Panasonic EP1014-U1 Service Manual

Massage lounger

Advertisement

ep1014u1.html
Table Of Contents
COVER
1 Components identification
1.1 Massage lounger
1.2 Controller
2 Massage range (movement range of
massage wheels)
2.1 Upward massage, Downward
massage, Kneading rolling, Regional
kneading rolling
2.2 Tapping, Rolling, Regional rolling,
Tapping rolling, Regional tapping
rolling
3 Turning on the power
3.1 Turning on the power
4 Required tools
5 Actual wiring diagram
6 Display method of massage block
total use time and operation time
7 Motion of the clutch and belt based
on various massager operations.
8 Massager up/down detection
gear adjustment method
9 Removing the massage block
9.1 Removing the rear cover
9.2 Removing the massager
10 Disassembly (massager) and
assembly
10.1 Removing the motor
10.2 Removing the tapping shaft
assembly
10.3 Removing the gear box
10.4 Removing the massage wheel
unit set (right, left)
10.5 Removing and mounting the
up/down shaft bolt
10.5.1 Removing
10.5.2 Mounting
10.5.3
http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/PVAccel.html (1 of 2) [12/6/2003 9:48:19 AM]
Service Manual
TOP NEXT
ORDER NO.HPD0204U00C1
MASSAGE LOUNGER
EP1014-U1
Power source
: 120V AC, 60Hz
Power consumption
: 200W
Kneading speed
: Approx. 28 times/min.
Tapping speed
: Approx. 500 times/min.(per side)
Rolling massage speed
: Approx. 1 cycle every 37 sec.
Massaging width
: Shoulder/lower back section : Approx. 2-15/16 in. (75mm)
Back rolling width/tapping width : Narrow : Approx. 3-5/16 in. (85mm)/: Wide : Approx. 4-5/16 in. (110mm)
SPECIFICATIONS

Advertisement

Table of Contents
loading

Summary of Contents for Panasonic EP1014-U1

  • Page 1 : Approx. 1 cycle every 37 sec. 10.5.2 Mounting Massaging width : Shoulder/lower back section : Approx. 2-15/16 in. (75mm) 10.5.3 Back rolling width/tapping width : Narrow : Approx. 3-5/16 in. (85mm)/: Wide : Approx. 4-5/16 in. (110mm) http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/PVAccel.html (1 of 2) [12/6/2003 9:48:19 AM]...
  • Page 2 14.2 Examination after inspection and repairing 14.3 Q&A 14.4 Instructions for trouble shooting in response to a customer's claim. 15 Trouble shooting 16 Exploded view 17 Replacement parts list for EP1014- TOP NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/PVAccel.html (2 of 2) [12/6/2003 9:48:19 AM]...
  • Page 3: Components Identification

    7 Motion of the clutch and belt based on various massager operations. 8 Massager up/down detection gear adjustment method 9 Removing the massage block 9.1 Removing the rear cover 9.2 Removing the massager 10 Disassembly (massager) and assembly http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/ep1014u1.html (1 of 3) [12/6/2003 9:48:20 AM]...
  • Page 4 13 Disassembly instruction ( Cosmetic part and chair construction) 13.1 Seat Cushion 13.2 Massage Wheel Cover 13.3 Under Cover 13.4 Caster Pipe Cover 13.5 Power Source Switch Block 13.6 Circuit Board B 13.7 Roller ottoman 13.8 Ottoman Power Lift Unit http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/ep1014u1.html (2 of 3) [12/6/2003 9:48:20 AM]...
  • Page 5 14.1 Grease use 14.2 Examination after inspection and repairing 14.3 Q&A 14.4 Instructions for trouble shooting in response to a customer´s claim. 15 Trouble shooting 16 Exploded view 17 Replacement parts list for EP1014-U1 http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/ep1014u1.html (3 of 3) [12/6/2003 9:48:20 AM]...
  • Page 6: Specifications

