NUMBER WITH OPTION "A" (ANSWER CONFIRMATION):
In order to make the call to the number successful it is necessary to press #; if this is not done the system will call
immediately the same number. In case the user wants to enter programming, he/she has to enter # and then dial the
personal code.
NUMBER WITH OPTION "B" (DIRECT ACCESS TO USER MENU): when the call is answered, after the message
repetition, the dialler switches immediately to the user menu without asking the personal code. By pressing # the ac-
cess will be anticipated.
NUMBER WITH OPTION "C" (RESET OF THE CALL CYCLE): when the call is considered successful, the dialler will
reset automatically the remaining calls.
Important: when this option is activated, it is useful to activate option A as well, to be sure that the entire call
cycle can be reset only by pressing #.
NOTE: the above mentioned options can be entered for each telephone number; at each telephone number
several options can be assigned.
CALLING THE DIALLER
If the answer is enabled, after the set number of rings, the system will accept the incoming calls, by keeping silent.
Enter # and then enter the personal code. If the code is correct the user will be introduced to the user vocal menu.
USER VOCAL MENU
The vocal menu can only be entered by calling the dialler, or when you are called by the dialler; it is not intended to
programme, but for remote operation by users (system check, output activation).
Menu 1 contains the commands to activate outputs (3 outputs): it is possible to enable (in steady or pulsed mode) and
disable a single or more outputs.
Menu 2 allow a user to check the status of the inputs 1, 2, 3 and SYS (enabled or open/ disabled or closed) and of the
outputs (enabled/disabled) in real time: their status are therefore listed by an automatic voice. Input SYS is intended
for real time status monitoring of remote devices, which are remotely switched by using the dialler outputs. It is also
possible to record two messages corresponding to activation or shutdown (example: "alarm unit on", "alarm unit off").
Menu 3 allow a user to connect with a remote system (example: intercom) for two-way telephone communication.
When the command is activated, ring output is activated (for ring simulation) and, simultaneously, the automatic voice
will ask to wait. When the remote system is connected the automatic voice will tell that the connection has been estab-
lished and that the communication can start.
Our products/systems comply with the essential requirements of EEC directives. Installation must be car-
ried out following the local installation norms by qualified personnel.
AMC Elettronica S.r.l. refuses any responsibility when changes or unauthorized repairs are made to the
product/system. It is recommended to test the operation of the alarm product/system at least once a
month. Despite frequent testing and due to, but not limited to, any or all of the following: tampering, elec-
trical or communication disruption or improper use, it is possible for the product/system to fail to prevent
burglary, robbery, fire or otherwise. A properly installed and maintained alarm system can only reduce the
risk that this happens.
Any GSM speech dialler or communicator, not connected to the PSTN standard telephone line, does not
ensure proper communication in case of problems or limitations due to the GSM network.
www.amcelettronica.com
6
Vision 3 Compact
