SMART/RG SR512nm Quick Start Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Quick Start Guide

SR512nm
This Quick Start Guide shows you how to set up and start using your new gateway.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR512nm and is the answer not in the manual?

Questions and answers

Related Manuals for SMART/RG SR512nm

Summary of Contents for SMART/RG SR512nm

  • Page 1: Quick Start Guide

    Quick Start Guide SR512nm This Quick Start Guide shows you how to set up and start using your new gateway.

  • Page 2: Installation

    INSTALLATION 1. Connect the DSL port of the gateway and the Modem port of the splitter with a telephone cable; connect the phone to the phone port of the splitter through a cable; and connect the incoming phone line to the Line port of the splitter. The splitter has three ports: Modem: Connect to the DSL interface of the gateway Phone: Connect to a telephone set...
  • Page 3 COAX 5 min...

  • Page 4: Led Indicators

    LED INDICATORS The LEDs on the SR512nm can assist you in better understanding the current state of your gateway. DSL 1-2 INTERNET LAN 1-4 WIFI POWER USB 1-2 COAX DSL sync in progress DSL sync acquired and gateway online Gateway online and data transfer in progress...

  • Page 5: Quick Gateway Configuration

    QUICK GATEWAY CONFIGURATION Warning: Do not press the Reset button unless you want to clear the current settings. The Reset button is in a small circular hole on the rear panel. If you want to restore the default settings, insert a thin wire (such as a paper clip) into the hole, press the Reset button gently for 1 second, and then release the button.

  • Page 6: Configuring The Wan Manually

    User Name: admin Password: admin Note: Your service provider may use other settings. Contact your provider for details. Configuring the WAN manually If the automatic connect process is unsuccessful, refer to the Advanced Setup > Layer 2 Interface WAN Services sections of the SmartRG SR2 3xx - SR5xx Gateway User Manual to manually establish a connection.

  • Page 7: Wifi Setup

    WiFi Setup Two methods, WPS and Manual, are available for WiFi setup. Perform the steps on this page for both methods, and then follow the instructions for the applicable method. 1. In the top navigation bar, click WIFI and then click 2GHz or 5GHz in the left menu. The steps are the same for both options.

  • Page 8: Wps Method

    WPS Method If the device you wish to connect to the Internet via your gateway supports the WPS secure WiFi connection method, follow these steps. 1. In the left navigation bar, click Wireless > Security. 2. Select Enable WPS and click Apply/Save to commit your selection.

  • Page 9: Manual Method

    Manual Method Set up your gateway’s parameters first, then follow these steps. 1. In the left navigation bar, select Wireless > Security and scroll down to the Manual Setup AP section. 2. If your gateway supports multiple wireless networks, select the SSID of the network you wish to configure.

  • Page 10: Fcc Statement

    FCC Statement FCC - PART 68 This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the bottom case of this equipment is a label that contains, among other information, a product identifier in the format US: VW7DL01BSR512NM. This equipment uses the following USOC jacks: RJ-11/RJ45/USB/Power Jacks.

  • Page 11: Fcc Radiation Exposure Statement

    IC CS-03 statement This product meets the applicable Industry Canada technical specifications. / Le présent matériel est conforme aux specifications techniques applicables d’Industrie Canada. The Ringer Equivalence Number (REN) is an indication of the maximum number of devices allowed to be connected to a telephone interface. The termination of an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices not exceed five.
  • Page 12 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution! Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. ...
  • Page 13 Le présent émetteur radio (identifier le dispositif par son numéro de certification ou son numéro de modèle s'il fait partie du matériel de catégorie I) a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur.

  • Page 14: Record Your Sr512Nm Wifi Settings

    RECORD YOUR SR512nm WIFI SETTINGS Predefined wireless settings If you change the preset wireless settings WiFi network name (SSID) Network key (password) ADDITIONAL SUPPORT If you require further instructions, please contact your local ISP Support. SMARTRG INC. ALL RIGHTS RESERVED. COPYRIGHT 2016 ©...