    :•Not reclined and leg rest retracted : 41-11/32X34-41/64X40-35/64 in.(1050X880X1030mm)/ •Reclined and leg rest extended : 29-9/64X34- 41/64X68-7/64in.(740X880X1730mm) Reclining angle : Approx. 123° to 160° Weight : 121 lbs. (55kg) Accessories : Back cushion, Headrest, Cushion pad http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0000000000.html (1 of 2) [12/6/2003 9:48:21 AM]...
  • Page 7 Maximum user weight : 264lbs.(120kg). © 2002 Matsushita Electric Works, Ltd. All rights reserved. Unauthorized copying and distribution is a violation of law. TOP NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0000000000.html (2 of 2) [12/6/2003 9:48:21 AM]...
  • Page 8 1 Components identification TOP PREVIOUS NEXT 1.1 Massage lounger 1.2 Controller TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0100000000x.html [12/6/2003 9:48:23 AM]...
  • Page 9 1.1 Massage lounger TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0101000000.html (1 of 2) [12/6/2003 9:48:25 AM]...
  • Page 10 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0101000000.html (2 of 2) [12/6/2003 9:48:25 AM]...
  • Page 11 1.2 Controller TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0102000000.html (1 of 2) [12/6/2003 9:48:27 AM]...
  • Page 12 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0102000000.html (2 of 2) [12/6/2003 9:48:27 AM]...
  • Page 13: Massage Range (Movement Range Of

    2 Massage range (movement range of massage wheels) TOP PREVIOUS NEXT 2.1 Upward massage, Downward massage, Kneading rolling, Regional kneading rolling 2.2 Tapping, Rolling, Regional rolling, Tapping rolling, Regional tapping rolling TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0200000000x.html [12/6/2003 9:48:27 AM]...
  • Page 14 Upward and downward massage (from gentle to strong) :45mm-wide adjustability where massage heads push out toward body as intensity increases.Others (from gentle to strong) :15mm-wide adjustability where massage heads push out toward body as intensityincreases. TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0201000000.html [12/6/2003 9:48:28 AM]...
  • Page 15 Neck to waist : Massage range width : 3-5/16 in. or 4-5/16 in. (85mm or 110mm) Intensity adjustment Tapping : 45mm-wide adjustability where massage heads push out toward body as intensity increases. Others : 15mm-wide adjustability where massage heads push out toward body as intensity increases. TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0202000000.html [12/6/2003 9:48:29 AM]...
  • Page 16: Turning On The Power

    3 Turning on the power TOP PREVIOUS NEXT 3.1 Turning on the power TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0300000000x.html [12/6/2003 9:48:30 AM]...
  • Page 17 3.1 Turning on the power TOP PREVIOUS NEXT Timer When the on/off button is pushed, a timer begins to prevent overuse. After approximately 15 minutes, time expires and the massage wheel goes into strage position. TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0301000000.html [12/6/2003 9:48:32 AM]...
  • Page 18: Required Tools

    4 Required tools TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0400000000x.html (1 of 2) [12/6/2003 9:48:34 AM]...
  • Page 19 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0400000000x.html (2 of 2) [12/6/2003 9:48:34 AM]...
  • Page 20: Actual Wiring Diagram

    5 Actual wiring diagram TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0500000000x.html (1 of 2) [12/6/2003 9:48:36 AM]...
  • Page 21 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0500000000x.html (2 of 2) [12/6/2003 9:48:36 AM]...
  • Page 22: Display Method Of Massage Block

    *When replacing the Main Circuit PCB, the use time is counted to zero because the use time is memoried in Main Circuit PCB. *When pushing on/off button, the operation returns to normal mode. Display method Display it by utilizing LEDs of controller. Time display of 5 - 5115 hours possible. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0600000000x.html (1 of 2) [12/6/2003 9:48:38 AM]...
  • Page 23 To read the each operation function.After reading the total use time and push the following button, you can read the each operation funtion use time as same display method of total use time. TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0600000000x.html (2 of 2) [12/6/2003 9:48:38 AM]...
  • Page 24: Motion Of The Clutch And Belt Based

