HEED OBELISK separates PRE and PX User Manual

OBELISK
separates
PRE and PX
Users Manual
Thank you for choosing our products!
With the development of the OBELISK separates, our aim was to take our highly praised
and award-winning Obelisk Si integrated amplifier to the next level of performance, in terms
of both functionality and sound. Using separate components for the various amplifier stages
gives more flexibility of use and achieves more transparency, information retrieval and
dynamic capability. We sincerely hope that you will agree, and that your Obelisk separates
will provide you with many years of impeccable, trouble-free operation.
Happy listening!
These components are designed to offer the finest performance available by avoiding
compromise, wherever possible. This detailed guide contains advice specifically related
to using this amplifier combination, as well as more general warnings about the use of
domestic audio components.

SPECIFICATIONS

Input (1) impedance:
Input (2-6) impedance:
Input (2-6) sensitivity (at 775 mV out):
RMS
Input (2) sensitivity / impedance with MM phono module
Output impedance (Pre Out, Tape Out):
Maximum output level (at THD = 1%):
Gain:
Headroom:
Signal-to-noise ratio (A-weighted):
Total harmonic distortion (at 775 mV out), unweighted):
RMS
Frequency response (+0, -1 dB, unity gain):
Frequency response (+0, -3dB, unity gain):
Power consumption:
Power consumption (standby):
Weight (Obelisk PRE):
(Obelisk PX):

WARRANTY

If within three years of the purchase date your Heed OBELISK PRE or PX prove to be defective
for any reason other than accident, misuse, neglect, unauthorised modification or fair wear and
tear, Heed Audio Ltd. will, at its discretion, replace the faulty parts without charge for labour. This
factory warranty is valid only for units sold into countries with no appointed Heed distributor.
Service enquiries in countries with appointed distributor should be addressed first to the
supplying dealer and/or Heed distributor. Warranties granted in these countries are entirely
at the discretion of distributor.
DISTRIBUTOR CONTACT
FACTORY CONTACT
HEED Audio Kft. (Ltd)
Reviczky Gyula u. 9-11
H-1181 Budapest
Hungary
75 Ohm
10 kOhm
220 mV
RMS
5 mV / 47 kOhm
35 Ohm
7.5 V
RMS
10 dB
20 dB
98 dB
<0,005 %
1 Hz - 105 kHz
1 Hz - 220 kHz
<10 W
4 W (+1 W per module)
4.2 kg
5 kg
Tel/Fax: +36 1 2947401
eMail: info@heedaudio.hu
Web: www.heedaudio.com
Heed OBELISK PRE - Users Manual 1.1 (2010)
