SanDisk CompactFlash Product Manual page 25

Table 4-2 Signal Description (continued)
Signal Name
-CSEL
(PC Card Memory Mode)
-CSEL
(PC Card I/O Mode)
-CSEL
(True IDE Mode)
D15 - D00
(PC Card Memory Mode)
D15 - D00
(PC Card I/O Mode)
D15 - D00
(True IDE Mode)
GND
(PC Card Memory Mode)
GND
(PC Card I/O Mode)
GND
(True IDE Mode)
-INPACK
( PC Card Memory Mode)
-INPACK
( PC Card I/O Mode)
Input Acknowledge
-INPACK
(True IDE Mode)
-IORD
(PC Card Memory Mode)
-IORD
(PC Card I/O Mode)
-IORD
(True IDE Mode)
SanDisk CompactFlash Memory Card Product Manual © 1998 SANDISK CORPORATION
CompactFlash Memory Card Product Manual
Dir. Pin Description
I 39 This signal is not used for this mode.
This signal is not used for this mode.
This internally pulled up signal is used to configure this device
as a Master or a Slave when configured in the True IDE Mode.
When this pin is grounded, this device is configured as a
Master. When the pin is open, this device is configured as a
Slave.
I/O 31, 30, 29, 28, These lines carry the Data, Commands and Status information
27, 49, 48, 47, between the host and the controller. D00 is the LSB of the Even
6, 5, 4, 3, 2, Byte of the Word. D08 is the LSB of the Odd Byte of the Word.
23, 22, 21
This signal is the same as the PC Card Memory Mode signal.
In True IDE Mode, all Task File operations occur in byte mode on
the low order bus D00-D07 while all data transfers are 16 bit
using D00-D15.
-- 1, 50 Ground.
This signal is the same for all modes.
This signal is the same for all modes.
O 43 This signal is not used in this mode.
The Input Acknowledge signal is asserted by the CompactFlash
Card when the card is selected and responding to an I/O read
cycle at the address that is on the address bus. This signal is
used by the host to control the enable of any input data buffers
between the card and the CPU.
In True IDE Mode this output signal is not used and should not
be connected at the host.
I 34 This signal is not used in this mode.
This is an I/O Read strobe generated by the host. This signal
gates I/O data onto the bus from the CompactFlash Card when
the card is configured to use the I/O interface.
In True IDE Mode, this signal has the same function as in PC
Card I/O Mode.
25