    7 Motion of the clutch and belt based on various massager operations. TOP PREVIOUS NEXT Massager operation and belt motion Massager operation and clutch motion http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0700000000x.html (1 of 2) [12/6/2003 9:48:40 AM]...
  • Page 25 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0700000000x.html (2 of 2) [12/6/2003 9:48:40 AM]...
  • Page 26 *One thread of the up/down detection gear gives a stroke change of 4mm. When the massager has been raised excessively : Turn the up/down detection gear clockwise to adjust. When the massager has been lowered excessively : Turn the up/down detection gear counterclockwise to adjust. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0800000000x.html (1 of 2) [12/6/2003 9:48:42 AM]...
  • Page 27 7. Install the rail piece A and B, and tighten uniformly the set screws (left and right, 3 pcs. each). 8. Using the manual operation of the controller, conduct the rolling operation. Set the massage heads adjustment switch to level 1, and check the up/down stroke. TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0800000000x.html (2 of 2) [12/6/2003 9:48:42 AM]...
  • Page 28: Removing The Massage Block

    9 Removing the massage block TOP PREVIOUS NEXT 9.1 Removing the rear cover 9.2 Removing the massager TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0900000000x.html [12/6/2003 9:48:43 AM]...
  • Page 29 1. Unzip the back cushion zipper and remove the back /cushion. 2. Unzip the rear cover fastener from the bottom of left side. 3. Pull the chair down backward and cut insulated ties and remove the plastic clip. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0901000000.html (1 of 2) [12/6/2003 9:48:45 AM]...
  • Page 30 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0901000000.html (2 of 2) [12/6/2003 9:48:45 AM]...
  • Page 31 Fitting B and Cord wire D and remove two cords from the massager. 6. Slide out the massager mechanism carefully. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0902000000.html (1 of 5) [12/6/2003 9:48:49 AM]...
  • Page 32 (2 of 5) [12/6/2003 9:48:49 AM]...
  • Page 33 (3 of 5) [12/6/2003 9:48:49 AM]...
  • Page 34 (4 of 5) [12/6/2003 9:48:49 AM]...
  • Page 35 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s0902000000.html (5 of 5) [12/6/2003 9:48:49 AM]...
  • Page 36: Disassembly (Massager) And

