INSTALLING THE BLADE GUARD & LANDING GEAR
If not already installed, install the included blade guards to every corner
and tighten the screws. Make sure the blade guards are secure and snug.
NOTE: Loose blade guards may interfere with propeller movement and
cause a crash. If the drone crashes, double check to make sure the blade
guard is not loose. If it is, re-tighten before flying.
If not already installed, install the included landing gear.
6

CHARGING THE DRONE

1. Push the on/off switch of the drone to OFF and open the battery cover.
2. Pull out the battery wire from the power port.
3. Connect the USB charging cable to the battery wire.
4. Plug the charger into a USB port. The USB will light up while charging
and will turn off once fully charged.
5. Reconnect the battery wire to the power port and close the battery cover.
Charging time: approximately 75 minutes --- Flying time: approximately
7 minutes
*Battery: Li-Po, 7.4V, 350mAh
If you purchased extra batteries, allow the engines to cool between flights in
order to prolong engine life.
