PROGRAMMING BY SMS

Vision Compact 3 can be programmed through SMS messages.
By sending one or more SMS to the dialler you can:
enable/disable open-collector PGM outputs
check the system status

USER OPERATIONS

The user has the option to enable/disable (in pulsed or steady mode) the PGM outputs, to monitor the status
of each input, to check the status (on/off) of external devices, to change the user code, to allow the techni-
cian to enter technical programming in remote mode.

USE OF SMS TEXT MESSAGES

All the messages conveyed to the dialler must have a determined structure. Firstly they must contain a
"declaration of personal code" .
Example: UPWD:111111 User Password
If the message contains one or more values for the parameters, their structure must be the following:
ID[.index] operation [value ]
[ ] contains numerical values that are not always necessary
ID = is the parameter identified by an alphanumeric code (example: UPWD is the parameter User Pass-
word, IN is the Input ). (Look at TAB. 1 for the complete list of IDs)
TPWD
UPWD
LOCK
IN
OUT
STATUS
[.index] = is the number of ID previously mentioned, therefore this is the output, input, telephone ...
number (example: IN.1 = INPUT 1)
Operator = this brings about a certain operation on parameter identified by ID. For the outputs the opera-
tor sets a value to them (see TAB.2)
: means entering, and is used for passwords (example: UPWD:111111)
= means a setting (example: OUT.1=ON switches on output 1)
? is a request of information (example: IN.1? Asks for the input 1 status)
ON Enable output
OFF Disable output
P Enable output in pulse mode
At each SMS text message, the system can answer with different messages as feedback:
OK command carried out
*?* command non recognized
*LOCKED* no user authorization
FAIL not possible to carry out the command (example: there are no privilege for its execution)
ON refers to the enabled status of an output
OFF refers to the disabled status of an output
www.amcelettronica.com
TECHNICAL PASSWORD
USER PASSWORD
SYSTEM UNLOCK
INPUT
OUTPUT
SYSTEM STATUS
TAB.1: IDs
TAB.2: VALUES
4
Vision 3 Compact