    10.2 Removing the tapping shaft assembly 10.3 Removing the gear box 10.4 Removing the massage wheel unit set (right, left) 10.5 Removing and mounting the up/down shaft bolt 10.5.1 Removing 10.5.2 Mounting 10.5.3 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1000000000x.html [12/6/2003 9:48:50 AM]...
  • Page 37 1. Remove the cable tie (medium), and remove the motor lead wire connector(white). 2. Remove the massage belt, up/down belt and intensity adjustment belt. 3. Remove the motor fitting set screw A to D, and remove the motor and tapping belt. TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1001000000.html [12/6/2003 9:48:51 AM]...
  • Page 38 Figure. B. Put the grease(WEP001Y8957) on the spring setting hole of Shield panel for PCB and set http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1002000000.html (1 of 3) [12/6/2003 9:48:54 AM]...
  • Page 39 Shield panel for PCB. C. Mount the Shield panel for PCB on massage mechanism. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1002000000.html (2 of 3) [12/6/2003 9:48:54 AM]...
  • Page 40 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1002000000.html (3 of 3) [12/6/2003 9:48:54 AM]...
  • Page 41 *Take care so that the grease does not stick to the massage clutch and up/down clutch pulleys. If grease sticks, remove it with alcohol. *The massage clutch and up/down clutch have similar shapes. The lead wires are the same gray color, so please choose based on connector color. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1003000000.html (1 of 2) [12/6/2003 9:48:56 AM]...
  • Page 42 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1003000000.html (2 of 2) [12/6/2003 9:48:56 AM]...
  • Page 43 5. Press down the Spring cover toward gear box and keeping press and remove the Fastening spring for shaft. Remove the Spring cover, Spring, and then remove the Massage wheel unit(left), Eccentric shaft ring and the Massage wheel unit(right). http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1004000000.html (1 of 3) [12/6/2003 9:48:58 AM]...
  • Page 44 (2 of 3) [12/6/2003 9:48:58 AM]...
  • Page 45 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1004000000.html (3 of 3) [12/6/2003 9:48:58 AM]...
  • Page 46 *1. To remove the up/down shaft bolt, the box driver (Ø13 mm) must be used. To install, the torque wrench with Ø13 mm must be used. *2. The torque wrench with Ø13 mm socket and the box driver (Ø13 mm) are available as parts. 10.5.1 Removing 10.5.2 Mounting 10.5.3 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1005000000.html [12/6/2003 9:48:59 AM]...
  • Page 47 Remove them with the box driver (Ø13 mm). (It is possible to use the Phillips head screwdriver. But it may deform the screw head. Therefore, it is necessary to use the box driver.) TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1005010000.html [12/6/2003 9:49:00 AM]...
  • Page 48 If the up/down shaft bolt has been excessively tightened, the bolt head may shear. Tighten the up/down shaft bolt of pinion A and pinion B, while controlling the torque. TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1005020000.html [12/6/2003 9:49:01 AM]...
  • Page 49 **When aligning two ellipse gears, smooth rotation will not be possible even if the alignment is off by just one tooth. During rotation, the gears will not match up, and may cause the massager to lock. Correct alignment of twogears required. TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1005030000.html [12/6/2003 9:49:02 AM]...
  • Page 50 10. Bind three cables at end of the cord guide frame and center of main circuit board with another two wires. 11. Wind three cords around the Cord wire for chair side one and half times and bind them together using a small cable tie. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1100000000x.html (1 of 2) [12/6/2003 9:49:04 AM]...
  • Page 51 12. Bind three cords with a small cable tie on approx. 8 in. from above binding position. *Caution during installation. *Put the massage block at its upper most point. *Do not allow the cord to ride on top of the frame. TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1100000000x.html (2 of 2) [12/6/2003 9:49:04 AM]...
  • Page 52 12 Arranging massage block lead wires TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1200000000x.html [12/6/2003 9:49:06 AM]...
  • Page 53 TOP PREVIOUS NEXT 13.1 Seat Cushion 13.2 Massage Wheel Cover 13.3 Under Cover 13.4 Caster Pipe Cover 13.5 Power Source Switch Block 13.6 Circuit Board B 13.7 Roller ottoman 13.8 Ottoman Power Lift Unit TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1300000000x.html [12/6/2003 9:49:07 AM]...
  • Page 54 1.Pull out the right and left armrest. 2.Pull out four rear head rest guides from the right and left under pipe./Please be careful of setting direction of the rear head rest guide as shown figure. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1301000000.html (1 of 2) [12/6/2003 9:49:09 AM]...
  • Page 55 3.Remove the seat cushion assy. TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1301000000.html (2 of 2) [12/6/2003 9:49:09 AM]...
  • Page 56 1.Detach the plastic clip on safety flap from matte. Cut two insulated tie carefully. 2.Remove eight screws connecting massage wheel cover and back frame. 3.Detach the plastic clip on top of back frame. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1302000000.html (1 of 2) [12/6/2003 9:49:11 AM]...
