i3 i3PROJECTOR Interactive Functions Manual

Hide thumbs Also See for i3PROJECTOR:

Advertisement

Quick Links

Download this manual See also: User Manual
i3PROJECTOR
INTERACTIVE FUNCTIONS MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the i3PROJECTOR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for i3 i3PROJECTOR

Summary of Contents for i3 i3PROJECTOR

  • Page 1 INTERACTIVE FUNCTIONS MANUAL...

  • Page 2: Table Of Contents

    Optical touch control projector packing list ..................i Accessories ..............................ii Install in Windows OS ..........................1 Install in Mac OS ............................20 Install in Linux OS ..........................28 Troubleshooting .............................30...

  • Page 3: Optical Touch Control Projector Packing List

    OPTICAL TOUCH CONTROL PROJECTOR PACKING LIST Accessory check list Please check this list against accessories included with your optical touch control projector. Please call the dealer where you purchased the product for any missing item. 1. Light pen 2. Battery (AAA) i3PROJECTOR Interactive functions manual...

  • Page 4: Accessories

    ACCESSORIES Keys and buttons for the light pen Touch control pen tip Before using the light pen Make sure it is powered on. How to use (your light pen)? Press the touch control pen tip to the screen, signals transmitted from the tip to validate locations with sensors in projector.The touch control pen tip lights up when sending signals.

  • Page 5: Install In Windows Os

    Install the LightPen software System requirements Operating system Microsoft Windows XP (SP2) (32bit)/Vista (32bit)/Windows 7 (32bit/64bit) Intel® Core™ 2 Duo 2.0 GHz or better (dedicated GPU is recommended) Memory 2 GB or more Minimum hard disk space 100 MB i3PROJECTOR Interactive functions manual...
  • Page 6 INSTALL IN WINDOWS OS 2. Software installation 2.1 Driver installation <Install from the USB device> A CD drive is created by connecting the interaction module to a computer through a USB cable (see Figure 1). Enter the windows\Setup.exe folder of the CD drive to install SPDriver. You may execute the launcher.exe program to start the SPDriver directly.
  • Page 7 (1) Click SPDriver and a pop-up window as shown below will display.Click Next to continue. (2) Select the destination folder for installation (a default folder is provided). Click Next to continue. (3) Please wait until the installation process is completed successfully. i3PROJECTOR Interactive functions manual...
  • Page 8 INSTALL IN WINDOWS OS - LIGHTPEN3 2.2 Install the LightPen 3 software Step 1: Insert the Owner's Manual CD into your CD drive. Step 2: Enter the "LightPen Software for Windows" folder found on your CD. Step 3: Double click the Setup.exe file name and a pop-up window as shown below will display. Step 4: (1) Click LightPen3 and a pop-up window as shown below will display.Click Next to continue.
  • Page 9 (2) Select the destination folder for installation (a default folder is provided). Click Next to continue. (3) Click Install after validating the installation data, continue the installation process. (4) Please wait until the installation process is completed successfully. i3PROJECTOR Interactive functions manual...
  • Page 10 INSTALL IN WINDOWS OS - LIGHTPEN3 3. Initialize the optical touch control function 3.1 Once the SPDriver is installed, run it by steps Start/All Programs/LightPen/SPDriver/ SPDriver, then connect your projector and a PC with a USB cable. Your system may look like the Figure shown below. (Windows 7/VISTA) (Win XP) 3.2 Click the...
  • Page 11 * Select "About" to show the software version information. (1) Select Calibration to execute the calibration procedure The system saves calibration data after the four calibration points are touched. Please wait while system is saving data. i3PROJECTOR Interactive functions manual...
  • Page 12 INSTALL IN WINDOWS OS - LIGHTPEN3 (2) Auto calibration You may select Auto Calibration to calibrate your product as prompted by the screens shown in Figure 3. DO NOT block images shown in the calibration screen while auto calibration is running. Figure 3 Figure 4 3.4 Calibration completed successfully.
  • Page 13 After the LightPen3 program is installed and "Start/All Programs/LightPen/LightPen3" executed, a toolbar will display on the right hand side of your screen (see figure). * Press LightPen icon and select "About" to show the software version information. i3PROJECTOR Interactive functions manual...
  • Page 14 TOOLBAR - LIGHTPEN3 4.2 Main functions Icons Names Descriptions Mouse Mouse functions. Red brush pen Red brush pen. Green brush pen Green brush pen. Blue brush pen Blue brush pen. Mark pen Translucent brush pen. To draw circles, rectangles, isosceles triangles, Drawing tools and lines.
  • Page 15 Click to select the desired drawing mode for hand drawing. Icons Descriptions Both parties make drawings with the same tool in full screen mode. Both parties make drawings with the same or different tools in equally divided screen mode. i3PROJECTOR Interactive functions manual...
  • Page 16 INSTALL IN WINDOWS OS - LIGHTPEN3 (2.1) Full Screen Dual Pens Both parties make drawings with the same tool in full screen mode. Divided Screen Dual Pen Both parties make drawings with the same or different tools in equally divided screen mode.
  • Page 17 * Only one eraser is available in full screen dual pen at the same time. Clear all Erase all strokes made by brush pen. Import background Load custom background. Save contents and hand drawings of current Save page. Exit Exit dual pen mode. i3PROJECTOR Interactive functions manual...
  • Page 18 INSTALL IN WINDOWS OS - LIGHTPEN3 Whiteboard mode Click , the screen will change to whiteboard background and the two functions on the tool bar would change to Import Background and Import Whiteboard. i. Click and the selection window will display for you to import desired pictures as background.
  • Page 19 You can use the light pen as a mouse in mouse mode. Pressing the light pen tip functions like clicking the mouse key. Pressing and holding the light pen for 2-3 seconds functions the same as right clicking your mouse. See Figure below. i3PROJECTOR Interactive functions manual...
  • Page 20 INSTALL IN WINDOWS OS - LIGHTPEN3 4.5 Change toolbar direction Point the light pen at any place under the projection image and press the pen tip to switch vertical toolbar into horizontal one. Point the light pen to the left or right of the projection image and press the pen tip to switch horizontal toolbar into vertical one.
  • Page 21 Point the light pen to the bottom away from the screen and press the pen tip to display or hide the toolbar for horizontal toolbar. 4.7 How to execute LightPen program again You may execute the LightPen3 program again by running the steps of "Start/All Programs/LightPen/ LightPen3". i3PROJECTOR Interactive functions manual...
  • Page 22 INSTALL IN WINDOWS OS - LIGHTPEN3 5. PowerPoint toolbar LightPen3 features PowerPoint toolbar supporting Microsoft Office 2003 or later versions. The PowerPoint toolbar will display at the right hand side of your screen if you open the PowerPoint Tool Setup from the toolbar and display the PowerPoint file in PowerPoint's Playback mode. The PowerPoint toolbar closed automatically after exiting Playback mode.
  • Page 23 Change position of PowerPoint toolbar Switch to mouse mode Switch to the right key of your mouse Switch to red brush pen Erase Erase all Back to previous page Go to next page. Select page Close slide playback i3PROJECTOR Interactive functions manual...

