- Page 1 TruWave Plus Multi-modality Device: IFC - TENS - NMES Strength Pain Relief Quick Start Guide 9990 Park Meadows Drive, Lone Tree, Co 80124, Office: 1-800-495-6670 Fax: 1-800-495-6695 Website: www.zynex.com Form #30058 Rev 1...
- Page 2 Remove Electrodes From Bag & Connect Leadwires Step 1 Leadwire Ends IFC Electrode Placement (4 Electrodes Required) Regardless of where your pain is on the body, when operating in IFC the BLACK BLACK ends of the leadwires must crisscross. Surround the area of pain BLACK with the electrodes as shown.
- Page 3 How to Set the Device to IFC & Start Treatment Press up arrow button once to turn To change treatment "Timer" Press display on the down or up arrow buttons, then press "Prog." button once Press the Program (Prog.) button Start treatment by pressing either up arrow button until the stimulation is strong but...
- Page 4 It is recommended to consult with your health care professional for electrode placement options, the specific NMES treatment mode and the treatment duration and frequency. If you need technical support or have additional questions about how to use your TruWave Plus, please call customer service: 800-495-6670...
Need help?
Do you have a question about the TruWave Plus and is the answer not in the manual?
Questions and answers
How do I get to both wires to work to use 4 pads, not just 2
To use 4 pads (electrodes) on the Zynex Medical Plus:
1. Insert the RED lead wire pin connectors into two electrode connectors on one side.
2. Insert the BLACK lead wire pin connectors into two electrode connectors on the other side.
3. Remove all four electrodes from their plastic backing.
4. Place the electrodes on the treatment site according to the selected modality:
- For IFC modality: arrange electrodes in a crisscrossed pattern.
- For TENS or NMES: place electrodes in a side-by-side or up-and-down pattern (crisscrossing is optional for TENS).
5. Plug both sets of lead wires (Channel 1 and Channel 2) into the top of the device.
This setup enables the use of 4 electrodes with 2 channels.