  • Page 57 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1302000000.html (2 of 2) [12/6/2003 9:49:11 AM]...
  • Page 58 1.Pull out the snap pin and take out the link support pin. 2.Cut two insulated ties connecting the under cover and the right and left under pipe. 3.Cut the insulated tie as shown figure. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1303000000.html (1 of 3) [12/6/2003 9:49:13 AM]...
  • Page 59 5.Remove staples connecting the under cover to the blow cushion left at inside of the power source switch block. 6.Unhook the under cover and remove the under cover. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1303000000.html (2 of 3) [12/6/2003 9:49:13 AM]...
  • Page 60 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1303000000.html (3 of 3) [12/6/2003 9:49:13 AM]...
  • Page 61 TOP PREVIOUS NEXT 1.Remove two screws connecting the caster with the right and left under pipe, and take off two casters.Cut three insulated ties, and remove two floor guides. 2.Pull out the caster cover. TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1304000000.html [12/6/2003 9:49:15 AM]...
  • Page 62 3.Remove screws and pull out the power source sw bracket. *If required to replace the fuse, after second step, pull out the fuse holder and replace the fuse inside. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1305000000.html (1 of 2) [12/6/2003 9:49:17 AM]...
  • Page 63 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1305000000.html (2 of 2) [12/6/2003 9:49:17 AM]...
  • Page 64 2.Cut the calbe tie and remove two screws of fitting B. Remove two screws of grounding wires. Remove all connectors on circuit board B. 3.Take out the circuit board B as shown figure. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1306000000.html (1 of 2) [12/6/2003 9:49:18 AM]...
  • Page 65 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1306000000.html (2 of 2) [12/6/2003 9:49:18 AM]...
  • Page 66 1.Remove the connector of the ottoman motor. 2.Remove two joint cover at upright position of the roller ottoman. 3.Remove the unzip the legrest cover. 4.Then remove the ottoman cover cloth. 5.Unscrew six screws and remove the ottoman housing B. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1307000000.html (1 of 6) [12/6/2003 9:49:24 AM]...
  • Page 67 6.Lower the ottoman pipe cover and cut an insulated tie, then pull out the cord. 7.Remove two slitted pins and nuts (M8). 8.Remove six screws assembled in the ottoman bearing housing B and ottoman gear box A. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1307000000.html (2 of 6) [12/6/2003 9:49:24 AM]...
  • Page 68 *Assemble instructions. 1.Set the ottoman pipe cover. 2.Set all components on the ottoman inside frame and tie up the cord. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1307000000.html (3 of 6) [12/6/2003 9:49:24 AM]...
  • Page 69 3.Assemble the ottoman housing B 4.Put the ottoman cover cloth on the roller ottoman unit and zip up. 5.Set the ottoman roller unit up to the ottoman pipe frame with two nut (M8). http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1307000000.html (4 of 6) [12/6/2003 9:49:24 AM]...
  • Page 70 6.Tie up a cord with the ottoman pipe frame and close the velcro. 7.Set two joint covers carefully by using any steel plate as shown figure. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1307000000.html (5 of 6) [12/6/2003 9:49:24 AM]...
  • Page 71 8.Set the legrest cover. TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1307000000.html (6 of 6) [12/6/2003 9:49:24 AM]...
  • Page 72 *Be careful that the back frame will fall down when removing the ottoman power lift unit. When disassembling, hold the back frame for safety and preventing from any damage of the back frame. http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1308000000.html (1 of 2) [12/6/2003 9:49:26 AM]...
  • Page 73 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1308000000.html (2 of 2) [12/6/2003 9:49:26 AM]...
  • Page 74 14 Other TOP PREVIOUS NEXT 14.1 Grease use 14.2 Examination after inspection and repairing 14.3 Q&A 14.4 Instructions for trouble shooting in response to a customer´s claim. TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1400000000x.html [12/6/2003 9:49:27 AM]...
  • Page 75 14.1 Grease use TOP PREVIOUS NEXT Please grease during each repair. Acceptable Grease •Alvania RA (light brown) •Molycoat (white) •E paste (yellow) •YM103 (yellow) •EM-D110 (yellow) TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1401000000.html [12/6/2003 9:49:29 AM]...
  • Page 76 •Upon finishing repairs, when placing the chair, make sure that it has enough space to fully recline. There should be more than 40cm between the wall and the chair when in the upright position. TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1402000000.html [12/6/2003 9:49:30 AM]...
  • Page 77 14.3 Q&A TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1403000000.html [12/6/2003 9:49:31 AM]...
  • Page 78 14.4 Instructions for trouble shooting in response to a customer´s claim. TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1404000000.html [12/6/2003 9:49:33 AM]...
  • Page 79: Trouble Shooting

