FORK, FORKBAR, AND LOAD BACKREST

Fork
The fork of 7FBMF16 to 30 is the same as that of the previous model. The fork of 7FBMF35 is the same as that
of 7FGJF35. The fork of 7FBMF40 to 50 is a newly adopted one. Refer to the table of "6.2. Fork" about its size.
The standard fork color is black. The orange-colored fork is also prepared as an option.
As the previous model, the option "without fork set" is available for all the mast too.
Width of fork
Model
(mm)
7FBMF16, 18 80
7FBMF20, 25 100
7FBMF30 100
7FBMF35 125
7FBMF40, 45 150
7FBMF50 150
Forkbar & load backrest
Load backrest
The load backrest is the standard equipment of the mast.
The backrest of 7FBMF16 to 30 is the same as that of the previous model. The backrest of 7FBMF35 is the same
as that of 7FGJF35. The backrest of 7FBMF40 to 50 is a newly adopted one, but its structure is the same as that
of 7FBMF16 to 35: Flat steal type.
The option "W/O load backrest" is available for all the mast of 7FBMF series.
7FBMF16 ~ 35 (V, FV, FSV)
Height of 7FBMF16, 18
load
1220 7FBMF20, 25
backrest
(mm)
7FBMF30, 35
Thickness of
fork (mm)
40
40
45
45
50
60
Model 920
—
—
Length of fork (mm)
800 1000 1100
—
—
—
—
—
Length of forkbar (mm)
Outside width of load backrest [+60 mm]
1020 1070
—
—
( : STD,
1200 1400
( : STD,
1170
— —
—
: Available)
1500
—
—
: Available)
1470
—
