- Page 1 Ambulatory blood pressure monitor featuring central blood pressure measurement User’s manual Please read the user’s manual carefully before the first use With wireless communication Bluetooth TensioMed® TensioDay Plus™‐5‐02 v2.00.06 Revised: 12‐10‐2015...
- Page 2 ________________________________________________________________________________________________________________________________ TensioMed® TensioDay Plus™ ...
-
Page 3: Table Of Contents
1. Introduction ............................... 4 1.1. Contents of the manual ........................ 5 1.2. Supplementary Information and Helpful Hints .................. 5 1.3. Warranty ............................. 6 1.4. General Information ........................... 6 2. The TensioMed® TensioDay Plus™ device .................... 8 2.1. Explanation of symbols ........................ 8 2.2. Accessories ............................ 1 0 2.3. Installing the Device .......................... 1 0 2.4. Operations Instructions ........................ 1 1 2.4.1. Functions of the button on the device .................. 1 2 2.4.1.1. One short push of the button ..................... 1 2 2.4.1.2. Two short pushes on the button .................. ... -
Page 4: Introduction
1. Introduction Thank you for choosing TensioMed® TensioDay Plus™. The TensioMed® TensioDay Plus™, ambulatory blood pressure monitor is a professional device, for clinical and ambulatory requirements, validated according to the British Hypertension Society and the Association for the Advancement of Medical Instrumentation standards. The device uses oscillometric method for blood pressure determination. It can also be used for ... -
Page 5: Contents Of The Manual
Copyright © 2011 TensioMed Ltd., Budapest, Hungary. All rights reserved. Under the copyright laws, this manual cannot be reproduced in any form without prior written permission of TensioMed Ltd. Every effort has been made to ensure that the information in this manual is accurate. ... -
Page 6: Warranty
1.3. Warranty TensioMed Ltd undertakes 2 years of warranty for the device (12 months for the accessories). The repairs are done by TensioMed Ltd at the place below. Head office and service: TensioMed Ltd. 163. Kétújfalu str. Budapest H‐1182 Hungary Phone: ( +36‐1) 433 1700, 433 1701 Fax: (+36 1) 433 1709 Web: www.tensiomed.com E‐mail: info@tensiomed.com 1.4. General Information, warnings and precautions We strongly suggest that you carefully study the Operating Instructions of this ... - Page 7 Pay special attention when applying the ambulatory BPM device to patients with serious mobility or other impairments, also unconscious or otherwise incapable patients and patients with coagulation disturbances. For children it is also recommended to apply the unit with special care. Children should not use the device on their own! Do not remove the outer cover of the device. The TensioMed® TensioDay Plus™ 24‐hour BPM device is sophisticated, multipurpose, software controlled measuring apparatus. In case of any problem, turn to a qualified service. Only use with cuffs supplied by TensioMed ltd. Use of cuffs supplied by a third ...
-
Page 8: The Tensiomed® Tensioday Plus™ Device
pressure to exceed 300 mmHg. If however the inflation continues above this value or the pressurization lasts too long, unplug the pneumatic connector of the cuff from the device and remove the cuff from the subject. Do not use the device on an arm, which is being injected with intravenous injection. Do not use on neonates. 2. The TensioMed® TensioDay Plus™ device 2.1. Explanation of symbols The front of the device is shown in Figure 1. Function button (Offering four menu options) Command symbols LCD Air connector ... - Page 9 17 The permanently placed in unused equipment must be collected in order to get more efficient reuse and recycling , as well as harmful effects on human health and for the environment of the ingredients are selectively 18 Level of protection against any liquid or grainy material filtering into the device (IP ) =2: Protected against solid foreign objects of 12,5mm and greater =2: Protection against vertically falling water drops when enclosure tilted up to 15° Figure 2. ________________________________________________________________________________________________________________________________ TensioMed® TensioDay Plus™ ...