    15 Trouble shooting TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1500000000x.html (1 of 6) [12/6/2003 9:49:38 AM]...
  • Page 80 (2 of 6) [12/6/2003 9:49:38 AM]...
  • Page 81 (3 of 6) [12/6/2003 9:49:38 AM]...
  • Page 82 (4 of 6) [12/6/2003 9:49:38 AM]...
  • Page 83 (5 of 6) [12/6/2003 9:49:38 AM]...
  • Page 84 TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1500000000x.html (6 of 6) [12/6/2003 9:49:38 AM]...
  • Page 85 16 Exploded view TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1600000000x.html [12/6/2003 9:49:39 AM]...
  • Page 86 FASTENING SPRING FOR SHAFT WEP578L0387 SPRING COVER WEP578L0197 SPRING WEP755L1187 MASSAGE WHEEL UNIT SET WEP755L1177 MASSAGE WHEEL UNIT (LEFT) WEP596L0637 ECCENTRIC SHAFT RING WEP755L1167 MASSAGE WHEEL UNIT (RIGHT) WEP1015L1008 MOTOR WEP1015L0178 GROUNDING PLATE http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1700000000x.html (1 of 8) [12/6/2003 9:49:45 AM]...
  • Page 87 WEP1800L1657 CIRCUIT BOARD SPACER WEP750L0207 PRO TEKTITE COVER FOR ECCENTRIC LINK WEP596L6328 SCREW(6ANGLE.S.K4-22) WEP1015L0197 ECCENTRIC SHAFT SPRING WEP596L6887 K TYPE RING STOPPER WEP569L0577 INTENSITY NUT CASE WEP755L0467 INTENSITY ADJUSTMENT PLATE WEP596L0218 GUIDE PLATE FOR GEAR BOX http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1700000000x.html (2 of 8) [12/6/2003 9:49:45 AM]...
  • Page 88 CORD FITTING WEP1014K3678 HEAD REST ASSY. BLACK Aromat WEP1014B3678 HEAD REST ASSY. BROWN Aromat WEP1014G3678 HEAD REST ASSY. GREEN Aromat WEP1014T3678 HEAD REST ASSY. TAUPE Aromat WEP1014N3678 HEAD REST ASSY. NAVY BLUE Aromat http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1700000000x.html (3 of 8) [12/6/2003 9:49:45 AM]...
  • Page 89 Aromat WEP1014N3638 CUSHION PAD (NAVY BLUE) Aromat WEP1014K3788 UNDER COVER (BLACK) Aromat WEP1014B3788 UNDER COVER (BROWN) Aromat WEP1014G3788 UNDER COVER (GREEN) Aromat WEP1014T3788 UNDER COVER (TAUPE) Aromat WEP1014N3788 UNDER COVER (NAVY BLUE) Aromat http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1700000000x.html (4 of 8) [12/6/2003 9:49:45 AM]...
  • Page 90 POLYETHYLENE WASHER WEP1015L6508 SERRATED WASHER WEP1010L0328 MATTE Aromat WEP1010L0918 COIL SPRING WEP1015L3468 CORD BUSHING WEP1022L0008 BLOW CUSHION RIGHT WEP1022L0018 BLOW CUSHION LEFT WEP1022L0098 UNDER PIPE RIGHT WEP1015L0099 UNDER PIPE LEFT WEP1014L0048 UPPER MEMBER http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1700000000x.html (5 of 8) [12/6/2003 9:49:45 AM]...
  • Page 91 WEP1014L1908 OTTOMAN HOUSING A WEP2010L6437 NUT M8 WEP2010L0917 SLITTED PIN WEP2000L6907 CUP WASHER B WEP2010L6897 WASHER WEP2100L9007 SCREW M4-80 WEP2010L6118 SCREW M4-14 WEP1015L2928 CONNECTING CORD FOR CONTROLLER WEP1015L2898 CONNECTING CORD FOR POWER SUPPLY A http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1700000000x.html (6 of 8) [12/6/2003 9:49:45 AM]...
  • Page 92 WEP1010L6558 HEX BOLT M6X12 WEP569K9047 TAPPING SCREW K3-10 WEP755L9107 SCREW K2-6 WEP752H0877 HINGE PIN D WEP004W8507 CABLE TIE L-8 WEP2000L0537 CIRCUIT BOARD SPACER WEP001Y8967 GREASE (EMD110) WEPGP1 GREASE (SHELL RA) WEP1800L0917 HINGE PIN D3 http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1700000000x.html (7 of 8) [12/6/2003 9:49:45 AM]...
  • Page 93 WEP1014K8008 INDIVIDUAL PACKAGE (BLACK) Aromat WEP1014B8008 INDIVIDUAL PACKAGE (BROWN) Aromat WEP1014G8008 INDIVIDUAL PACKAGE (GREEN) Aromat WEP1014T8008 INDIVIDUAL PACKAGE (TAUPE) Aromat WEP1014N8008 INDIVIDUAL PACKAGE (NAVY BLUE) Aromat WEP000S8857 TORQUE WRENCH WEP000S8867 BOX DRIVER TOP PREVIOUS http://202.224.189.178/~sgml/viewing/EP1014-U1/NA/SVC/s1700000000x.html (8 of 8) [12/6/2003 9:49:45 AM]...
