  • Page 1 PORTABLE 7" LCD MONITOR AND DVD PLAYER VBP700 VBP700 VBP700 VBP700 VBP700 IN A BAG...
  • Page 2 Notice: This Product incorporates copyright protection technology that is pro- tected by method claims of certain U.S. Patents and other intellectual property rights owned by Macrovision Corporation and other rights own- ers. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited view- ing uses only unless otherwise authorized by Macrovision Corporation.
  • Page 3 A. Introduction Thank you for selecting the VBP700 portable DVD player in a bag. The main features include a 7" Screen (16:9 Aspect Ratio) Liquid Crystal Display (LCD) monitor and a DVD player. The unit applies the latest state of the art electronics and is designed for use in ho- tels, offices home or vehicle.
  • Page 4 Also refer to the instructions supplied with the discs. C. Contents 1. 1 x 7’’ LCD Monitor & DVD Player Combo 2. 1 x AC to DC Adapter 3. 1 x Remote Control w/Battery 4.
  • Page 5 2. Powering the system in a car Plug one end of the cigarette lighter adapter into the DC 9V jack on the unit, then plug the other end into the cigarette lighter socket. 3. Powering the system with rechargeable Battery Please refer to K.
  • Page 6 1.Installing the System onto the seat back in a car (Refer to Figure 2) Seat Standoff 1). Take one of the supplied straps from the carrier bag. Connect the latch to one of the upper metal rings on the mounting bag. Connect the “S”...
  • Page 7 2. Installing the system between the driver/passenger seat (Refer to Figure 3) 1). Take one strap and connect the latch to the upper metal ring on the left side of the bag. Attach the “S” hook to the same ring after looping the strap around the headrest of the driver’s seat.
  • Page 8 F. Controls, Indicators, and Connectors 1. Unit View (Refer to Figure 4) 1) Menu 2) UP Button 3) LEFT Button 4) DOWN Button 5) OK Button 6) RIGHT Button 7) Open Button 8) Previous Button 9) Stop Button 10) Next Button 11) Play Button 12) Pause 13) Screen Mode (WIDE) Button...
  • Page 9: Numeric Keypad

    2. Remote Control View (Refer to Figure 5) 1) DISPLAY Button 2) ANGLE Button 3) SUBTITLE Button 4) AUDIO Button 5) ZOOM Button 6) UP/DOWN/LEFT/RIGHT/ ENTER Biotins 7) RETURN Button 8) A-B Button 9) FORWARD Button 10) REVERSE Button 11) SLOW Button 12) STOP Button 13) NUMERIC KEYPAD 14) SETUP Button...
  • Page 10 DVD player’s volume. e. To stop playing a disc, press STOP. f. To turn off the DVD player, slide POWER ON/OFF to OFF. The DVD player’s POWER indicator turns off. g. To remove the disc, open the disc tray, then you will see a...
  • Page 11 H. SETUP Press ‘SETUP’ to display the Main screen o f the SETUP Menu on the screen. Press ‘SETUP’ again to exit the SETUP Menu and the unit will resume its last playback mode. 1) Press ‘SETUP’, the ‘General Setup’ page will display on screen. a).Select ‘TV Type’...
  • Page 12 TV DISPLAY Screen Display * Normal/PS: When the player is connected to a normal TV, and a wide picture is shown on the full screen. * Normal/LB: When the player is connected to a normal TV, and a wide picture is shown on the screen with a black strip at both the top and bottom of the screen.
  • Page 13 Select ‘SCREEN SAVER’ using the DOWN button. *On: enables screen saver *Off: disables screen saver (off) *NOTE: The DVD player will enter the Screen Saver mode after approximately five minutes if the same image remains on the screen. e). Select “ Last Memory” by using the DOWN button.
  • Page 14 a).Select “Brightness” by using the UP or DOWN buttons ,then press Enter you can change the brightness by pressing the LEFT or RIGHT buttons. To exit Brightness setting, press Enter again to return the main Menu. BRIGHTNESS Screen Display b).Select “Contrast” by using the UP or DOWN buttons,then press “Enter”...
  • Page 15 d).Select “Saturation “ by using the UP or DOWN buttons, then press “Enter” you can adjust the Saturation by pressing the LEFT or RIGHT buttons. SATURATION (Color)Screen Display To exit “Saturation” setting, press “Enter” again to return to the main Menu. 3).Select “Password”...
  • Page 16 PASSWORD VERIFY Input Screen Display NOTE: The Default Password is 3308. This password is always effective even after you have selected your own password and changed it. To avoid the possibility of others using the default password to set the parental level and change the password, you can record this default password in another area and delete it from this manual.
  • Page 17 Preference Subtitle Language c. Select ‘Disc Menu’ using the DOWN button, then press RIGHT to enter the submenu. Select the Disc Menu Language you desire using the UP or DOWN buttons , then press Enter to confirm the setting. Press LEFT to return. Preference Disc Menu LANGUAG Note: Language and subtitle selection is only available for discs that are recorded in the above listed languages.
  • Page 18 Select the parental level you desire using the UP or DOWN but- tons for discs with lock-out function or multiple rating levels. These are listed from the lowest level (1 Kid Safe) to the highest level (Adult). Enter a 4 digit password, then press ‘ENTER’ to confirm the parental level setting.
  • Page 19 I. Playing DVD 1. Basic Operation POWER OPEN PLAY SLOW PAUSE STOP NEXT PREVIOUS FORWARD REVERSE LEFT/RIGHT/UP/DOWN ENTER NUMBERS RETURN MENU REPEAT DISPLAY ANGLE SUBTITLE AUDIO ZOOM SETUP Turn the unit on/off Remove/load the disc Start Play/Execute item or setting Play at 1/2, 1/4, 1/8 or 1/16 times speed Still Picture (1 time) Stop at the present playing point /...
  • Page 20 2. MENU A DVD is divided into sections called titles and chapters. When you play a DVD, a root menu of the disc will appear on the screen of your TV or Monitor. The contents of the menu vary from disc to disc. Press MENU during playback to display the menu.
  • Page 21 c. Press ‘DISPLAY’ a 3rd time to display the Elapsed Time for the chapter. The heading will disappear automatically in 3 seconds. Chapter Elapsed Time Screen Display d. Press ‘DISPLAY’ a 4th time to display the Remaining Time for the chapter.
  • Page 22 Angle Screen Display 3. SUBTITLE During disc playback press ‘SUBTITLE’ to select the subtitle lan- guage you desire*, with the current Subtitle Language Number (1) and the total number of subtitle languages (2) displayed. If there are multiple languages press ‘SUBTITLE’ again to select another subtitle language.
  • Page 23 4. AUDIO During playback press ‘AUDIO’ to select the audio language you desire*, with the current audio channel number (1) and the total number of audio channels (2) displayed. Press ‘AUDIO’ again to select another audio language. The audio display will disappear automatically if the ‘AUDIO’...
  • Page 24 6. A-B REPEAT a. During playback press first time ‘A-B’ to set the Starting Point A. A-B Repeat Starting Point Screen Display b. Press ‘A-B’ second time to set the Ending Point B and the layer will repeatedly play the part between Point A and Point B. A-B Repeat Ending Point Screen Display c.
  • Page 25 7. REPEAT a. During playback press ‘REPEAT’ once to repeatedly play the cur- rent chapter. Chapter Repeat ON Screen Display b.During playback press ‘REPEAT’ again to repeatedly play the current title. Title Repeat ON Screen Display c. During playback press ‘REPEAT’ a 3rd time to repeat all Chapters and Titles.
  • Page 26: Playing Audio Cds

