LG RT-29FA65VE Service Manual page 27

Up to 29''
Hide thumbs

Advertisement

Table of Contents
LOCA. NO
PART NO
R841
0RF0161K607
1.6 OHM 2 W 5.00% TA62
R842
0RD1002F609
10K OHM 1/6 W 5% TA52
330 OHM 1/2 W(7.0) 5.00% TA52
R843
0RD3300A609
R844
0RD8200F609
820 OHM 1/6 W 5.00% TA52
R845
0RD1002F609
10K OHM 1/6 W 5% TA52
R846
0RD7502F609
75K OHM 1/6 W 5.00% TA52
220K OHM 1/6 W 5.00% TA52
R847
0RD2203F609
R858
0RD4701F609
4.7K OHM 1/6 W 5% TA52
R901
0RD2200F609
220 OHM 1/6 W 5.00% TA52
R902
0RD2200F609
220 OHM 1/6 W 5.00% TA52
R903
0RD2200F609
220 OHM 1/6 W 5.00% TA52
R904
0RD1801F609
1.8K OHM 1/6 W 5.00% TA52
R906
0RD1000F609
100 OHM 1/6 W 5% TA52
R907
0RD1000F609
100 OHM 1/6 W 5% TA52
R908
0RD1000F609
100 OHM 1/6 W 5% TA52
1/2 W 1.5K,10%,PLIKOR(HIGH SURGE)
R909
0RCZVTA002D
R910
0RCZVTA002D
1/2 W 1.5K,10%,PLIKOR(HIGH SURGE)
R911
0RCZVTA002D
1/2 W 1.5K,10%,PLIKOR(HIGH SURGE)
R912
0RD2204A609
2.2M OHM 1/2 W(7.0) 5.00% TA52
1.2K OHM 1/6 W 5% TA52
R913
0RD1201F609
R914
0RD2200F609
220 OHM 1/6 W 5.00% TA52
R915
0RD0102F609
10 OHM 1/6 W 5% TA52
R921
0RD1000F609
100 OHM 1/6 W 5% TA52
R922
0RD0622F609
62 OHM 1/6 W 5.00% TA52
R923
0RS0102J607
10 OHM 1 W 5.00% TA62
R924
0RS3300J607
330 OHM 1 W 5.00% TA62
R925
0RS4300J607
430 OHM 1 W 5.00% TA62
R926
0RS6800K607
680 OHM 2 W 5.00% TA62
SW1101
140-313A
TACT 2LEAD 100G(TA) LG C&D 5V 0.001A
SW1102
140-313A
TACT 2LEAD 100G(TA) LG C&D 5V 0.001A
TACT 2LEAD 100G(TA) LG C&D 5V 0.001A
SW1103
140-313A
SW1104
140-313A
TACT 2LEAD 100G(TA) LG C&D 5V 0.001A
SW1105
140-313A
TACT 2LEAD 100G(TA) LG C&D 5V 0.001A
SW1106
140-313A
TACT 2LEAD 100G(TA) LG C&D 5V 0.001A
SWP801
6600VM2002A
SDKEA3 ALPS IEC 250V 8A
SPARK GAP
SG901
165-004A
AG20PT 152F-L3N/S-23
SG902
165-004A
AG20PT 152F-L3N/S-23
AG20PT 152F-L3N/S-23
SG903
165-004A
SG904
6918VAX002H
WSP-122N 1200V -100V,+300V AXIAL TP
SG908
6918VAX002E
WSP-351M 350V 20% AXIAL TP 7.5MM
FILTER & CRYSTAL
FB1241
125-123A
FERRITE BFD3565R2F(TAPING)
FB401
125-022K
FERRITE AXIAL 62MM 1UH NY 3.5X6.0MM
FB801
125-022K
FERRITE AXIAL 62MM 1UH NY 3.5X6.0MM
FB802
125-022K
FERRITE AXIAL 62MM 1UH NY 3.5X6.0MM
FB803
125-022K
FERRITE AXIAL 62MM 1UH NY 3.5X6.0MM
FB825
125-022K
FERRITE AXIAL 62MM 1UH NY 3.5X6.0MM
DESCRIPTION
SWITCH
For Capacitor & Resistors,
the charactors at 2nd and 3rd
digit in the P/No. means as
follows;
LOCA. NO
PART NO
L920
125-022K
T1111
150-F06P
T802
150-F06T
X11
6202VDB007B
Z101
6200QL3001Z
JK1203
6613V00008A
JK201
6612VJH011K
JK202
6612VJH011L
A1
3828VA0464F
A2
6710V00112S
FP801
0FT4001B53C
PA1101
6726VH0001A
SK901
6620VBC003A
T402
6174V-5003L
TH801
163-058D
TU101
6700VS0002F
VD1111
164-003K
- 27 -
CC, CX, CK, CN : Ceramic
CQ : Polyestor
CE : Electrolytic
DESCRIPTION
FERRITE AXIAL 62MM 1UH NY 3.5X6.0MM
LINE FILTER SQE2930 10MH
SQE3535 20MH PHY TURN
RESONATOR,HC49U 20.250MHZ 30PPM
B39361-X6966-D100 EPCOS ST
JACK
PMJ014A E/P(ST
PPJ109K A/V I/O 6P STEREO FOR21PIN
PPJ109L A/V I/O 6P DVD
ACCESSORIES
MANUAL,OWNERS 112P/Q/R/S TX
REMOTE CONTROLLER,MC049A W/O PIP W/O TXT
MISCELLANEOUS
FUSE, 4000MA 250 V 5.2X20
REMOTE CONTROLLER RECEIVERTSOP1238RF1
SOCKET (CIRC),CPTPCS030A 8PIN 14/360
FBT,BSC28-N2334 29 YINGYANG
THERMISTOR,PTC03-07MX JA HWA 7 OHM
TUNER,TAEW-G002D W/W ALL IN W/S 09Z VE
VARISTOR,SVC621D-14A ILJIN 620V 0%
RD : Carbon Film
RS : Metal Oxide Film
RN : Metal Film
RF : Fusible
