Steren 208-900 Instruction Manual

Steren 208-900 Instruction Manual

Tdt sdtv / hdtv tuner
Hide thumbs Also See for 208-900:
Table of Contents

Advertisement

Quick Links

208-900
TDT SDTV / HDTV Tuner
VIDEO
V2.0
Instruction manual
0915v
22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 208-900 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Steren 208-900

Summary of Contents for Steren 208-900

  • Page 1 208-900 TDT SDTV / HDTV Tuner VIDEO V2.0 Instruction manual 0915v...
  • Page 2 HIGHLIGHTS The SDTV high defi nition reciver allows you watch TV programs in High Defi ni- tion into current standard TV, with 480 lines of resolution (standard) defi nition, trough the RCA or RF connector and High Defi nition using the HDMI connector. Also, you can record TV programs using an USB memory (not included).
  • Page 3 IMPORTANT Please read the following precautions carefully before using the set-top box(STB): Do not disassemble the STB. If the STB products smoke or special smell, turn off the STB and remove the power plug. Power off the STB before inserting or removing video/audio cables, or when it is thundering.
  • Page 4 Package Contents The package should contain the following items: TV Receiver x1 pc Remote Control x1 pc User Manual x1 pc...

  • Page 5: Front Panel

    Product Description Front panel 1. REMOTE CONTROL SENSOR:Used to receive the signal from the Remote Control. 2. LED DISPLAY SCREEN: Used to display power on or standby. Rear panel 1. RF IN: This socket connects to your external Aerial. 2. RF OUT: This socket will feed the RF signal to either your TV oranother video sys- tem.
  • Page 6 Remote Controller POWER: Switch the receiver in and out of Standby mode. <0>-<9>: Numeric keys. MENU: Display main menu on TV screen, and press again to disappear menu. OK: To confi rm current setting, or display channel list in no-menu mode, VOL-/VOL+: To increase / decrease volume, or to move the cursor.
  • Page 7 Installation Placing the STB Place the STB on a stable table. Note: Do not place anything on the STB. Leave over 10cm space around two sides of the STB for radiating. Connecting Cables For a basic connection from your Set Top Box to your television set, you can use AV connection.

  • Page 8: Using The Remote Control

    Using the Remote Control Step 1 Open the battery box cover of the controller, insert 2 x AAA batteries according to the “+” and “–” marks in the battery box, and close the cover. Step 2 To use the Remote Control, point it towards the front of the Digital Set Top Box. The Remote Control has a range of up to 7 meters from the Set Top Box at an angle of up to 60 degrees.
  • Page 9 Basic operation Program manage settings To access the menu press the MENU button and select [Program]. Using the RIGHT/ LEFT keys to navigate through the menu. The menu provides options to adjust the program manage settings. Select an option and press OK or RIGHT to adjust that setting.

  • Page 10: Channel Search

    LCN (logical channel number) Set LCN no or off if you want to sort the channels manually. Channel search To access the menu, press MENU and select [Channel Search] using the RIGHT/LEFT keys. This menu provides options to adjust the search channel settings. Press UP/DOWN to select an option and press RIGHTLEFT to adjust the settings.
  • Page 11 Signal Type Set signal type here: Air or Cable. RF Channel Select RF channel. Here can be set RF CH3, RF CH4 or RF loopthrough. Option To access the menu, press MENU and select [Option] sing the RIGHT/LEFT keys. The menu provides options to adjust the OSD language,subtitle language and audio language.

  • Page 12: Time Setting

    AV Setting To access the menu, press MENU and select [System] using the RIGHT/LEFT keys. The menu provides options to adjust the system settings. Press the UP/DOWN key to select an option and press RIGHT/LEFT to adjust the setting. Press EXIT to exit the menu. Time Setting To access the menu, press MENU then select [Time] using the RIGHT/LEFT keys.

  • Page 13: Factory Setting

    System Select ‘System’ in the Main Menu to enter the Tools menu which contains 6 submenu items: Information, Factory Setting,Timer Setting, OSD Setting, USB Upgrade, and OTA Upgrade. Information View model, hardware and software information. Factory Setting Reset your set top box to the default factory settings. Enter your password or the default password ‘0000’...

  • Page 14: Usb Upgrade

    Timer Setting Timer setting here: (1) Timer List (2) Timer Setting OSD Setting USB Upgrade...
  • Page 15 OTA Upgrade 1) Auto OTA Setting. 2) Manual OTA Media center To access the menu, press the MENU button and select [Media Center] using the RIGHT/ LEFT keys. Music player...
  • Page 16 Picture Player Movie Player...
  • Page 17 Record Manager DVR Confi guration...
  • Page 18 Time shift Press [Pause] key fi rst, then at any time you can press [Play] key, the unit will start playing recorded program from the start. Press [Fast Forward] / [Fast Back] to move through current recording. Note: Time shifting is only available when USB HDD is connected to system and read/ write speed is high enough to support that.
  • Page 19 Troubleshooting Problem Potential Reasons What to do No picture Power isn’t connected Connect the power The power switch is not Switch on the power Screen shows Cable not connected Plug in the cable “No Signal” Aerial cable is faulty Check aerial cable and connections No sound from Speaker No or incorrect connec-...
  • Page 20 Specifi cations Input: 5 V --- 2A Resolution: 480p / 720p / 1080i / 1080p @ HDTV / 480i @ SDTV Input impedance: 75 Ω Bandwidth : 6 MHz Operating temperature: o° - 40° (+32° to 104° F) Humidity: 20% to 90% no condensing Storage temperature: - 20 °...
  • Page 21 Product: TDT SDTV / HDTV Tuner Part number: 208-900 Brand: Steren WARRANTY This Steren product is warranted under normal usage against defects in workmanship and materials to the original purchaser for one year from the date of purchase. CONDITIONS 1. This warranty card with all the required information, invoice, product box or package, and product, must be presented when warranty service is required.
  • Page 22 Este instructivo puede mejorar con su ayuda, llámenos al: Help us to improve this instruction manual, call us to: 01 800 500 9000 Centro de servicio a clientes Customer Service Center...
