EXPLODED VIEW PARTS LIST

LOCA. No.
PART No.
104
343-B52A
112
6334V29003A
120
120-C77G
121
4810V00088B
150
6140VC2005F
153
6150V-5006F
170
170-844K
174
6411VCH001A
300
3091V00361D
310
5020V00533B
320
320-062F
330
5020V00534D
400
3809V00123H
520
6871VMMT20Z
560
6871VSMJ32G
570
6871VSMJ43D
600
6871VSMJ30J
601
4810V00383E
610
6871VSMJ31B
700
0IGL120104A
913
332-229H
943
1PTF0403116
SUPPORTER, PCB(CF-14F20)
CPT, A68QCU759X 00M7ND LG-PHILIPS 48KHZ S/FOCUS
SPEAKER,FULLRANGE C122P02K1459 8 OHM 10/15W 130 57*117
BRACKET, SPEAKER CE-29K30 NON PP NONE
COIL,DEGAUSSING 29 FLAT ASSY (W) SELLA TECH 2001R+D07L
DY(DEFLECTION YOKE), 6150Z-1247A 29Ó LPDBJ (SIGLE FOCUS)
CPT EARTH, 29Ó 98T 4LUG LEAD SET SPRING(50MM)
POWER CORD ASSY, A001P201 CHAUS NON CHINA 2110M
CABINET ASSEMBLY, RT-29FB65VE NON MC049A (SY-SET)
BUTTON, CONTROL RT-29FA65VE(#117A) ABS, HF-380 6KEY MC049A
SPRING, KNOB SPRING
BUTTON, POWER RT-29FA65VE(#84B) ABS, HF-380 1KEY MC049AÓ
BACK COVER ASSEMBLY, RT-29FA65VE(ST-SET) 2PHONE MC049A
PWB(PCB) ASSEMBLY,MAIN MC049A RT-29FA65VE.LMLLSA8
PWB(PCB) ASSEMBLY,SUB CTL MC-049A FA60 LGESY
PWB(PCB) ASSEMBLY,SUB POWER MC-049A FA60 LGESY
PWB(PCB) ASSEMBLY,SUB A/V MC-049A FA60 SIDE A/V LGESY
BRACKET, SIDE AV 29FA55RB #117A MC049A ABS, HF-380 SY LOCAL
PWB(PCB) ASSEMBLY,SUB CPT MC-049A 29Ó FLAT+VM(W/O PIP) LGESY
IC,LG SEMICONDUCTOR CDS SENSOR MODULE(P1201-04)
SCREW,DRAWING HEXAGON HEAD
SCREW TAP TITE(P),TRUSS HEAD + D4.0 L16.0 MSWR3/FZB
