SERVICE MANUAL
SERVICE MANUAL

DVD PLAYER

MODEL
STANDBY/ON
DISPLAY
PLAY MODE
ST
ANDBY
POWER
DIMMER
CLEAR
ON
OFF
Black model
MDD1N
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
DV-SP55
TOP MENU
MENU
RETURN
SETUP
120V AC, 60Hz
ON THE
DV-SP55
Ref. No. 3848
122004
ON
STANDBY
OPEN/
CLOSE
REPEAT
A-B
RANDOM
PLAY MODE
1
2
3
DISPLAY
4
5
6
DIMMER
7
8
9
0
CLEAR
TOP MENU
MENU
ENTER
RETURN
SETUP
AUDIO
ANGLE SUBTITLE ZOOM
TV CONTROL
TV/VIDEO
CHANNEL
DIRECT DIGITAL PASS
ON/
STANDBY
VOLUME
DVD PLAYER
DV-SP55
RC-524DV
RC-524DV
