  • Page 1 LAPDOG INSTRUCTION MANUAL GAMING CONTROL CENTER...

  • Page 2: Table Of Contents

    Connecting Keyboard to LAPDOG ............15 Arranging Cables in LAPDOG ..............16 Reattaching Cable Compartment Cover ..........17 Reattaching Mouse Pad ................18 Connecting Your LAPDOG to the PC ............19 Using Other USB Peripherals and Devices with LAPDOG ....22 Using LAPDOG for Fast-Charging Your Cell Phone ......22...

  • Page 3: Introduction

    Its large and integrated 11" x 11" performance mouse pad guarantees unrestrained control and precision for your mouse movements. LAPDOG is very comfortable on your lap thanks to the underside memory foam lap cushion, which is removable when needed. LAPDOG also features a built-in powered USB 3.0 hub with additional ports for any USB headset, game controllers, flash drives and supports USB fast-charging.
  • Page 4 LAPDOG...

  • Page 5: Getting To Know Your Lapdog

    GAMING CONTROL CENTER Getting to Know Your LAPDOG Keyboard tray (Corsair K70 or K65 series) Corsair K65 keyboard adapter plate Cable compartment cover Mouse pad plate Memory foam pad Cable compartment USB 3.0 port #1 (internal) USB 3.0 port #2 (internal) USB 3.0 port #3 (external)
  • Page 6 LAPDOG...
  • Page 7 GAMING CONTROL CENTER Getting to Know Your LAPDOG (continued) 12V DC IN power LED indicator Allen screws x15 Allen key x1 Zip tie x2 Connection cable (16ft) USB 3.0 Type A plug 12V DC IN power jack 12V DC IN port USB 3.0 Type A plug...

  • Page 8: Installing Corsair K65 Series Keyboard And Wired Usb Mouse

    LAPDOG Installing Corsair K65 Series Keyboard and Wired USB Mouse Removing Mouse Pad Plate and Cable Compartment Cover 1. Unscrew and detach cable compartment cover (C). 2. Unscrew and detach mouse pad plate (D).

  • Page 9: Removing Keyboard Adapter Plate

    GAMING CONTROL CENTER Removing Keyboard Adapter Plate 1. Unscrew and detach the K65 keyboard adapter plate (B). 2. Slide the adapter plate (B) upwards.

  • Page 10: Installing K65 Keyboard

    45 degree angle. Once the front edge is placed securely underneath the bottom lip, lay the rest of the keyboard flat in the tray. Connecting Keyboard and Mouse to LAPDOG Connect the keyboard’s USB cable connector with keyboard icon on it into internal USB 3.0 port (G/H).

  • Page 11: Arranging Cables In Lapdog

    GAMING CONTROL CENTER Arranging Cables in LAPDOG Arrange the keyboard and mouse cables with the provided space inside the compartment (F). Use the supplied cable zip ties (P) to secure the bundle to both plastic loops protruding from the bottom of the cable compartment (F).

  • Page 12: Reattaching Cable Compartment Cover

    LAPDOG Reattaching Cable Compartment Cover 1. Close the cable compartment cover (C). 2. Secure cable compartment cover (C) with two allen screws (N) using the provided allen key (O).

  • Page 13: Reattaching Mouse Pad

    GAMING CONTROL CENTER Reattaching Mouse Pad Plate 1. Reattach mouse pad plate (D). 2. Secure mouse pad plate (D) with four allen screws (N) using the provided allen key (O).

  • Page 14: Installing Corsair K70 Series Keyboard And Wired Usb Mouse

    LAPDOG Installing Corsair K70 Series Keyboard and Wired USB Mouse Removing Mouse Pad and Cable Compartment Cover 1. Unscrew and detach cable compartment cover (C). 2. Unscrew and detach mouse pad plate (D).

  • Page 15: Removing Keyboard Adapter Plate

    GAMING CONTROL CENTER Removing Keyboard Adapter Plate 1. Unscrew and detach the K65 keyboard adapter plate (B). 2. Slide the adapter plate (B) upwards.

  • Page 16: Installing K70 Keyboard

    45 degree angle. Once the front edge is placed securely underneath the bottom lip, lay the rest of the keyboard flat in the tray. Connecting Keyboard and Mouse to LAPDOG Connect the keyboard’s USB cable connector with keyboard icon on it into internal USB 3.0 port (G/H).

  • Page 17: Arranging Cables In Lapdog

    GAMING CONTROL CENTER Arranging Cables in LAPDOG Arrange the keyboard and mouse cables with the provided space inside the compartment (F). Use the supplied cable zip ties (P) to secure the bundle to both plastic loops protruding from the bottom of the cable compartment.

  • Page 18: Reattaching Cable Compartment Cover

    LAPDOG Reattaching Cable Compartment Cover 1. Close the cable compartment cover (C). 2. Secure cable compartment cover (C) with two allen screws (N) using the provided allen key (O).

  • Page 19: Reattaching Mouse Pad

    GAMING CONTROL CENTER Reattaching Mouse Pad Plate 1. Reattach mouse pad plate (D). 2. Secure mouse pad plate (D) with four allen screws (N) using the provided allen key (O).

  • Page 20: Connecting Your Lapdog To The Pc

    LAPDOG Connecting Your LAPDOG to the PC 1. Locate LAPDOG end (R+S) of the provided 16ft cable (Q). 2. Connect USB 3.0 plug (R) to USB 3.0 host connection port (K) on the back of the LAPDOG. 3. Connect 12V DC IN power jack (S) to 12V DC IN power port (L)
  • Page 21 GAMING CONTROL CENTER 4. On the other end of cable (Q), locate another Y-split section with USB 3.0 Type A plug (U) and 12V DC IN port (T). 5. Connect USB 3.0 plug (U) to any available USB 3.0 port on your computer.
  • Page 22 LAPDOG 6. Connect supplied 12V charging cable (V) to 12V DC IN port (T) on the Y-split section. Enjoy your new LAPDOG!

  • Page 23: Using Other Usb Peripherals And Devices With Lapdog

    GAMING CONTROL CENTER Using Other USB Peripherals and Devices with LAPDOG 1. LAPDOG provides two external USB 3.0 ports (I and J) for connecting various other USB peripherals and devices. Once they are connected to the LAPDOG, they will be recognized by the host PC as if they were directly connected to any available USB port on that host PC.