-
Page 10: Accessories
2.2. Accessories TensioMed® TensioDay Plus™ ambulatory blood pressure monitoring device (Figure 1), is supplied with the following accessories: pouch for the device with belt four, AA size batteries 3 different cuffs TensioMed® TensioWin™ software on CD User’s manual Bluetooth adapter tape measure For the 3 different size cuffs the dimensions are: Cuff type Arm circumference Bladder dimensions Sleeve dimensions... -
Page 11: Operations Instructions
In case you do not have a Bluetooth communication adapter or a built‐in Bluetooth in your PC, connect the Bluetooth communication adapter to your PC and do the setting. If you find it necessary, ask for the help of your system supervisor who is responsible for your computer. Allow the Bluetooth communication in your PC. Then if the device is within 10 m from the Bluetooth adapter, the computer will get into connection with the device via the software. To transmit data, it is necessary to use the TensioMed® TensioWin™ program, of course. 2.4. Operation Instructions ... -
Page 12: Functions Of The Button On The Device
If the battery voltage is adequate, the device will be D 09-39 ready for measuring and the current computer time will be displayed. TensioMed® TensioDay Plus™ is ready for operation: 2.4.1.1. One short push of the button starts a manual measurement. During the ambulatory measuring mode, there might be a need for manual ... -
Page 13: 2. Two Short Pushes On The Button
N 20-39 up in the tabulated list of measurements. The device indicates the waking up by a D and by an N when the patient goes to bed. ________________________________________________________________________________________________________________________________ TensioMed® TensioDay Plus™ ... -
Page 14: Data Transmission
permitted ‐ the device and the PC will connect automatically. This sign will appear on the LCD. The actual data transmission does not happen, yet this can be started by the TensioMed® TensioWin™ program. During the operation of the Bluetooth communication CONNECT between the device and the PC, when the actual data ... -
Page 15: Error Codes For Users
(e.g. because of movement), the measurement will be interrupted. With the TensioMed® TensioWin™ program ‐ in case of a faulty measurement ‐ it is possible to set the device to repeat it according to the measuring ... -
Page 16: Sound Signals
You can connect it properly if you insert the plug with a twisting motion until it stops - during measurements avoid excessive muscle movement, particularly in the arm, as this may lead to longer measurement or measurement error and it may decrease the accuracy of the measurement - Ask the patient to keep a diary on his/her daily activities, symptoms, and the time of going to bed and waking up in the morning ________________________________________________________________________________________________________________________________ TensioMed® TensioDay Plus™ ... -
Page 17: Specifications
Operating environment: 10 ‐ 40 ° C Humidity: 30 ‐ 85 % Size: 116,0 × 94,0 × 47,0 mm Weight: 250g (including batteries) Blood Pressure measurement method: Oscillometric Data Storage: Max 1000 measurements Blood Pressure measurements range: 30 ‐ 280 mmHg Static accuracy: ±3 mmHg, or ± 2 % of the measured value Measuring accuracy: Systolic: 94 out of 99 comparisons were within 5 mmHg (95%), in case of 33 out of 33 patients, 2 comparisons out of 3 were within 5 mmHg, 0 out of 33 patients, where none of the measurements out of 3 were within 5 mmHg Diastolic: 93 out of 99 comparisons were within 5 mmHg (94%), in case of 32 out of 33 patients, 2 comparisons out of 3 were within 5 mmHg, 0 out of 33 patients, where none of the measurements out of 3 were within 5 mmHg Average difference from the auscultatic (Korotkov) measurements: (systolic / diastolic): 0.5/‐0.4 mmHg The range of the difference (systolic/diastolic): 2.8/2.8 mmHg Pressure sensor: Piezo‐resistive Inflation: Automatic motor‐driven pump Safety: Maximum inflation 280 mmHg Deflation: Automatic, stepwise ________________________________________________________________________________________________________________________________ TensioMed® TensioDay Plus™ ... -
Page 18: Electromagnetic Compatibility
The TensioMed® TensioDay Plus™ TD3 device is intended for use in the electromagnetic environment specified below. The customer or the user of the TensioMed® TensioDay Plus™ TD3 device should assure that it is used in such an environment. Emissions test Compliance Electromagnetic environment ‐ guidance RF emissions Group 1 The TensioMed® TensioDay Plus™ TD3 device uses RF CISPR 11 energy only for its internal function. Therefore, its RF emissions are very low and are not likely to cause any interference in nearby electronic equipment. RF emissions Class B The TensioMed® TensioDay Plus™ TD3 device is suitable ... - Page 19 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the TensioMed® TensioDay Plus™ TD3 device is used exceeds the applicable RF compliance level above, the TensioMed® TensioDay Plus™ TD3 device should be observed to verify normal operation. If abnormal performance is observed, ...
- Page 20 ________________________________________________________________________________________________________________________________ TensioMed® TensioDay Plus™ ...
- Page 21 ________________________________________________________________________________________________________________________________ TensioMed® TensioDay Plus™ ...
- Page 22 ________________________________________________________________________________________________________________________________ TensioMed® TensioDay Plus™ ...
- Page 23 ________________________________________________________________________________________________________________________________ TensioMed® TensioDay Plus™ ...
- Page 24 ________________________________________________________________________________________________________________________________ TensioMed® TensioDay Plus™ ...
