1
What's in the shipping package?
The package includes the following items:
ZT-USB Series
Device
If any of these items are missing or damaged, please contact the local distributor
for more information. Save the shipping materials and cartons in case you want to
ship the module in the future.
2
Installing Driver and Utility
1.
Install the ZT-Series_Driver_Installer.exe (v1.0.0 or later) at first,
CD: \Napdos\ZigBee\ZT_Series\driver
http://ftp.icpdas.com/pub/cd/usbcd/napdos/zigbee/zt_series/driver
2.
Install the ZT Configuration Utility (v1.0.0 or later),
CD: \Napdos\ZigBee\ZT_Series\utility
http://ftp.icpdas.com/pub/cd/usbcd/napdos/zigbee/zt_series/utility
3.
Insert the ZT-USB Series into your computer, and you can find out ZT-USB
COM Port Number in the "Device Manager." Refer to the user manual for
more details.
CD: \Napdos\ZigBee\ZT_Series\document
http://ftp.icpdas.com/pub/cd/usbcd/napdos/zigbee/zt_series/document
ICP DAS, ZT-USB Series Quick Start, Version 1.02
ZT-USB Series
Quick Start
Release Note
Quick Start
CD
Page 1
Advertisement
Related Manuals for ICP DAS USA ZT-USB Series
Summary of Contents for ICP DAS USA ZT-USB Series
-
Page 1: Quick Start
Install the ZT Configuration Utility (v1.0.0 or later), CD: \Napdos\ZigBee\ZT_Series\utility http://ftp.icpdas.com/pub/cd/usbcd/napdos/zigbee/zt_series/utility Insert the ZT-USB Series into your computer, and you can find out ZT-USB COM Port Number in the “Device Manager.” Refer to the user manual for more details. CD: \Napdos\ZigBee\ZT_Series\document http://ftp.icpdas.com/pub/cd/usbcd/napdos/zigbee/zt_series/document... - Page 2 802.11b/g 802.11b/g Channel 1 Channel 6 Channel 11 2400 00 01 02 03 05 06 07 08 0A 0B 0C 0D 0E 0F 2485 802.11b/g Channel (North America) 802.15.4 Channel Page 2 ICP DAS, ZT-USB Series Quick Start, Version 1.02...
- Page 3 115200(Default) bps Communication Speed (The Interval Time of Sending Broadcast Frame): The data payload of ZT-2000 and ZT-USB series modules is 79 bytes. Once the data is more than 79 bytes, it will be divided into several packets. This parameter is used to decide the interval time of sending broadcast frame in order to prevent the network crashes.
-
Page 4: Data Transmission
ZigBee Slave 00 01 00 02 The above schematic diagram is showing ZT-USB series application mode, and it always transmits data to the remote device via broadcasting. M o d u l e F r a m e T y p e N o t e... - Page 5 Select the name of the module that you want to configure. After clicking the button, the utility will begin checking the connection. Once a connection is established, select either the [Default] or the [Wizard] Page 5 ICP DAS, ZT-USB Series Quick Start, Version 1.02...
- Page 6 RF Channel, RF Power, Baud rate, Data Format, Application Mode and so the relevant parameters. Once the module configuration has been completed, the message “The Configuration was successful” will be displayed. Page 6 ICP DAS, ZT-USB Series Quick Start, Version 1.02...
-
Page 7: Testing Communications
Use the DCON Utility on the Host PC to search for ZT-2000 series I/O modules. If there any devices are found, it means that the configuration is correct. DCON Utility ZT-USBC ZT-2000 Page 7 ICP DAS, ZT-USB Series Quick Start, Version 1.02... -
Page 8: Troubleshooting
Troubleshooting (1) Technical Support. If you have any difficulties using your ZT-USB series module, please send a description of the problem to service@icpdas.com, Please the following items, A description to the communication protocol for more information. A copy of the configuration file for the ZT module. This file can be obtained using the procedure outlined below and should be attached to your email.
