Page 1: Quick Installation Guide
Disk Station DS1010+ Quick Installation Guide DS1010+11182009... -
Page 2: Table Of Contents
Table of Contents Chapter 1: Before You Start Package Contents Safety Instructions Chapter 2: Hardware Setup Tools and Parts for Hard Disk Installation Install Hard Disks Start Up Your DS1010+ Chapter 3: Install DS1010+ Firmware Install from Windows Install from Mac OS X Install from Linux Learn More... -
Page 3: Chapter 1: Before You Start
Before You Start Before you start setting up DS1010+, please check the package contents to verify that you have received the items below. Please also read the safety instructions carefully before use to prevent your DS1010+ from any damages. Package Contents Main Unit x 1 AC power cord x 1 2M RJ-45 LAN cable x 2... -
Page 4: Safety Instructions
Do not use chemical or aerosol cleaners to clean it. Do not place the Synology product on a cart, table, or desk, which is not stable to avoid the product from falling over. The power cord must plug in to the right supply voltage. Make sure that the supplied AC voltage is correct and stable. -
Page 5: Chapter 2: Hardware Setup
• At least one 3.5” or 2.5” SATA hard disk (Please visit www.synology.com for compatible hard disk models.) Warning: If you install a hard disk that contains data, system will format the hard disk and erase all data. If you need the data in the future, please back it up before installation. - Page 6 Pull the handle to remove the hard drive tray from DS1010+. Load the hard disk in the hard drive tray. For 3.5” Hard Disk: Place the hard disk in the hard drive tray, and then tighten the screws to secure the hard disk. For 2.5”...
- Page 7 Insert the loaded hard drive tray into the empty hard disk bay. Important: Make sure the tray is pushed in all the way. Otherwise, the hard disk might not be able to function properly. Press the handle in flush with the front panel to hold the hard drive tray in place. Slide the Lock switch downward to lock the handle of the hard drive tray.
- Page 8 The disk position is numbered as shown below (starting from left): HDD1, HDD2, HDD3, HDD4, and HDD5, respectively. Note: If you want to set up a RAID set, it is recommended that all installed hard disks are of the same size to make the best use of hard disk capacity. Chapter 2: Hardware Setup...
-
Page 9: Start Up Your Ds1010
Start Up Your DS1010+ Connect one end of the power cord to the Power port of DS1010+, and the other to the power outlet. Power port Use the LAN cable to connect DS1010+ to your switch/router/hub. LAN port Push the Power button on the front panel to turn on your DS1010+. Power button Your DS1010+ is now online and detectable from a network computer. -
Page 10: Chapter 3: Install Ds1010+ Firmware
DS1010+. After the firmware is installed, you can manage all features of your DS1010+ by logging into the Disk Station Manager with a web browser. Install from Windows Insert the installation CD into your computer, and then choose Set up the Synology Server from the autorun menu. - Page 11 After Synology Assistant opens, double-click your DS1010+ from the server list. Click Browse to select the “.pat” installation file in the installation CD. Follow the onscreen instructions to complete the setup process. Note: If you choose One-Click Setup, the default admin password for your Disk Station Manager will be blank.
-
Page 12: Install From Mac Os X
SynologyInstall icon on the desktop. In the window that appears, double-click the MacOSX folder, and then double-click Synology Assistant-2.2-[number].dmg. Double-click the Synology Assistant.app in the window that appears. After Synology Assistant opens, double-click your DS1010+ from the server list. Chapter 3: Install DS1010+ Firmware... - Page 13 Click Browse to select the “.pat” installation file in the installation CD. Follow the onscreen instructions to complete the setup process. Note: If you choose One-Click Setup, the default admin password for your Disk Station Manager will be blank. Chapter 3: Install DS1010+ Firmware...
-
Page 14: Install From Linux
Linux distributions (for evaluation purpose only). Install and Run Synology Assistant You can install and run Synology Assistant using the command lines or the GUI. If you want to install using the command lines: Run the script install.sh in the Linux folder of the installation CD, which will guide you through the steps below. - Page 15 Insert the installation CD into your computer, and then double-click the SynologyInstall icon on the desktop. In the File Browser window that appears, double-click the Linux folder, and then double-click Synology Assistant-2.2-[number].tar.gz. Click Extract, and then extract the SynologyAssistant directory to the path “/usr/ local” or any other path.
- Page 16 “/usr/local/SynologyAssistant” (or “ [the path you just specified]/ SynologyAssistant”), double-click SynologyAssistant, and then select Run in Terminal in the dialog box that appears. Install DS1010+ Firmware After Synology Assistant opens, double-click your DS1010+ from the server list. Chapter 3: Install DS1010+ Firmware...
-
Page 17: Learn More
Learn More Congratulations! Your DS1010+ is set up now. Refer to the User’s Guide in the installation CD for advanced settings and management. For more information or online resources about your DS1010+, please visit www.synology.com. Chapter 3: Install DS1010+ Firmware... -
Page 18: Copyright Notice
LIMITED WARRANTY AND LIABILITY Synology provides a limited warranty for its Products only to the initial person or entity that originally purchased the Product from Synology or its authorized distributor or retailer. Synology warrants that every hardware portion of the Products will be free from physical defects in material and workmanship within warranty period, or the Product will be repaired or replaced as determined solely by Synology. - Page 19 (ii) the related order for, purchase, delivery, receipt or use of any product or service from Synology, or iii) any other dispute arising out of or relating to the relationship between You and Synology; the term “Synology” means Synology, Inc, its parents, subsidiaries, affiliates, directors,...
