- Page 1 Manual de instrucciones y manual de instalación Manuale dell utente e manuale di installazione Bedienungsanleitung und Installationshandbuch Bruksanvisning och installationsmanual CJ-7600E CJ-7600E 7.0 WIDE TFT LCD COLOR MONITOR MONITEUR COULEUR TFT 7,0 DE LARGE MONITOR ANCHO TFT LCD COLOR DE 7,0 AMPIO MONITOR A COLORI LCD TFT DA 7 7.0 -BREITBILD-TFT-LCD-FARBMONITOR...
-
Page 2: Table Of Contents
CONTENTS １． SAFETY INSTRUCTIONS ....................... 3 ２． BEFORE USE ............................. 5 ３． FEATURES ............................6 ４． CONTENTS ............................6 ５． FUNCTION OF EACH PART ......................7 ６． FUNCTION ..........................8 [1] Power On/Stand-by ........................ 8 [2] Volume control ........................8 [3] Switch input video ......................... -
Page 3: １． Safety Instructions
SAFETY INSTRUCTIONS Please read the Safety Rules carefully before using this product. Following the safety rules pre- vents users from damages related with the misuse of the product. It is very important to follow these safety rules. We state Caution and Warning to clarify any potential risk of damage as- sociated with the misuse of the product. - Page 4 CAUTION ● Disconnect battery before installation. Re-connect once installation is complete. Prevents electric shock or short circuit. ● Do not use for long periods without engine running. It may cause battery to go fl at. ● The rear-view monitor image has the same right-left inversion as your vehicle s rearview mirrors.
-
Page 5: ２. Before Use
２. BEFORE USE Precautions (when you use the monitor) ● Use the product at the temperature range of -10° C 60° C. ● Screen may be a little dark when the product is operated in low temperature areas. Screen will show normal luminosity after a few minutes. -
Page 6: ３. Features
３. FEATURES ◆ 7 Widescreen digital TFT LCD with high resolution and low reflection ◆ All functions are displayed on screen (OSD function) ◆ 7 language display Selection ◆ DC 12V/24V ◆ Automatic illumination sensor ◆ Camra input (2 systems), main/sub-camera operating together ◆... -
Page 7: ５. Function Of Each Part
５. FUNCTION OF EACH PART [Monitor] ① ② ④ ③ ⑤ ⑥ ① DIMMER SENSOR Automatic brightness control sensor ② AV Switch AUX ③ Switch camera inputs / Volume control / Set SUB-MENU ▲ ▼ ④ ENT (VOL) Confi rm button / Volume control setting menu display (press and hold) button ⑤... -
Page 8: ６． Function
６. FUNCTION Power On/Stand-by Press POWER 「 」 button on monitor then the picture of the camera will be shown on the monitor. Volume control ① Press and hold the ENT(VOL) button in the AV or main camera screen to display the set volume. -
Page 9: Switch Signal Input Screen
Switch signal input screen (signal input priority order: main > sub signal) ① When a single signal (main, sub) is entered, the camera image corresponding to this is displayed. If the signal is terminated, the display returns to the previous screen. ※... - Page 10 General 1) Volume control ① Select [Volume] in the [General] menu and press the ENT(VOL) button. ② Press the ▲／▼ buttons to adjust the volume. ※ The volume can be adjusted between 0 and 15. The initial setting is 5. General General Volume...
- Page 11 Color tone ① Select [Brightness], [Tone], [Vividness] and [Dimmer] in the [Color tone] menu with the ▲／▼ buttons and press the ENT(VOL) button. Press the ▲／▼ buttons to adjust the [Brightness], [Tone] and [Vividness]. ② Select [Daytime], [Night], [Auto] and press the ENT(VOL) button to change the [Dimmer] setting. 1) Brightness Color tone Color tone...
- Page 12 In such cases, the display location should be set at the closest marker No. - Distance markers cannot be set if non Clarion cameras are used. Caution - The markers may not indicate the exact position of the bumper, the vehicle s width or the distance to the rear.
- Page 13 3) Marker type (set the marker pattern) ① Select [Marker type] in the [Marker] menu and press the ENT(VOL) button. ② Select [Type 1] to [Type 7] with the ▲／▼ buttons and press the ENT(VOL) button. Marker Type１ Type２ Type３ Marker Type４...
-
Page 14: Settings 9
4) Up/down, Left/Right adjustment (adjust the bumper position of the car) ① Select [Up/down] in the [Marker] menu and press the ENT(VOL) button. ② Adjust the V (vertical movement) value with the ▲／▼ buttons (▲: Up, ▼: Down). (V= −10∼＋10, Default setting: V=0) Marker Ｖ... -
Page 15: ８． Installation
INSTALLATION (U-Bracket) 1. Please ensure that the monitor is installed with enough room for heat to dissipate. Install the monitor stand with enclosed screws as per the picture. 2. Fix the monitor to the monitor stand firmly. Standard Installation Ceiling Installation... -
Page 16: ９. Connections
Hazard off Main trigger (violet/white) Ground ACC (red) ※１ Use Clarion Cameras only. (black) DC12/24V ※２ A camera connecting cable, sold separately, is required for connecting the camera. ■ When the B/U terminal is connected to the car s B/U: •... -
Page 17: １ ０． Troubleshooting
TROUBLESHOOTING Problem Cause Measure No image is displayed. Is camera connected Check the wiring to the camera and the camera properly? connection. Power does not turn on. Is power cable connected Check the wiring. properly? Is a fuse blown out? Replace with a fuse of the same amperage (5A) Color is washed-out. - Page 18 Clarion Co., Ltd. All Rights Reserved. Copyright © 2014: Clarion Co., Ltd. Printed in Korea / Gedruckt in Korea / Stampato nella Corea del Sud / Imprimé en Corée / Impreso en Corea / Tryckt i Korea 2014/08 CJ-7600E...
