Wall Chaser WCP 32 - original
instruction
Table of contents
1 Symbols .............................................. 9
 7RRO 6SHFL¿FDWLRQV ................................. 9
3 Application ........................................... 9
4 Controls .............................................. 9
5 Safety instructions ................................ 9
5.1 Safety precautions for work procedures
comprising abrasive cutting .................. 10
5.2 Further safety precautions for work
procedures comprising abrasive cutting ... 11
5.3 Emission levels ................................... 11
6 Tool clamping ..................................... 12
6.1 Installation of diamond discs ................ 12
6.2 Slotting with four discs ........................ 12
6.3 Uninstallation of diamond discs ............. 12
6.4 Adjusting the cutting depth .................. 12
7 Dust exhaust ...................................... 12
8 Commissioning ................................... 12
8.1 Smooth start-up ................................. 13
8.2 Overload protection ............................. 13
8.3 Thermal overload protection ................. 13
9 Maintenance ....................................... 13
10 Environmental Protection / Disposal ........ 13
11 Warranty ........................................... 13
12 Declaration of Conformity .................... 14
1

Symbols

Double insulation
Warning of general danger
Risk of electric shock
Use protective goggles!
Wear ear protection!
Wear a dust mask!
Use protective gloves!
Read the instructions
Not to be included in municipal refuse
Advice or tip
GB


7RRO 6SHFL¿FDWLRQV

Voltage
Frequency
Input power
Idle speed
Weight
of discs
Depth of groove
Width of groove
- with one disc
- with two discs
Width of spacer rings
Protection class
3

Application

This tool is intended exclusively for cutting grooves
and dividing of materials, especially concrete,
brickwork, tiles, etc., without the use of water. For
materials that produce dust or fumes hazardous to
health during processing, use an exhaust system in
line with regional safety regulations (see the Use
of higher class exhausters - M, H).
The user is responsible for any use not in compli-
ance with the intended use.
4

Controls

[1-1] Switch
[1-2] Switch unblocking
[1-3] Cutting depth regulating wheel
[1-4] Slide unblocking button
[1-5] Rotation direction arrow
[1-6] Exhaust attachment
[1-7] Auxiliary handle unblocking
[1-8] Auxiliary handle
[1-9] Load indication light
[1-10] Quick-clamp nut
[1-11] Shutter
[1-12] Spacer rings
[1-13] Diamond discs
Not all of the accessories illustrated or described
are included as standard delivery.
5

Safety instructions

WARNING!
Read all instructions. Failure to follow all instruc-
WLRQV OLVWHG EHORZ PD\ UHVXOW LQ HOHFWULF VKRFN ¿UH
and/or serious injury. The term "power tool" in all
of the warnings listed below refers to your mains-
operated (corded) power tool or battery-operated
(cordless) power tool.
9
220 - 240 V
50 - 60 Hz
1600 W
7200 min -1
4.9 kg
125 mm
0 - 32 mm
2.6 mm
7 - 35 mm
2.5; 5; 10; 15 mm
II /
