Section 2 : Introduction

The BEC23 meter is a single phase, STS compliant Prepayment Electricity Meter comprising 2 parts, these
being a totally sealed metering unit and a wall base. There are different models in the BEC23 range.
These models are listed below with their technical specifications. Note the actual functionality of the
different models is identical.
BEC23 Technical Manual
BEC23PL
This is a STS single-phase prepayment electricity meter that utilizes a common
base. The data is entered by means of a keypad and the internal
disconnection switch is rated to 100A.
BEC23PLT
This is a STS single-phase prepayment electricity meter that utilizes a common
base. The data is entered by means of a keypad and the internal
disconnection switch is rated to 100A. It also has a tamper switch to detect
tampering on the meter.
BEC23PD/T
This is a STS single-phase prepayment electricity meter that utilizes a common
base. The data is entered by means of a keypad and the disconnection switch
is a double pole circuit breaker, rated to 60A.
BEC23PE
This is a STS single-phase prepayment electricity meter that utilizes a common
base. The data is entered by means of a keypad and the disconnection switch
is an earth leakage circuit breaker, rated to 20A.
BEC23PET
This is a STS single-phase prepayment electricity meter that utilizes a common
base. The data is entered by means of a keypad and the disconnection switch
is an earth leakage circuit breaker, rated to 20A. It also has a tamper switch to
detect tampering on the meter.
