LG RT-29FA65VE Service Manual page 25

Up to 29''
Hide thumbs

Advertisement

Table of Contents
LOCA. NO
PART NO
P13B
387-A09J
9P 2.5MM 500MM H-B UL1007AWG26
6P 2.5MM 500MM H-B UL1007AWG26
P201B
387-A06J
387-A03J
3P 2.5MM 500MM H-B UL1007AWG26
P202B
P403B
387-A08F
8P 2.5MM 350MM H-B UL1007AWG26
P603B
387-A05J
5P 2.5MM 500MM H-B UL1007AWG26
RESISTOR
F802
0RP0050H709
0.05 OHM 1/2 W 10% TA52
F804
0RP0050H709
0.05 OHM 1/2 W 10% TA52
F805
0RP0020J809
0.02 OHM 1 W 20% TA52
0.02 OHM 1 W 20% TA52
F806
0RP0020J809
FR402
0RP0050H709
0.05 OHM 1/2 W 10% TA52
FR403
0RP0050H709
0.05 OHM 1/2 W 10% TA52
FR404
0RP0050H709
0.05 OHM 1/2 W 10% TA52
0.05 OHM 1/2 W 10% TA52
FR405
0RP0050H709
0RF0101K607
1 OHM 2 W 5.00% TA62
FR901
J204
0RD1000F609
100 OHM 1/6 W 5% TA52
J208
0RD1000F609
100 OHM 1/6 W 5% TA52
J211
0RD1000F609
100 OHM 1/6 W 5% TA52
0RD1000F609
100 OHM 1/6 W 5% TA52
J220
J222
0RD1000F609
100 OHM 1/6 W 5% TA52
J261
0RD1000F609
100 OHM 1/6 W 5% TA52
J509
0RD1000F609
100 OHM 1/6 W 5% TA52
100 OHM 1/6 W 5% TA52
J510
0RD1000F609
J512
0RD1000F609
100 OHM 1/6 W 5% TA52
J566
0RD1000F609
100 OHM 1/6 W 5% TA52
L1102
0RD0472F609
47 OHM 1/6 W 5% TA52
7.5K OHM 1/6 W 5.00% TA52
R102
0RD7501F609
0RD7502F609
75K OHM 1/6 W 5.00% TA52
R105
R109
0RD0562F609
56 OHM 1/6 W 5.00% TA52
R11
0RD1000F609
100 OHM 1/6 W 5% TA52
R110
0RD8200F609
820 OHM 1/6 W 5.00% TA52
0RD1301F609
1.3K OHM 1/6 W 5.00% TA52
R1101
R111
0RD0682F609
68 OHM 1/6 W 5.00% TA52
R1110
0RD1000F609
100 OHM 1/6 W 5% TA52
R112
0RD1501F609
1.5K OHM 1/6 W 5% TA52
300 OHM 1/6 W 5.00% TA52
R113
0RD3000F609
R1136
0RD4701F609
4.7K OHM 1/6 W 5% TA52
R1143
0RD3300F609
330 OHM 1/6 W 5.00% TA52
R1146
0RD3900F609
390 OHM 1/6 W 5% TA52
220 OHM 1/6 W 5.00% TA52
R1147
0RD2200F609
0RD3000F609
300 OHM 1/6 W 5.00% TA52
R1148
R1149
0RD3300F609
330 OHM 1/6 W 5.00% TA52
R1150
0RD4300F609
430 OHM 1/6 W 5.00% TA52
75 OHM 1/6 W 5.00% TA52
R1203
0RD0752F609
0RD0752F609
75 OHM 1/6 W 5.00% TA52
R1204
R1205
0RD0752F609
75 OHM 1/6 W 5.00% TA52
R1230
0RD2200A609
220 OHM 1/2 W(7.0) 5.00% TA52
R1231
0RD2200A609
220 OHM 1/2 W(7.0) 5.00% TA52
22K OHM 1/6 W 5% TA52
R124
0RD2202F609
R125
0RD2700A609
270 OHM 1/2 W(7.0) 5.00% TA52
R126
0RD1000F609
100 OHM 1/6 W 5% TA52
DESCRIPTION
- 25 -
For Capacitor & Resistors,
the charactors at 2nd and 3rd
digit in the P/No. means as
