- Page 1 PELICAN WATER TECHNOLOGIES, INC. PSE1800/PSE2000 Carbon Filtration and Softening System Complete Owners Manual...
-
Page 3: Table Of Contents
T able of Contents I N T R O D U C T I O N C H A P T E R Product Certifications Natursoft Tank Install 11-12 Product Operation and Specifications Natursoft Tank Start Up C H A P T E R C H A P T E R Parts &... -
Page 4: Product Certifications
Product Certifications Pelican NaturSoft NS3– WQA Gold Seal Certified to NSF/ANSI Standard 42 for Material Safety and Structural Integrity only. Pelican 5 Micron Pre-Filter System – NSF/ANSI Certified Standard 42 for material and structural integrity requirements. Carbon Filtration Media – NSF/ANSI Certified Standard 42 Clack V3007-xx Bypass Fittings –... -
Page 5: Product Operation And Specifications
PSE1800 8-10 GPM PSE2000 12-16 GPM Rated Capacity (Gallons): Holds9.1 Gallons in the PSE1800 Tanks Holds 16.7 Gallons in PSE2000 Tanks Minimum Working Pressure (PSIG): 25 PSI Operating Temperatures (°F): 36°F – 12 0°F pH Range: 7-11 pH Water Conditions for NaturSoft Operation: ... -
Page 6: Parts & Pre-Installation Checklist
Chapter Parts & Pre-Installation Checklist Open the parts bags marked “WF-SP-PARTS” and “WF-CF-PARTS” and use the checklist below to confirm receipt of all parts. Part Description Rec. V3007 WS1 Fitting 1” PVC Male NPT Elbow Assembly V3007-01 WS1 Fitting ¾” to 1” PVC Solvent 90 Assembly V3007-03 WS1 Fitting ¾”... -
Page 7: Carbon Tank Setup & Carbon Soak
Carbon Tank Setup & Carbon Soak You will need the following tools/parts for this section: 1 x PVC-FE 1 x V3007 1 x HOSE-B 1 x Bypass 1 x PVC-RED Garden Hose 1. Grab 1 x PVC-FE, 1 x HOSE-B, and 1 x PVC-RED and assemble the carbon soak/carbon wash assembly as illustrated below. - Page 8 3. Take 1 x Assembled 1 x Bypass and the above assembled carbon V3007, wash assembly Attach the bypass to the head of the carbon tank, by inserting the bypass valve into the head with the un-threaded end pushing into the tank.
-
Page 9: Pre-Filter Installation
Pre-Filter Installation Includes: 1. 1ea. 10” blue pre-filter housing 2. 1ea. 5 micron pre-filter 3. 1ea. mounting bracket with mounting screws 4. 1ea. shut off valve 5. 1ea. pre-filter wrench for changing the pre-filters Sequence for plumbing from incoming water supply before connecting to the filter tank(s): 1. -
Page 10: Carbon Wash
Chapter Carbon Tank Carbon Wash You will need the following tools/parts for this section: Carbon Tank 1 x Bypass Valve 1 x Bypass Fitting Set (determine based on pipe type and size) 1 x Assembled V3007, Carbon Wash Assembly For the installation of the carbon filter you will be re-using the assembled carbon wash assemblies used in Chapter 1. -
Page 11: Carbon Tank Install
1. Attach the assembled 90-degree threaded elbow with the backwashing assembly attached, to the up-flow side of the bypass valve. 2. Now connect your garden hose to the backwashing assembly now attached to the bypass valve. 3. Turn water on slowly and increase water pressure a little at a time. Run the water through the up-flow inlet side for 15-30 minutes or until the water runs clear. - Page 12 1. Bypass valve installation – The bypass valve comes complete and ready to install with o-rings, split rings and black quick connectors. To install simply press the bypass valve onto the head of the tank and hand tighten both black quick connectors. 2.
-
Page 13: Natursoft Tank Install
Chapter NaturSoft Tank Install You will need the following tools/parts for this section: NaturSoft Tank 1 x Bypass Valve 1 x Bypass Fitting Set (determine based on pipe type and size) Note: After installation the arrows on the bypass valve may be pointing in different direction than the diagram shows, if this is the case simply pull up on the red arrows to take them off and turn them around. -
Page 14: Natursoft Tank Start Up
1. Bypass valve installation – The bypass valve comes complete and ready to install with o-rings, split rings and black quick connectors. To install simply press the bypass valve onto the head of the tank and hand tighten both black quick connectors. 2. -
Page 15: Troubleshooting & Helpful Hints
Chapter Carbon Tank Troubleshooting If you notice the pressure dropping off during the carbon wash turn the water off and let the tank sit about 30 minutes to allow the carbon to settle down off of the basket inside the tank. If the pressure drops off again, let the system stand for 72 hours. - Page 16 NaturSoft Helpful Hints/What to Expect What to expect if you have an existing home without a prior softener Immediately after the installation you will experience all of the benefits listed above. Depending on the amount and type of scale deposits present in the plumbing of your home and the type of plumbing materials used, you may or may not observe the following within one to four weeks following the installation of the new system.
- Page 17 chemically softened water the remaining spotting consists of minerals not salt, and is more visible as a result. Yet, the cleaning of this type of spotting approaches the ease of cleaning up the salt haze when compared to untreated water. (You can conduct your own test by putting the NaturSoft™...
- Page 18 Tips for Cleaning Hot-Water Heaters when using a NaturSoft System Cleaning and restoring the plumbing system is a major benefit of the NaturSoft product. It is a benefit that no installation of a traditional water softener would provide. At the same time we can agree that the cleaning process represents impairment to the enjoyment of the improved water quality.
-
Page 19: Warranty Information
Pelican, this may void your warranty. Please contact your authorized Pelican dealer for further details. Pelican Water Technologies or its Authorized Dealers will not be liable for any circumstance for consequential or incidental damages. In any dispute between the... -
Page 21: Warranty Registration Form
Pelican™ Warranty Registration Form Date Item(s) were Received: ____________Order ID#: ___________________ Model: ___________ Name: ______________________ Address: _______________________________________________ City: _______________ State: __________ Zip: ___________ Send To: Pelican Water Technologies 3121 Suite D Opportunity Court South Daytona, FL 32119 Phone: 1-(866) 767-6401 Plumbers Information (optional) We like to recommend good plumbers through out the USA and if you were happy with your installer please give us their information so we can pass it on as a courtesy.
