- Page 2 Installing the HDD/ODD Cage and Top Panel Foreword Thank you for your purchase of this Streacom product, every care has been taken to ensure that it meets with the high standards that we have set for ourselves. Should you have any questions that are not covered in this user guide, support can be offered via email through our website at www.streacom.com...
- Page 3 Specification Chassis Material Aluminum Available Colours Silver / Black - Brushed Finish Motherboard Compatibility Mini ITX HDD Drive Support 1 x 3.5" + 1 x 2.5" ODD Drive Support Slot loading drive, left side eject button Cooling Method Passive - Heat Pipe (65W Max TDH Recommended) Front Ports 2 x USB, 1 x SD Card Reader Dimensions...
- Page 4 Removing the Top Panel The top panel is held in place with 4 screws, 2 at the bottom and 2 at the side. The side screws are accessed between the gaps of the heatsink fins. Remove the screws and slide the top panel away from the chassis Removing the HDD/ODD Cage The HDD/ODD cage is held in place by 4 screws...
- Page 5 Installing the I/O Shield Locate the I/O shield that is supplied with your motherboard and firmly push it in place. Ensure that it clicks in place fully otherwise the motherboard will be difficult to fit. CPU Cooler Mounting Nut Adhesive Pad Protective Label Fit the CPU Cooler Mounting Nuts The chassis is supplied with 4 mounting nuts...
- Page 6 Installing the Motherboard Carefully lower the motherboard into the chassis, with the I/O port side leading so that the ports can fit into the I/O shield. When the motherboard is correctly in position, fix it to the chassis stand-offs using the screws provided. Ensure that all the holes correctly align before fully tightening the screws.
- Page 7 Attach the CPU Cooler Retention Arms The kit will include 2 retention arms which should be fixed to the underside of the lower CPU connector. These arms will allow the cooler to be fixed to the CPU and Motherboard. Thermal paste should be applied to the surface that will be in contact with the CPU.
- Page 8 Installing the HD and OD Drives With the cage out of the chassis, all the drives can fitted with ease. The slot loading optical drive is mounted using 4 screws, 2 either side. The mounting holes are rectangular which allows for small adjustments to the position on the drive.
- Page 9 Installing PCI Card (Optional) To install an expansion card, first remove the pre-installed PCI blanking plate by removing the single lower screw. The PCI mount can also be removed to make it easier to install the expansion card. This is done by removing the 2 screws either side on the mount.
- Page 10 Melbournestraat 56, 3047 BJ Rotterdam, The Netherlands www.streacom.com V1.12.02...