    d. Press “REPEAT” a 4th time, to resume normal play. 4. PLAYING AUDIO CDS When playing an audio CD press the DISPLAY button on the remote to view time information. The options below show you what information is available using this function. a.
  • Page 27: Using The Repeat Feature

    c. Press ‘DISPLAY’ a 2nd time and ‘Total Elapsed’ appears along with the current track playing and the total time that the CD has been playing. TOTAL ELAPSED Screen Display d. Press ‘DISPLAY’ a 3rd time and ‘Total Remain’ appears along with the current track playing and the amount of time remaining on the TOTAL REMAIN Screen Display e.
  • Page 28: Playing Mp3 Discs

    REPEAT ONE (repeat playback of a song) REPEAT FOLDER (repeat playback of a specific folder) Insert an MP3 CD, the DVD player will initialize the disc and the directory (folder) will be shown on the TV screen. When an MP3 disc is inserted into the unit, the menu screen appears automatically.
  • Page 29 Use the ( NEXT ) button to move to the next song. Press the (PREVIOUS) button to move to the beginning of the previous song. Using The Repeat Feature The default mode for the Repeat feature is OFF. Pressing REPEAT consecutively changes the repeat options: •...
  • Page 30 6. Playing JPEG file 1) Load the JPEG Disc into tray. 2) Select JPEG file by pressing “UP/DOWN” button. 3) You can open the JPEG file by pressing “Play” or “ENTER”. 4) Pressing the “LEFT Key“ will rotate the picture90 degrees counterclocckwise.
  • Page 31 k. Press “display” 11th time, “COMPRESS TO CENTER H” will display on the screen, the picture will refresh from top and bot- tom to center. l. Press “display” 12th time, “COMPRESS TO CENTER V” will display on the screen, the picture will refresh from right and left to center.
  • Page 32 7. Connecting to a TV or another monitor ( Refer to Figure 6) You can also connect the DVD player to a TV to enjoy high quality stereo sound and picture on another monitor. 1. Connect one end of the audio/video cable’s black (1/8”...
  • Page 33 Please fully charge the battery prior to first use. NOTE: When the DVD player is used with the battery as a power source, ensure that the battery has been charged for at least eight hours prior to connecting it to the DVD player.
  • Page 34 The lock position is indicated by a click. The unit will fit snugly to the player. 5. Push the battery plug into the DVD player DC input jack. Figure 8. Installing the DVD Player Battery C) or exceed 95...
  • Page 35 NOTE: Plugging headset into Headphone Jack 1 disables external speakers. 2.Wireless headphones The VBP700 includes a built in infrared transmitter* for use with wire- less headphones (PN IRHSCS). Turning the Wireless Headphone switch ON will activate the internal IR receiver and the volume can then be adjusted separately with the controls on each headset.
  • Page 36 AUDIO L/R INPUT This power adapter has a built-in wireless FM Modulator. The FM modu- lator is designed to transmit the audio from your DVD player to your vehicle radio. The channel select switch is used to select the modulator frequency (88.1MHz, 88.3MHZ, 88.5MHz and 88.7MHz).
  • Page 37: 90-Day Limited Warranty

    AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 90 days from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor.
  • Page 38 © 2004 Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, N.Y. 11788 128-7003...
