SmartDial Wireless User Manual -en_GB Document in original language 08-07-2014 A003... -
Page 2: Table Of Contents
Contents 1 Declaration of Conformity ....... 1 2 Product description ........3 3 Guidelines for installation ....... 3 4 Operation..........4 5 Interface Description ........5 5.1 Display symbols ........7 5.2 Power-up screen........13 5.3 Binding screen ........15 5.4 Default screen........ -
Page 3: Declaration Of Conformity
SE-739 30 Skinnskatteberg SWEDEN Office: +46 222 440 00 Fax: +46 222 440 99 www.systemair.com hereby confirms that SmartDial, CO2 sensor, Humidity sensor, Input module and RS485 Gateway comply with all applicable requirements in the Directive 1999/5/EC. EN 61000-6-3 2007: Emission standard, residential, commercial and light industry. - Page 4 EN 60730-1: 2007: Safety requirements for automatic controls in household and similar use. The units will meet the requirements of the WEEE and ROHS directives. The complete technical documentation is available. Skinnskatteberg, 02-07-2014 Mats Sándor Technical Director SmartDial User Manual Systemair AB...
-
Page 5: Product Description
2 Product description SmartDial makes it possible to wirelessly set the temperature and fan speed on the Systemair air handling unit. It is also possible to see alarms reported by the air handling unit. SmartDial, together with up to nine other wireless modules are wirelessly connected to a gateway. -
Page 6: Operation
4 Operation The Systemair air handling unit can operate in one of the following 5 modes: Mode Function The fans in the air handling unit are stopped. Away Low energy support control is activated. Auto The fans are working according to values preset in the air handling unit. -
Page 7: Interface Description
5 Interface Description Fig. 1 Interface description SmartDial User Manual Systemair AB... - Page 8 Activates DI5 in the main controller in button the air handling unit (Extended/Forced running). The corresponding icon at the top of the display is visible when active. To adjust the fan speed, see the unit’s panel and follow it’s instructions. SmartDial User Manual Systemair AB...
-
Page 9: Display Symbols
Shows the currently set temperature. Confirm the setting with the “confirm button”. Alarm Visible if the air handling unit reports an alarm, if there is an error in the appliance or if the bind procedure is not successful. SmartDial User Manual Systemair AB... - Page 10 Description Explanation Symbol Battery The battery symbol is visible if battery level is low, not visible otherwise. Broken sensor Invalid temperature value transmitted. or short circuit. SmartDial User Manual Systemair AB...
- Page 11 B. Low fan speed: Can be used when leaving the building for a longer period. C. Normal fan speed: Will give required air change under normal conditions. D. High fan speed: To increase the airflow if necessary. SmartDial User Manual Systemair AB...
- Page 12 Fan speed symbol D. Wireless Com- The Wireless Communication Fault munication symbol is visible if the communication Fault with the gateway is lost, not visible otherwise (Communication lost for more than 60 minutes). SmartDial User Manual Systemair AB...
- Page 13 (new) mode is received from the main controller in the air handling unit. The icon is flashing when the mode is changed and the new mode is not yet confirmed by the main controller in the air handling unit. SmartDial User Manual Systemair AB...
- Page 14 The icon is flashing when the mode is changed and the new mode is not yet confirmed by the main controller in the air handling unit. Cancel Cancel symbol Confirm Confirm symbol SmartDial User Manual Systemair AB...
-
Page 15: Power-Up Screen
5.2 Power-up screen After power-up, all icons will be lit for two seconds. Fig. 2 Power-up screen SmartDial User Manual Systemair AB... - Page 16 After two seconds the software version will be shown. If SmartDial is not bound to the gateway after 4 seconds, the binding screen (figure 3) will be shown. If SmartDial is bound to the gateway after 4 seconds, the default screen (figure 4) will be shown.
-
Page 17: Binding Screen
5.3 Binding screen Fig. 3 Binding screen If SmartDial is not bound to the gateway after 4 seconds, the binding screen (figure 3) will be shown. In binding mode, SmartDial contacts the gateway and requests connection. Note: Binding mode must first be activated on the gateway. See RS485 Gateway User Manual for more information. - Page 18 To initiate the bind procedure, press the confirm button (6). When the bind is successful the default screen (figure 4) is shown. The Cancel button (3) is only active when SmartDial is already bound. When active and pressed the default screen (figure 4) is shown.
-
Page 19: Default Screen
In the rare case that the temperature cannot be measured (product failure), two dashes are shown. The actual fan speed is always shown. The 4 icons above the buttons are visible. icon is shown if the system is in auto mode. SmartDial User Manual Systemair AB... - Page 20 10 seconds, the binding screen is shown. Note: Normally the binding screen is automatically shown after initial power-up. So this is only needed in rare cases where you want to connect the device to another system. SmartDial User Manual Systemair AB...
-
Page 21: Setting Temperature And Fan Speed
5.5 Setting Temperature and Fan speed SmartDial User Manual Systemair AB... - Page 22 Square The square is moving in the settings by turning the dial clockwise or counterclockwise. When turning the dial, the square appears and you can choose either fan speed settings or temperature settings. SmartDial User Manual Systemair AB...
- Page 23 Press the cancel button (3) to back out to the starting point (no square active) at any time. If there is no activity for 30 seconds it will automatically back out to the starting point. SmartDial User Manual Systemair AB...
-
Page 24: Change Batteries
(1) and flip out the dial. 2. Use a screwdriver or similar to push down the lock (2) and flip out the unit (3). 3. Change the batteries. 4. Remount in opposite order. SmartDial User Manual Systemair AB... -
Page 25: Troubleshooting
7 Troubleshooting Indication Probable cause and action SmartDial is not working Check if batteries are depleted or inserted incorrectly RF binding and/or Check if remote modules too communication problems close (< 1 m) or too far away (> 30 m) from the gateway... - Page 26 Systemair AB reserves the right to make changes and improvements to the contents of this manual without prior notice. Systemair AB Industrivägen 3 SE-739 30 Skinnskatteberg, Sweden Phone +46 222 440 00 Fax +46 222 440 99 www.systemair.com...