  • Page 24: Install In Mac Os

    INSTALL IN MAC OS The LightPen3 software features an optical touch control function 1. System requirements For normal optical touch control operation, please make sure the following system requirements are met. Install your LightPen3 software System requirements Operating system Mac OS X v10.5 or above Intel processor Memory 2 GB or more...
  • Page 25 * Select "About..." to show the software version information. 3.3 Select "Calibration" to execute the calibration procedure. 3.4 The system saves calibration data after touching the four calibration points. i3PROJECTOR Interactive functions manual...
  • Page 26 INSTALL IN MAC OS - LIGHTPEN3 4. Toolbar 4.1 LightPen3 toolbar After the LightPen3 program is installed and executed, a toolbar displays on the right hand side of your screen. * Select "About LightPen3" to show the software version information.
  • Page 27 Save contents and hand drawings of current page. Whiteboard mode Switch to whiteboard background mode. Previous page Back to previous page. Next Go to next page. Editor Handwriting editor. On screen keypad Open the on screen keypad. Exit Exit application software. i3PROJECTOR Interactive functions manual...
  • Page 28 INSTALL IN MAC OS - LIGHTPEN3 4.3 Sub-functions Drawing tools Click the main menu and a popup sub-menu from the main menu is shown as below. Click to select the desired drawing tool for hand drawing. Whiteboard mode Click , the main menu will change to white background with the two functions Import Background and Import Whiteboard.
  • Page 29 Click to select the desired edit function. Icons Descriptions Select what you have drawn as an object to enlarge, decrease, rotate, delete or move it. Print current screen. Undo last action. Cancel undoing last action. i3PROJECTOR Interactive functions manual...
  • Page 30 INSTALL IN MAC OS - LIGHTPEN3 4.4 Switch the mouse or brush pen mode You can switch between mouse or brush pen modes by pointing the pen tip above or below the projected image and pressing the pen tip. Icons in toolbar change to when switching to mouse mode;...
  • Page 31 4.5 Change toolbar position There is a quick method to change position visibility of the toolbar. Press the light pen tip at the left or right side beyond the screen, then you can change position visibility of the toolbar. i3PROJECTOR Interactive functions manual...

  • Page 32: Install In Linux Os

    INSTALL IN LINUX OS -SPDRIVER The SPDriver software features an optical touch control function 1. System requirements For normal optical touch control operation, please make sure the following system requirements are met. Install SPDriver System requirements Operating system Linux OS Ubuntu 10.04, Debian 5.05, Suse 11.3 Intel®...
  • Page 33 * Select "About" to show the software version information. 3.3 Select "Calibration" to execute the calibration procedure. (There is no white background while calibrating.) 3.4 The system saves calibration data after touching the four calibration points. i3PROJECTOR Interactive functions manual...

  • Page 34: Troubleshooting

    TROUBLESHOOTING Q1: Why does the message "The LightPen program is not found" appear? A: It may be caused by the following: (1) Your computer and projector are not properly connected. Please make sure the USB cable is properly inserted in both your computer and projector. (1-1) Insert the USB cable again if you see the screen as shown below.
  • Page 35 Please keep the sensors of your projector away from direct ambient lights. 6: Since SP driver is resident in the PC, the driver displayed is an invalid one when connects to the SP module again. i3PROJECTOR Interactive functions manual...
  • Page 36 TROUBLESHOOTING Q6: Why does SPDriver have no response from virtual keyboard function when it set as <Mouse mode> on Windows Vista/Windows 7 operating system? A: This function of SPDriver may be restricted by the default setting of <User Account Control, UAC> on the Windows operating system.
  • Page 37 TROUBLESHOOTING (4) Restart the computer to complete the process. i3PROJECTOR Interactive functions manual...
