Powering Matrox MXO2

You can power MXO2 using an AC outlet via the external power supply, or using a
battery via the Matrox battery power cable. For battery requirements and guidelines,
see your Matrox MXO2 Installation and User Guide.
²Caution Matrox will not be held responsible for damages caused to your MXO2
system or connected hardware resulting from a non-Matrox-approved or faulty battery.
External
power supply
To AC
outlet
Powering Matrox MXO2
Power button
IEC-C13
power cable
(not supplied)
OR
Female 4-pin
XLR cable
(not supplied)
Matrox battery
power cable
(sold separately)
Battery on a
universal battery
adapter
(not supplied)
