Pathos Acoustics Converto User Manual page 7

Power Supply & Swith ON.
Connect the power supply output (B) into the socket on the rear
panel of the unit (12).
Connect the power plug of the power supply input (A) to the
power cord that came with the box and plug the cable into the
socket on the wall.
When Converto is properly powered the power LED (16) will
turn red, indicating that Converto is on standby mode (standby
consumption is less than 1W).
To turn on Converto simply press the power button (15) on the
front panel, the power LED (16) goes from red to green and
starts flashing after about 10 seconds and remain ON, one of the
LEDs will light up to indicate the selected input (20 21 22 or
23).
From now CONVERTO is on and ready to work.
To turn off Converto just hold down the power button (15) for 2 seconds, the LED indicates the selected
input turns off and the power LED (16) goes from green to red.
Converto is in standby mode.
Each time it is turned on again Converto stores the last input selected, but if power is removed the next
time the selected input will be the number one (20)
Inputs
Converto has 4 inputs, 3 digital and one analog for headphone listening.
To select the input just press the input selector button (17)
Input 1. USB:
Connect this input (11) a USB cable type "B" from a PC.
Before connecting to a computer, you must install it on the proper drivers that
came with the USB stick included in the package.
The LED (20) on the front panel indicates that this input has been selected.
Input 2. SPDIF optic or RCA:
Connected to this input a digital source via optical cable (10A) or RCA (10B).
Through the switch (9), you can decide whether to use input 2 in one way or another.
The LED (21) on the front panel indicates that this input has been selected.
Input 3. SPDIF RCA:
Connected to this input (8) a digital source via RCA cable.
The LED (22) on the front panel indicates that this input has been selected.
Input 4. Line IN (only for headphone listening)
Connected to this input (7) a line source through RCA stereo cable.
This input can only be used for headphone listening.
The LED (23) on the front panel indicates that this input has been selected.
Output
Converto has two line outputs, balanced and unbalanced.
Balanced output:
it is a stereo line where you can connect a pair of balanced XLR cables (4.5).
Unbalanced output:
it is a stereo line where you can connect a pair of unbalanced RCA cables (6).
