How to connect the SmartBox
W ITH SMARTL INK
HEA DS TA GE S
™
SmartLink
Headstage
Standard
Probe
3.5 mm jack for
aural monitoring
Micro HDMI Connector
REF
™
NeuroNexus Technologies, Inc. ©2014
Telephone: +1.734.913.8858 | Fax: +1.734.786.0069 |
™
USB port
Connect to earth ground
USB port
(Standard-B)
HDMI Connector
p.9
| 655 Fairfield Court, Suite 100, Ann Arbor, Michigan USA
support@neuronexus.com
CONNECTIONS
PC
5 VDC, 2 A in
SmartBox
™
