- Page 1 Operation Manual 4Bank DMX Part No. 3100070 Rev B 02-10-2016...
- Page 2 Kino 41K Mount w/ 3/8” Pin (10mm) X16-25 4Bank Extension, 25ft BAL-457-120U 4Bank DMX Ballast, Univ 120U BAL-457-230U 4Bank DMX Ballast, Univ 230U Each 4Bank DMX System consists of: 1 Fixture 1 Mounting Plate 1 Extension Cable 1 4Bank DMX Ballast True Match Lamps ®...
- Page 3 KIT-2GF-X120U Gaffer DMX Kit, Univ 120U KIT-2GF-X230U Gaffer DMX Kit, Univ 230U Kit Contents: 2 4ft 4Bank Fixture 2 4Bank DMX Ballast 2 MTP-BC41 Mount w/ Baby Receiver (16mm) 2 Extension, 25ft Gaffer DMX Kit 2 Lamp Case 1 Gaffer Ship Case...
- Page 4 Fixture Assembly The 4Bank fixture is comprised of a removable Louver, Reflector and Lamp Harness. The Louver and Reflector are held in place with Velcro fasteners. The Lamp Harness is secured by means of a ¼ turn fastener and two clips. To Release the Lamp Harness Remove the harness from 2 clips located under the reflector.
- Page 5 Inserting Lamps Locking Lamp Connector: Depress both tabs on lamp connector and apply to lamp pins. Match the Harness color-codes at each end of the lamp. Push lamps into the fixture’s Lamp Holder Clips. Gelling the Fixture Restricting the airflow around the lamps can cause the lamp to operate hotter.
-
Page 6: Mounting The Fixture
Mounting the Fixture The standard mount (MTP-KF41) comes with a 3/8” Lollipop that clamps into a grip head. The ball and socket mount allows the fixture to be oriented in a broad range of angles. Align the center pin of the mounting plate to the center hole on the mating plate. -
Page 7: Extension Cable
Other Fixture Mounting Options The grommet holes along the edge of the fixture are designed to allow the fixture to be screwed onto set walls. Extension Cable To insert the cable, position the logo up to align the key ways on the extension cable with the circular receptacle on the ballast. - Page 8 Ballast Operation WARNING! 1) ALWAYS TURN OFF THE BALLAST BEFORE connecting or disconnecting Lamps, Harnesses or Extension Cables. 2) Use only with Sine wave inverters. Do not operate on SCR dimmers. 3) If powering the ballasts through a Dimmer Pack, set the Dimmer to Non-Dim mode.
- Page 9 4Bank DMX Control Panel A) Circular Output Connector: Provides electrical power to the lamp head with the use of a 4Bank extension cable. B) DMX-In & DMX-Out: DMX-In receives DMX signals from Dimmer Board. DMX-Out relays DMX signals through other Fixtures or Instruments.
-
Page 10: Manual Operation
Manual Operation The Ballast operates remote from the fixture. Connect the Extension cable to the Ballast and the Lamp Harness. After the lamps are properly installed, the Ballast can be turned on. Each switch controls one lamp. The color bands on the lamp harness correspond to the switches as illustrated. White Black White... -
Page 11: Dmx Operation
The dimmer board/light console should have its channel set to LINEAR light output response. (LINEAR response is the default setting on most dimmer boards.) For example: If the 4Bank DMX base address is set at 001, the configuration below will provide 4 lamps individually addressable through DMX 512. - Page 12 4Bank DMX ballasts can be jumpered using the IN and OUT ports. As many as 100 ballasts can be jumpered on one chain as long as the DMX cable run remains under 1000 feet or 40 x 25ft DMX cables.
-
Page 13: Accessories And Parts
Accessories and Parts DFS-4804 4ft 4Bank Flozier, Full DFS-4804-H 4ft 4Bank Flozier, Half DFS-D4 2ft 4Bank Flozier, Full DFS-D4-H 2ft 4Bank Flozier, Half FIX-484 4ft 4Bank Fixture Shell FIX-244 2ft 4Bank Fixture Shell HAR-4804 4ft 4Bank Harness HAR-2404 2ft 4Bank Harness HAR-4802 4ft Double Harness HAR-2402... - Page 14 MTP-BC41 Kino 41K Mount w/ Baby Rcvr Curve (16mm) MTP-BF41S Kino 41K Mount w/ Baby Rcvr Short (16mm) MTP-L Kino 41 Lollipop w/ 3/8” Pin (10mm) MTP-LBC Kino 41 Lollipop w/ Baby Rcvr Curve (16mm) MTP-LBS Kino 41 Lollipop w/ Baby Rcvr Short (16mm) REF-4804 4ft 4Bank Reflector...
- Page 15 Cases KAS-C46 KAS-54L KAS-KFC BAG-201 Part Number Description Dimensions Weight Holds (Empty) BAG-201 2ft 4Bank Soft Case 28.5 x 7.5 x 20” 3.5 lb 2ft 4Bank System (1), (72.5 x 19 x 51cm) (2kg) Lamp Case BAG-401 4ft 4Bank Soft Case 55 x 8 x 19.5”...
- Page 16 This product is made of recyclable materials and should be disposed of in accordance with local and state regulations. Kino Flo, Inc. 2840 N. Hollywood Way, Burbank, CA 91505, USA Tel: 818 767-6528 website: www.kinoflo.com...