follows;
LOCA. NO
PART NO
R127
0RD1000F609
100 OHM 1/6 W 5% TA52
1.3K OHM 1/6 W 5.00% TA52
R13
0RD1301F609
0RD1001F609
1K OHM 1/6 W 5% TA52
R180
R181
0RD3002F609
30K OHM 1/6 W 5.00% TA52
R182
0RD1002F609
10K OHM 1/6 W 5% TA52
100K OHM 1/6 W 5% TA52
R183
0RD1003F609
0RD1801F609
1.8K OHM 1/6 W 5.00% TA52
R184
R185
0RD1801F609
1.8K OHM 1/6 W 5.00% TA52
R186
0RD4701F609
4.7K OHM 1/6 W 5% TA52
R187
0RD1801F609
1.8K OHM 1/6 W 5.00% TA52
22K OHM 1/6 W 5% TA52
R188
0RD2202F609
R189
0RD5602F609
56K OHM 1/6 W 5% TA52
R190
0RD5103F609
510K OHM 1/6 W 5.00% TA52
R191
0RD1000F609
100 OHM 1/6 W 5% TA52
4.7K OHM 1/6 W 5% TA52
R192
0RD4701F609
0RD4701F609
4.7K OHM 1/6 W 5% TA52
R193
R201
0RD0752F609
75 OHM 1/6 W 5.00% TA52
R202
0RD0752F609
75 OHM 1/6 W 5.00% TA52
75 OHM 1/6 W 5.00% TA52
R209
0RD0752F609
0RD0752F609
75 OHM 1/6 W 5.00% TA52
R210
R211
0RD0752F609
75 OHM 1/6 W 5.00% TA52
R212
0RD0752F609
75 OHM 1/6 W 5.00% TA52
R24
0RD1000F609
100 OHM 1/6 W 5% TA52
100 OHM 1/6 W 5% TA52
R25
0RD1000F609
R26
0RD2700F609
270 OHM 1/6 W 5% TA52
R28
0RD1000F609
100 OHM 1/6 W 5% TA52
R29
0RD1000F609
100 OHM 1/6 W 5% TA52
3.3K OHM 1/6 W 5.00% TA52
R30
0RD3301F609
0RD1501A609
1.5K OHM 1/2 W(7.0) 5.00% TA52
R301
R302
0RN4702F409
47K OHM 1/6 W 1.00% TA52
R303
0RD2400A609
240 OHM 1/2 W(7.0) 5.00% TA52
5.6 OHM 1/2 W(7.0) 5.00% TA52
R304
0RD0561A609
0RD1002F609
10K OHM 1/6 W 5% TA52
R305
R306
0RD1002F609
10K OHM 1/6 W 5% TA52
R307
0RD3601F609
3.6K OHM 1/6 W 5.00% TA52
R308
0RD4702F609
47K OHM 1/6 W 5% TA52
2K OHM 1/6 W 5% TA52
R309
0RD2001F609
R31
0RD3301F609
3.3K OHM 1/6 W 5.00% TA52
R310
0RD4702F609
47K OHM 1/6 W 5% TA52
R312
0RD4701F609
4.7K OHM 1/6 W 5% TA52
4.7 OHM 1/2 W 2.00% TA52
R313
0RN0471H509
0RN0471H509
4.7 OHM 1/2 W 2.00% TA52
R314
R315
0RS2700K607
270 OHM 2 W 5.00% TA62
R316
0RD1000F609
100 OHM 1/6 W 5% TA52
27K OHM 1/6 W 5.00% TA52
R317
0RD2702F609
0RN2001F409
2K OHM 1/6 W 1.00% TA52
R318
R319
0RN8202F409
82K OHM 1/6 W 1.00% TA52
R32
0RD3301F609
3.3K OHM 1/6 W 5.00% TA52
R320
0RD1001F609
1K OHM 1/6 W 5% TA52
0RD0561A609
5.6 OHM 1/2 W(7.0) 5.00% TA52
R321
R322
0RD1501F609
1.5K OHM 1/6 W 5% TA52
R323
0RD2702F609
27K OHM 1/6 W 5.00% TA52
CC, CX, CK, CN : Ceramic
RD : Carbon Film
CQ : Polyestor
RS : Metal Oxide Film
CE : Electrolytic
RN : Metal Film
RF : Fusible
DESCRIPTION
