audio Video Receivers. (Volume, Mute, Power, Input) There are two methods to program your remote outlined below. Note: If you wait more than 10 seconds between any step in the programming procedure, the setup will “Time Out”, and you will need to start again from the beginning. -
Page 4: Code Entry
Programming the Remote Control, continued Code Entry Follow this procedure to program the remote with a 5-digit code. Note: Where several codes are listed for a manufacturer, it may be necessary to repeat the sequence below with each code until the correct one is found. To control your TV, press and release the RED button. - Page 5 Programming the Remote Control, continued Troubleshooting Setting the Volume(+)/Volume(-) to adjust audio device Volume as an alternative to TV volume Follow this procedure to program the Volume(+) / Volume(-) buttons to operate your audio device. Note: Before this can be done, you will first need to program your audio device as explained on page 3.
- Page 6 FAQs Why don’t the TV and AUDIO buttons do anything other than setup? The CM7500XRC2 is a mode-less design which eliminates confusion of being on the wrong mode during use. When a TV is programmed, the ON/OFF, Volume(+)/ Volume(-), Mute and Input will be the only buttons that will control functions of the TV. When an audio device is programmed, the ON/OFF buttons will be the only buttons that will control functions of the actual audio device.
