AMC vision 3 compact User Manual

VISION 3 COMPACT
GSM SPEECH DIALLER

DESCRIPTION

Vision 3 Compact is a GSM communicator, which uses the existing cellular network to provide reliable and
cost effective communication for security systems. When triggered it can send SPEECH and SMS text mes-
sages.
The system gives full remote control of its outputs is possible over a remote touch tone telephone, by using
a vocal menu that allows the user to activate outputs throughout the programming, or by means of SMS
text messages.
The system provides following features:
- 3 Input Zones separately programmable and configurable
- 3 PGM Outputs controllable for remote switching of other devices
- 1 STATUS Input (SYS) to check a remote device's state
- 1 RESET Input for the local reset of alarm
- 1 Output for notification of system error
- 1 Output for ring simulation of entering calls, which can be used for connections with other devices
- 1 LED to signal GSM cellular network signal strength OK
- 1 LED for notification of stand-by operation
- Simulated PSTN line, which allows to call with a normal touch tone telephone or connect an hardwired
communicator
- It is possible to use SMSs to programme the communicator or to turn on one or more outputs; once the
command has been received, an SMS will be sent back to confirm the action
- Possibility to trigger an output by calling the communicator, which will wait for a single ring and will recog-
nize the associated telephone number, from which the call has been performed. Once the output has been
activated the communicator will ring back the calling telephone to confirm activation of the output
- SIM card expiry date automatic check
- Credit exhaustion automatic check
www.amcelettronica.com
USER MANUAL
Vision 3 Compact
